Multi-viewing Microscope
Model Number
BS-2080MH10
Instruction Manual
This instruction manual is for the microscope BS-2080MH10. To insure safety and obtain optimum
performance and familiarize yourself fully with the use of this microscope. We recommend that you
read the manual thoroughly before operating the microscope ,Attain this manual instruction in an easily
accessible place near the microscope for the further reference.
Advertisement
Table of Contents
Related Manuals for BestScope BS-2080MH10
Summary of Contents for BestScope BS-2080MH10
- Page 1 BS-2080MH10 Instruction Manual This instruction manual is for the microscope BS-2080MH10. To insure safety and obtain optimum performance and familiarize yourself fully with the use of this microscope. We recommend that you read the manual thoroughly before operating the microscope ,Attain this manual instruction in an easily...
-
Page 2: Table Of Contents
BestScope International Limited Contents BS-2080MH10 Use Notices 1. Name of Components ……………………………………………………1 2. Installation ……………………………………………………………… 2 2-1 Order of Installation …………………………………………………………… 2-2 Installation Steps ……………………………………………………………… 3. Adjustment ………………………………………………………………10 4. Operation ………………………………………………………………11 4-1 Primary Minor Operation ………………………………………………… 4-2 Adjusting Secondary Minor …………………………… ……………………... -
Page 3: Use Notices
BestScope International Limited Use Notices BS-2080MH10 I. Safety note 1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being damaged. 2. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and easy shaking environment. -
Page 4: Name Of Components
BestScope International Limited 1. Name of Components BS-2080MH10 Secondary Minor Binocular Viewing Device Video Port Secondary Minor Binocular Viewing Device Primary Minor Trinocular Viewing Unit Left Secondary Minor Column support Left Image Rotation Connecting Tube Right Image Rotation Connecting Tube... -
Page 5: Installation
BestScope International Limited 2. Installation BS-2080MH10 Order of Installation Four Eyepieces Video Port (optional) Tow Eyepieces Four Eyepieces ⑩ Tow Binocular Trinocular Viewing Unit Tow Binocular ⑩ Viewing Device Viewing Device ⑩ ⑩ Left Image Rotation LED Pointer Image Rotation Set ⑧... -
Page 6: Installation Steps
BestScope International Limited BS-2080MH10 2-2 Installing steps Installation Body’s chassis 2-2-1 1. Installing the Mechanical Stage Support Device Before installing the device, be sure to adjust Guide Board the coarse focus knob. Make the guide board (see figure 1) down to the lowest position, so you can install the mechanical stage support device easily. - Page 7 BestScope International Limited BS-2080MH10 2 Installing the Lamp House Keep the bolt on the lamp house (figure 4) in line with the jack on the back of the microscope (like the show of figure 5), then pushing the lamp...
- Page 8 BestScope International Limited BS-2080MH10 4 Installing the Objective 1. Adjusting the coarse focus knob until the support device of the mechanical stage reach its low limit position. 2. Wresting the lowest magnification objective Figure 7 onto the nosepiece from the left or the right...
- Page 9 BestScope International Limited BS-2080MH10 2-2-2Connecting Teaching Image Rotation Set ☆ Spinning the left/right Image Rotation Connecting Fitting (figure9,figure11) into corresponding port of LED pointer Image Rotation Set(figure10), and make sure the coincidence of label show in A-2,B-2. The result is...
- Page 10 BestScope International Limited BS-2080MH10 2-2-4 Stack Mounting Teaching Set 1. Stack Mounting Teaching Image Rotation Set Please loosen bolt microscope head and insert the Teaching Image Rotation (figure16) into Microscope head installed (figure17) , turn to a proper position, then use the hexagon wrench screw down the bolt to fix.
- Page 11 BestScope International Limited BS-2080MH10 2-2-5 Installing Binocular/Trinocular viewing Device 1. Please ease the bolt on the head of left/right Teaching Image Rotation Set (figure20) installed, insert Trinoclular viewing unit into Figure 20 Trinoclular Viewing Unit the head of the left/right Teaching Image Rotation Set (figure16), turn 图...
- Page 12 BestScope International Limited BS-2080MH10 3. Pull out the lid of eyepiece on the Eyepiece eyepiece tube, insert eyepiece into eyepiece tube, until they are against each other. The result is showing in the figure 27, 29. Figure 24 Figure 25 4.
-
Page 13: Adjustment
BestScope International Limited 3.Adjustment BS-2080MH10 Interpupillar Distance Indicator Diopter Ring Diopter Ring Video Port (optional) Diopter Ring Light Path Selector Lever Pointer Rocket Interpupillar Distance Right Coarse Indicator Turn to B Focus Knob Interpupillar Distance Indicator Main Switch Pointer Knob... -
Page 14: Operation
BestScope International Limited 4. Operation BS-2080MH10 4-1 Primary Minor operation 4-1-1 Turning on the Lamp (Figure 30) Connect the power, turn on the main switch (figure 30) to “-”(on). 4-1-2 Adjust Brightness (Figure 31) Turning the brightness adjustment knob Main switch... - Page 15 BestScope International Limited BS-2080MH10 4-1-4 Placing Specimen(figure 33) Place the slide on the mechanical stage. Use the stage clips to clamp the slide gently. Turn the portrait and lateral adjustment knob of the mechanical ruler, move the specimen onto the required position.
- Page 16 BestScope International Limited BS-2080MH10 4-1-7 Focus (figure21, figure22) 1. When not using the video set Push in the light path selector lever (figure 25) completely, then observe with both eyes. Use the 10×objective focus, to avoid the objective touch with...
- Page 17 BestScope International Limited 1. Using the Swing out Condenser When using the low magnification objective, turn out the condenser, and let it away from the light path. While using the high magnification objective, turn it into the light path. 2. Adjusting the Aperture Diaphragm The aperture diaphragm is designed for the adjustment of the numerical aperture, not for the brightness.
- Page 18 BestScope International Limited BS-2080MH10 4-1-9 Adjusting the Field Diaphragm (Figure 39) The control for the field diaphragm is a ring used for adjusting the area of field diaphragm. When using, turn the ring to reduce the field diaphragm, look into the...
-
Page 19: Adjusting Secondary Minor
BestScope International Limited BS-2080MH10 4-2 Adjusting Secondary Minor 4-2-1AdjustingInterpupillar Distance After adjusting the Primary Minor, observing the Secondary Minor Set, it will be a sharp image simultaneously. When observing with two eyes, hold on the left/right prism bolder, turn around... -
Page 20: Technical Specifications
BestScope International Limited 5．Technical Specifications BS-2080MH10 1. Main specifications Optical System Infinite Optical System Compensation Free Trinocular Head, Inclined at 30, Interpupillar distance: 48-75mm Viewing Head Compensation free binocular Head, Inclined at 30, Interpupillar distance:48-75mm Eyepiece (Ocular) Exceed wide field ocular EW10X/22, tubeΦ30 matched... -
Page 21: Trouble Shooting
BestScope International Limited 6．Trouble shooting BS-2080MH10 Some problems will happen in the using of the microscope, you could solve them according the following list Problems Reason for problem Solution I. Optical Part: The poor contact exists in the lamp Ensure the contact pin and the lamp house and the illumination system. - Page 22 BestScope International Limited The nosepiece is not in the located Turn the nosepiece in the required position position The interpupillar distance is not Adjust the interpupillar distance 6. The eyes are correct correctly uncomfortable, the left and right fields of view is not...
- Page 23 BestScope International Limited BS-2080MH10 PROBLEM REASON FOR PROBLEM SOLUTION II. Mechanical Part: 1. The coarse focus The tension adjustment collar is too Loose properly knob is hard to run tight 2. The image can’t stay on the focal plane in the...
