- Page 1 Quick Guide SMic133D DIGIMIC Multimedia unit Article no.: 05.1925/05.1925.CH SMic133D...
- Page 2 SMic133D DIGIMIC Quick Guide Introduction and connections With the SMic series of the DIGMIC family, you have your conference subjects optimally supplied with multimedia. The SMic133D has a microphone, headphone jack, speaker, language selector, tuning function, identification and provides access to session-relevant information. The SMic is operated via a touchscreen display in combination with the BrählerOS software.
- Page 3 SMic133D DIGIMIC Quick Guide Example system image Headphones You can listen to the audio signal in two ways - via the integrated speaker or via headphones. Connect the headphones and adjust the volume. To do this, tap the volume control on your screen (left image). A volume control opens (right image).
- Page 4 SMic133D DIGIMIC Quick Guide Microphone Plug in the microphone. Note the notch on the microphone plug and the Minicon jack. Screw the microphone tight to lock it in place. Minicon socket Microphone Press the microphone key to switch the microphone on. Press the microphone key again to switch the microphone off.
- Page 5 SMic133D DIGIMIC Quick Guide Alternatively, set the language selector via the OLED display. Press the CH +/- function key to set the desired language. The SMic133D automatically detects which channels are occupied. Unoccupied channels are skipped during the dialing process. Example: Channels 5 and 10 are occupied in addition to the original channel.
- Page 6 SMic133D DIGIMIC Quick Guide Multimedia functions Home Button The home button will always take you back to the home page. Agenda Tap on "Agenda". An overview of all agenda items appears on your screen. Scroll up and down the agenda with your finger.
- Page 7 SMic133D DIGIMIC Quick Guide Streaming It is possible to receive video streams with the SMic133. These must be fed in by the operator of the conference. The following icon appears in the bottom bar of the screen: Click the icon to see the stream. To close open documents and images click the X in the upper right corner.
- Page 8 SMic133D DIGIMIC Quick Guide Alternatively, you can perform tuning via the OLED display and its corresponding control keys. Press the function keys to perform the tuning. Depending on the setting, the representation on the display changes. Here are some examples: Display of all 5 keys and thus voting on five points (questions): Representation with digits selected...
- Page 9 SMic133D DIGIMIC Quick Guide RFID card reader The SMic is equipped with an RFID card reader. By means of RFID card all conference topics can be registered and identified. RFID card reader Your data is stored on your personal card for a specific purpose. Insert your RFID card into the RFID card reader.
- Page 10 SMic133D DIGIMIC Quick Guide You can find more information about our products on the Internet at: www.braehler-systems.com © 2022 Copyright by BRÄHLER Systems GmbH, Königswinter All rights reserved, in particular (also in extracts) those of translation, reprinting, reproduction by copying or similar processes.
