installation/Processing

integrated Handle
All the NEC MultiSync
®
equipped with an integrated handle to the rear of the monitor housing. This
is particularly helpful for the removal
of the display from its cardboard
packaging, for transporting the
display, and for its installation. The
possibility of (unnecessary) damage
to the LCd surface during transport and/or installation is thereby minimised. in
addition, one-handed transport of the display is possible which also allows for
more freedom of movement and manoeuvring during positioning.
Simple 4-Step installation
The MultiSync
EA series can be installed into the required space in less than
®
a minute.
1.
Open the cardboard packaging
2.
Take out the wadding material
3.
Take out the monitor using the handle integrated
in the housing
4.
Remove the Pe protective wrapping
14
EA series displays (exception: EA191M) have been
High-Quality Processing
All our displays have been constructed with an extremely high degree of work-
manship, guaranteeing a high standard of quality and a long product lifetime.
For particular protection of the display and to ensure high reliability, the inner
rear side of the display consists only of a high quality metal cover plate, without
the use of any plastics or other synthetic materials.
All load-bearing components (panel, chassis, PCB) have been fitted with metal
fastenings so as to guarantee high stability, even when stressed with larger
loads. For example, in the case where the installed display is particularly tilted
forward.
in addition, all important components have been processed with V0 flame-
retardant material, which provides particular protection against risk of fire.
Metal parts and screws hold
Cabinet
weighted parts (Panel & Chassis)
Panel
Chassis
.
Cabinet
Panel
Chassis
Screw
Screw
Metal parts and screws hold
weighted parts (Panel & Chas
