Gas Conversion Guide
Thermostatic
Griddles
Follow the below steps to convert your CPG Thermostatic Griddle from Natural Gas to Liquid Propane.
These units are shipped fully equipped for use with Natural Gas. If you want to convert your unit to LP,
a different orifice is necessary. Orifice(s) for Liquid Propane are provided in a bag tied to the valve on
the front panel of the unit. The following steps will explain how to replace the burner orifice(s), pilot
orifice(s), and how to set the gas regulator to your new gas type.
Safety Precautions
CAUTION:
•
Failure to comply with the following operation instructions could lead to potential hazards and/or
unsafe practice and could result in injury and damage to product and property.
NOTICE:
•
Local codes regarding installation vary greatly from one area to another. The National Fire
Protection Association, Inc., states in its NFPA96 latest edition that Local codes are "Authority
Having Jurisdiction" when it comes to requirement for installation of equipment. Therefore,
installation should comply with all Local codes.
•
This product is intended for commercial use only. Use in residential setting will void the warranty.
WARNING:
•
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other equipment.
•
Improper installation, adjustment, alteration, service or maintenance could lead to property
damage, injury or death. Read the installation, operating and maintenance instructions thoroughly
before installing or servicing CPG equipment. This manual must be retained for future reference.
•
A licensed installer must handle all maintenance and repair.
Gas Pressure
•
The appliance and its individual shutoff valve (to be supplied by user) must be disconnected from
the gas supply piping system during any pressure testing of that system at test pressures in excess
of 1/2 PSI (3.45 kPa).
•
The appliance must be isolated from the gas supply piping system by closing its individual manual
shut-off valve during any pressure testing of the gas supply piping system at test pressures equal
to or less than 1/2 PSI (3.45 kPa).
Cooking Performance Group
.
www.cookingperformancegroup.com
Advertisement
Table of Contents
Related Manuals for CPG 351GTCPG15NL
Summary of Contents for CPG 351GTCPG15NL
- Page 1 Thermostatic Griddles Follow the below steps to convert your CPG Thermostatic Griddle from Natural Gas to Liquid Propane. These units are shipped fully equipped for use with Natural Gas. If you want to convert your unit to LP, a different orifice is necessary. Orifice(s) for Liquid Propane are provided in a bag tied to the valve on the front panel of the unit.
- Page 2 Gas Conversion Guide Replacing the Burner Orifice(s) STEP 1: STEP 2: Remove the knobs. Remove front panel. STEP 3: STEP 4: Remove the grease trap. Disconnect main pipe assembly from burner. STEP 5: STEP 6: Remove bracket containing elbow. Replace burner orifice with applicable size.
- Page 3 Reconnect main pipe assembly to burner. Repeat steps 4–8 for each individual COMPATIBLE MODELS # OF BURNERS burner on your unit. Please reference the table to the left to verify the number of 351GTCPG15NL burners your unit has. 351GTCPG24NL 351GTCPG36NL 351GTCPG48NL 351GTCPG60NL...
- Page 4 Gas Conversion Guide STEP 3: STEP 4: Remove the bottom plate. Unscrew connector ring on gas connector tube. STEP 5: STEP 6: Unscrew pilot orifice from the gas Repeat steps 4 and 5 for each inlet tube and replace pilot orifice burner.
- Page 5 Gas Conversion Guide STEP 9: STEP 10: Flip the unit back over. Slide the grease trap back into place. STEP 11: Prior to reattaching the front panel, be sure to check all fittings for leaks. Then reattach the front panel for knobs. Setting Pressure Regulator Commercial cooking equipment must have a pressure regulator on the incoming service line for safe and efficient operation, since service pressures may fluctuate on local demand.
- Page 6 Orifice Elevation Size Chart If you will be operating your CPG Griddle at an elevation above 2,000 ft please see the chart below to find the proper orifice(s) to use for most efficient use and safety when ooperating your unit.
