Summary of Contents for CPG ULTRA Series
- Page 1 User Manual Electric Countertop Griddles 351GUCPG24M, 351GUCPG36M, 351GUCPG48M REVISED 12/2022 www.cookingperformancegroup.com...
-
Page 2: Table Of Contents
User Manual Congratulations on your purchase of Cooking Performance Group commercial cooking equipment! At Cooking Performance Group, we take pride in the design, innovation, and quality of our products. To ensure optimal performance, we have outlined the following instructions and guidelines in this manual carefully for your review. -
Page 3: Features & Specifications
User Manual Features & Specifications • 1" thick chrome plated griddle for enhanced heat distribution and quick recovery • Snap-action thermostat from 150 - 450°F • 3000/4000W (208/240V) element per each 12" of cooking surface • 20.7" deep plate provides greater cooking surface •... -
Page 4: Safety Precautions
Improper installation, adjustment, alteration, service or maintenance could lead to property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing CPG equipment. This manual must be retained for future reference. • A factory authorized agent must handle all maintenance and repair. -
Page 5: Receiving Product
• Installation and service should be performed by an authorized service agency. All CPG griddles should also be installed under an approved hood. CPG Limited Warranty does NOT cover equipment that fails to follow these guidelines or has been altered, modified, or repaired by anyone other than an authorized service agency. -
Page 6: Installation Instructions
• Level unit by adjusting the (4) feet which have an adjustment of 1¾" (43.75mm) for accurate leveling and perfect line-up with other CPG series units. EXHAUST CANOPY • This product conforms to UL-197 standards and is required to be installed under a ventilation hood in accordance with all applicable codes. - Page 7 NOTE: CPG Series electric griddles may be wired for operation in the field for either 1-phase or 3-phase power supplies by making line connections at the junction box(es) located at the rear of the unit. NOTE: A qualified electrical installer must install this griddle.
-
Page 8: General Operation
Your new CPG chrome plated griddle has excellent heat retention and heat transfer as well as minimal flavor transfer. CPG has created a griddle that offers a reduction in energy costs and clean up time, translating into a great deal of profit savings. - Page 9 User Manual COOKING • Set the thermostat dial knob at the temperature desired. • After a short pre-heating period (15-20 minutes), the thermostat will automatically maintain the selected temperature. We recommend the operating temperature for a chrome griddle to be 10- 15°F LOWER than standard griddles.
-
Page 10: Cleaning Instruction
User Manual Cleaning Procedure CAUTION: CHROME PLATED GRIDDLES ARE DELICATE PIECES OF EQUIPMENT. • DO NOT use any abrasive or flammable cleaning fluids. • DO NOT hose down, immerse, or pressure wash any part of the griddle, excluding the catch tray. •... - Page 11 User Manual DAILY CLEANING 1 . Clean plate while still hot between 300-350°F. 2 . Scrape griddle plate with blade scraper ONLY. 3 . Pour room temperature water (or for heavy duty cleaning, Noble Chemical Griddle Kleen cleanser (#147GKCHROME) on the surface and immediately scrub the griddle with a natural non-scratching stiff bristle brush.
-
Page 12: Troubleshooting
User Manual Troubleshooting NOTE: These examples are provided for your reference. Provided a failure occurs, stop using the griddle immediately and contact an authorized service agency. All maintenance should be done with the power supply shut off. Problem Possible Causes Solutions Heat is set too high Turn heat down... -
Page 13: Load Chart
User Manual Electrical Diagrams LOAD CHARTS Phase Three Phase Single Phase Voltage Rated Wattage 6000 8000 6000 8000 Wire Connect Nominal Amps Per Line 14 .4 14 .4 16 .7 28 .9 16 .7 28 .88 Use Wire Size or Larger Phase Three Phase Single Phase... -
Page 14: Electrical Diagrams
User Manual Electrical Diagrams 351GUCPG24M www.cookingperformancegroup.com... - Page 15 User Manual Electrical Diagrams 351GUCPG36M 351GUCPG48M www.cookingperformancegroup.com...
