NEC MultiSync EX231W Specifications page 2

The MultiSync EX231W features a 4-way ergonomic stand with capabilities of
pivot (A), height-adjustment (up to 110mm) (B), tilt (C) and swivel (D), allowing you
to create an ideal ergonomic display orientation for maximum viewing comfort.
A
C
For simple transport of the EX231W, a quick release lever (E) allows you to quickly
and easily remove the display from the stand, while the built-in recessed handle (F)
helps avoid damage to the bezel and screen while carrying.
E
A top-mounted USB pass-through (G) allows for the easy addition of a webcam,
microphone or other peripherals. The input panel (H) includes a second USB pass-
through as well as a mini-AC adapter, and DisplayPort and DVI-I connections.
G
B
D
F
H
MultiSync and XtraView are registered trademarks and ECO Mode
and Rapid Response are trademarks of NEC Display Solutions. All
other brand or product names are trademarks or registered trade-
marks of their respective holders. Product specifications subject to
change. 10/10 ver. 1.
©
2010 NEC Display Solutions of America, Inc. All rights
reserved.
Model MultiSync EX231W
Display
Viewable Image Size 23"
Aspect Ratio 16:9
Pixel Pitch 0.265mm
Pixels Per Inch 96 @ native resolution
Brightness (typical) 250 cd/m
1000:1 (25,000:1 dynamic)
Contrast Ratio (typical)
Viewing Angle (typical) 170° Vert., 176° Hor. (85U/85D/88L/88R) (CR>5)
Response Time (typical) Rapid Response (5ms)
Display Colors More than 16.7million
Synchronization Range
31.5-83 KHz
Horizontal
Vertical 56-75Hz
Input Signal
Video Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (positive/negative)
Sync
Inputs DVI-I and DisplayPort
Resolutions Supported 720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 768 @ 60-75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60 Hz
1440 x 900 @ 60 Hz
1440 x 1050 @ 60-75 Hz
1600 x 1200 @ 60 Hz
1920 x 1080 @ 60 Hz
Native Resolution 1920 x 1080 @ 60 Hz
Additional Features Ultra-thin frame (bezel), widescreen format, USB
pass-though, ambient light sensor, human sensor,
ECO Mode, carbon footprint meter, cost meter,
integral power meter, Dynamic Video Mode, hot
key, OSD turnoff, OSD lockout, cable manage-
ment, sRGB, HDCP, AccuColor control, No Touch
Auto Adjust, DDC/CI, NaViSet software, Plug
and Play (VESA DDC 2B), VESA DPMS power
management, IPM system, off-timer, touch OSD
user control, quick release stand, EPEAT Gold,
ENERGY STAR 5.0, RoHs compliancy
AC 100-120V / AC 220-240V
Voltage Rating
Power Consumption
Typical 31W
Power Savings Mode 0.37W
ECO Mode ON 16W
Dimensions (W x H x D)
Net (with stand) 21.3 x 15.8-20.1 x 8.5 in. /
540.2 x 401.3-511.3 x 215mm
Net (without stand) 21.3 x 12.5 x 1.9 in. / 540.2 x 318.3 x 47.7mm
Weight
Net (with stand) 9.3 lbs. / 4.2 kg
Net (without stand) 6.2 lbs. / 2.8 kg
VESA Hole Configuration 100 x 100mm
Specifications
Environmental Conditions
Operating Temperature 5-35°C / 41-95°F
Operating Humidity 20-80%
Operating Altitude 2000m / 6562 ft.
-10-60°C / 14-140°F
Storage Temperature
Storage Humidity 10-85%
Storage Altitude 12,192m / 40,000 ft.
Limited Warranty 3 years parts and labor, including backlight
M - F (7am - 7pm CST)
Technical Support
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
2
