Summary of Contents for BOMBARDIER OUTLANDER 330 H.O. 2x4

  • Page 2 In USA, products are distributed by Bombardier Motor Corporation of America. In Canada, products are distributed by Bombardier Inc. The following are trademarks of Bombardier Inc. or its subsidiaries: BOMBARDIER ®...
  • Page 3 Bombardier ® all-terrain vehicle system descriptions contained in this (ATV). It is backed by the Bombardier document are correct at the time of warranty and a network of authorized publication. Bombardier Inc. however, Bombardier ATV dealers ready to pro-...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious injury or death. NOTICE..................INTRODUCTION................SAFETY INFORMATION SPECIAL SAFETY MESSAGES............ OPERATION WARNINGS ............10 SAFETY WARNING ..............37 RIDING TIPS ................
  • Page 5 5) Transmission Lever................6) Multi-Function Switch ............... 7) Speedometer ..................8) Ignition Switch .................. 9) Fuel Tank Cap ................... 10) Fuel Gauge..................11) Fuel Valve..................12) Brake Pedal ..................13) Footpeg..................... 14) Access Panel..................15) Rear Storage Compartment .............. 16) Seat Latch ..................17) Front/Rear Cargo Rack................
  • Page 6 Steering/Control Systems................ 100 Suspension ....................102 Brake ....................... 103 Body/Frame ..................... 103 TROUBLESHOOTING ..............105 SPECIFICATIONS................ 108 SI METRIC INFORMATION GUIDE..........116 WARRANTY BOMBARDIER LIMITED WARRANTY NORTH AMERICA: ® 2004 BOMBARDIER ATV............118 BOMBARDIER INTERNATIONAL LIMITED WARRANTY: 2004 BOMBARDIER ® ATV............121 FREQUENTLY ASKED QUESTIONS ..........

  • Page 7: Notice

    NOTICE This Operator’s Guide has been pre- pared to acquaint the owner/operator of a new vehicle with the various vehi- cle controls, maintenance and safe op- erating instructions. It is indispensable for the proper use of the product. This Operator’s Guide uses the follow- ing symbols.

  • Page 8: Introduction

    INTRODUCTION Your selling dealer should have provided you with some basic information on the particular controls and features of your new ATV. Please take the time to study this Operator’s Guide and all on-product warning labels that came with the ATV. It more completely describes what you should know about the ATV before riding it.

  • Page 9: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION...

  • Page 10: Special Safety Messages

    SPECIAL SAFETY MESSAGES AN ATV IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE. An ATV handles differently from other vehicles including motorcycles and cars. A collision or rollover can occur quickly, even during routine maneuvers such as turning and driving on hills or over obstacles, if you fail to take proper precautions. SEVERE INJURY OR DEATH can result if you do not follow these instructions: Read this Operator’s Guide and all on-product warning labels carefully and fol- low the operating procedures described.
  • Page 11 Always follow proper procedures for climbing hills as described further in this Operator’s Guide. Check the terrain carefully before you start up any hill. Never climb hills with excessively slippery or loose surfaces. Shift your weight forward. Never open the throttle suddenly or make sudden gear changes. Never go over the top of any hill at high speed.

  • Page 12: Operation Warnings

    HOW TO AVOID THE HAZARD Beginning and inexperienced operators should complete the certified training course offered by Bombardier Inc. They should then regularly practice the skills learned in the course and the operating techniques de- scribed further in this Operator’s Guide.
  • Page 13 ATV safely and may be involved in a serious acci- dent. HOW TO AVOID THE HAZARD No one under 16 should operate a Bombardier ATV. SAFETY INFORMATION...
  • Page 14 WARNING V00A02Q POTENTIAL HAZARD Carrying a passenger on this ATV. WHAT CAN HAPPEN Greatly reduces your ability to balance and control this ATV. Could cause an accident, resulting in harm to you and/or your passenger. HOW TO AVOID THE HAZARD Never carry a passenger.
  • Page 15 WARNING V00A03Q POTENTIAL HAZARD Operating this ATV on paved surfaces. WHAT CAN HAPPEN The ATV’s tires are designed for off-road use only, not for use on pave- ment. Paved surfaces may seriously affect handling and control of the ATV, and may cause the vehicle to go out of control. HOW TO AVOID THE HAZARD Never operate the ATV on any paved surfaces, including sidewalks, drive- ways, parking lots and streets.
  • Page 16 WARNING V00A04Q POTENTIAL HAZARD Operating this ATV on public streets, roads or highways. WHAT CAN HAPPEN You can collide with another vehicle. HOW TO AVOID THE HAZARD Never operate this ATV on any public street, road or highway, even a dirt or gravel one.
  • Page 17 WARNING V00A06Q POTENTIAL HAZARD Operating this ATV without wearing an approved helmet, eye protection and protective clothing. WHAT CAN HAPPEN Operating without an approved helmet increases your chances of a severe head injury or death in the event of an accident. Operating without eye protection can result in an accident and increases your chances of a severe injury in the event of an accident.
  • Page 18 WARNING V00A07Q POTENTIAL HAZARD Operating this ATV after consuming alcohol or drugs. WHAT CAN HAPPEN Could seriously affect your judgment. Could cause you to react more slowly. Could affect your balance and perception. Could result in an accident. HOW TO AVOID THE HAZARD Never consume alcohol or drugs before or while driving this ATV.
  • Page 19 WARNING V00A08Q POTENTIAL HAZARD Operating this ATV at excessive speeds. WHAT CAN HAPPEN Increases your chances of losing control of the ATV, which can result in an accident. HOW TO AVOID THE HAZARD Always travel at a speed which is proper for the terrain, visibility and op- erating conditions, and your experience.
  • Page 20 WARNING V00A09Q POTENTIAL HAZARD Attempting wheelies, jumps and other stunts. WHAT CAN HAPPEN Increases the chance of an accident, including an overturn. HOW TO AVOID THE HAZARD Never attempt stunts, such as wheelies or jumps. Do not try to show off. SAFETY INFORMATION...
  • Page 21 WARNING POTENTIAL HAZARD Failure to inspect the ATV before operating. Failure to properly maintain the ATV. WHAT CAN HAPPEN Increases the possibility of an accident or equipment damage. HOW TO AVOID THE HAZARD Always inspect your ATV each time you use it to make sure the ATV is in safe operating condition.
  • Page 22 WARNING V00A0BQ POTENTIAL HAZARD Removing hands from handlebars or feet from footrests during operation. WHAT CAN HAPPEN Removing even one hand or foot can reduce your ability to control the ATV or could cause you to lose your balance and fall off the ATV. If you remove a foot from the footrests, your foot or leg may come into contact with the rear wheels, which could injure you or cause an accident.
  • Page 23 WARNING V00A0CQ POTENTIAL HAZARD Failure to use extra care when operating this ATV on unfamiliar terrain. WHAT CAN HAPPEN You can come upon hidden rocks, bumps, or holes, without enough time to react. Could result in the ATV overturning or going out of control. HOW TO AVOID THE HAZARD Go slowly and be extra careful when operating on unfamiliar terrain.
  • Page 24 WARNING V00A0DQ POTENTIAL HAZARD Failure to use extra care when operating on excessively rough, slippery or loose terrain. WHAT CAN HAPPEN Could cause loss of traction or vehicle control, which could result in an accident, including an overturn. HOW TO AVOID THE HAZARD Do not operate on excessively rough, slippery or loose terrain until you have learned and practiced the skills necessary to control the ATV on such terrain.
  • Page 25 WARNING V00A0EQ POTENTIAL HAZARD Turning improperly. WHAT CAN HAPPEN ATV could go out of control, causing a collision or overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for turning as described further in this Operator’s Guide. Practice turning at low speeds before attempting to turn at faster speeds.
  • Page 26 WARNING V00A0QQ POTENTIAL HAZARD Operating on excessively steep hills. WHAT CAN HAPPEN The vehicle can overturn more easily on extremely steep hills than on level surfaces or small hills. HOW TO AVOID THE HAZARD Never operate the ATV on hills too steep for the ATV or for your abilities. Practice on smaller hills before attempting larger hills.
  • Page 27 WARNING V00A0FQ POTENTIAL HAZARD Climbing hills improperly. WHAT CAN HAPPEN Could cause loss of control or cause ATV to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for climbing hills as described further in this Operator’s Guide. Always check the terrain carefully before you start up any hill. Never climb hills with excessively slippery or loose surfaces.
  • Page 28 WARNING V00A0GQ POTENTIAL HAZARD Going down a hill improperly. WHAT CAN HAPPEN Could cause loss of control or cause ATV to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for going down hills as described fur- ther in this Operator’s Guide. NOTE: A special technique is required when braking as you go down a hill.
  • Page 29 WARNING V00A0HQ POTENTIAL HAZARD Improperly crossing hills or turning on hills. WHAT CAN HAPPEN Could cause loss of control or cause ATV to overturn. HOW TO AVOID THE HAZARD Never attempt to turn the ATV around on any hill until you have mastered the turning technique as described further in this Operator’s Guide on level ground.
  • Page 30 WARNING V00A0IQ POTENTIAL HAZARD Stalling, rolling backwards or improperly dismounting while climbing a hill. WHAT CAN HAPPEN Could result in ATV overturning. HOW TO AVOID THE HAZARD Use proper gear and maintain steady speed when climbing a hill. If you lose all forward speed: Keep weight uphill.
  • Page 31 WARNING V00A0JQ POTENTIAL HAZARD Improperly operating over obstacles. WHAT CAN HAPPEN Could cause loss of control or a collision. Could cause the ATV to overturn. HOW TO AVOID THE HAZARD Before operating in a new area, check for obstacles. Never attempt to ride over large obstacles, such as large rocks or fallen trees.
  • Page 32 WARNING POTENTIAL HAZARD Skidding or sliding improperly. WHAT CAN HAPPEN You may lose control of this ATV. You may also regain traction unexpectedly, which may cause the ATV to overturn. HOW TO AVOID THE HAZARD Learn to safely control skidding or sliding by practicing at low speeds and on level, smooth terrain.
  • Page 33 WARNING V00A0LQ POTENTIAL HAZARD Operating this ATV through deep or fast flowing water. WHAT CAN HAPPEN Tires may float, causing loss of traction and loss of control, which could lead to an accident. HOW TO AVOID THE HAZARD Never operate this ATV in fast flowing water or in water deeper than that specified further in this Operator’s Guide.
  • Page 34 WARNING POTENTIAL HAZARD Improperly operating in reverse. WHAT CAN HAPPEN You could hit an obstacle or person behind you, resulting in serious injury. HOW TO AVOID THE HAZARD When you select reverse gear, make sure there are no obstacles or people behind you.
  • Page 35 WARNING POTENTIAL HAZARD Operating this ATV with improper tires, or with improper or uneven tire pressure. WHAT CAN HAPPEN Use of improper tires on this ATV, or operation of this ATV with improper or uneven tire pressure, may cause loss of control, and increases the risk of an accident.
  • Page 36 Never modify this ATV through improper installation or use of accesso- ries. All parts and accessories added to this vehicle should be genuine Bombardier or equivalent components designed for use on this ATV and should be installed and used according to instructions. If you have ques- tions, consult an authorized Bombardier ATV dealer.
  • Page 37 WARNING V00A0PQ POTENTIAL HAZARD Overloading this ATV or carrying or towing cargo improperly. WHAT CAN HAPPEN Could cause changes in vehicle handling which could lead to an accident. HOW TO AVOID THE HAZARD Never exceed the stated load capacity for this ATV. Cargo should be properly distributed and securely attached.
  • Page 38 WARNING V03M01Q POTENTIAL HAZARD Transporting inflammable or dangerous material can lead to explosions. WHAT CAN HAPPEN This can cause serious injury or death. HOW TO AVOID THE HAZARD Never transport inflammable or dangerous material. While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious injury or death.

  • Page 39: Safety Warning

    SAFETY WARNING To fully appreciate the pleasures and excitement of riding an ATV, there are some basic rules and tips that you should follow. Some may be new to you while others may be common sense or obvious. However, we ask that you take a few minutes to read this Operator’s Guide completely before you operate the ATV.

  • Page 40: Riding Tips

    RIDING TIPS While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that could result in serious injury or death. WARNING The pre-operation check is very important prior to operating the vehicle. Always check the proper operation of critical controls, safety features and mechanical components before starting.

  • Page 41: Clothing

    Clothing Actual weather conditions should help you decide how to dress. However, it is important that you always wear the appropriate protective clothing and apparel, including an approved helmet, eye protection, boots, gloves, long sleeved shirt and pants. Never wear loose clothing such as a scarf that may get entangled in the ATV or on tree shrubs and branches.

  • Page 42: Carrying Loads

    Carrying Loads Any load carried on the ATV’s carrying rack(s) will affect the stability and control of the ATV. For this reason, do not exceed the load limits of the ATV manufacturer. Always make sure the load is secured and cannot interfere with your proper con- trol.

  • Page 43: Environment

    Always keep a safe distance from other riders. Your judgment of speed, terrain conditions, weather, mechanical condition of your ATV and the “trust in judg- ment” you have in others around you will help you make a better choice of ap- propriate safe distance.

  • Page 44: General Operating And Safety Precautions

    An operator who takes a vehicle off-road should always exercise the utmost care in selecting the safest path and keeping close watch on the terrain ahead of him. On no account should the vehicle be operated by anyone who is not completely familiar with the driving instructions applicable to the vehicle, or should it be op- erated on steep or treacherous terrain.

  • Page 45: Drop-Offs

    Drop-Offs An ATV will “bottom-out” and usually stop if either the front or rear wheels are driven over a drop-off. If the drop is sharp or deep, the vehicle will nose dive and tip-over. WARNING Avoid negotiating drop-offs. Reverse and select an alternate route. Riding Techniques Riding your ATV too fast for the conditions may result in injury.
  • Page 46 Even though there is an adequate suspension system on an ATV there are “wash- board” or rough terrain conditions that will make you feel uncomfortable and even cause back injury. “Posting” or riding in a crouched position will often be required. Slow down and allow your flexed legs to absorb impact.
  • Page 47 If your trip crosses frozen waterways, make sure the ice is thick enough to sup- port the total weight of yourself, the ATV and its load. Be ever watchful of open ice… it is a sure indication that the thickness of the ice varies. If in doubt, do not attempt to cross.
  • Page 48 If you do get into a slide or skid, it may help to turn the handlebar into the direction of the skid until you regain control. Never jam the brakes and lock the wheels. Respect and follow all posted trail signs. They are there to help you and others. Obstacles on the trail should be crossed with caution.
  • Page 49 Uphill Keep your body weight forward towards the top of the hill. Keep your feet on the footrests and shift into low gear then accelerate and when necessary, change gear quickly as you climb. Do not over-speed since this may cause the front of the ATV to lift from the ground and fall back on you.
  • Page 50 Downhill Keep your body weight rearwards. Apply the brake gradually to prevent skidding. Do not “coast” down the slope using solely engine compression or in neutral gear. V00A0YL SAFETY INFORMATION...
  • Page 51 Side-Hilling This is one of the most risky types of riding since it may drastically change the balance of the ATV. It should be avoided wherever possible. If it is necessary to do so however, it is important that you ALWAYS keep your body weight on the upside of the slope…...
  • Page 52 Part of your responsibility towards safety is to respect the contents of this Oper- ator’s Guide. It provides valuable advise on how to properly take care of your ATV. If further assistance is required your authorized Bombardier ATV dealer is always willing to help.

  • Page 53: Location Of The Important Labels

    LOCATION OF THE IMPORTANT LABELS The following labels are on your ATV. If missing or damaged, they can be replaced free of charge. See an authorized Bombardier ATV dealer. V07A03L SAFETY INFORMATION...
  • Page 54 V07A06L SAFETY INFORMATION...
  • Page 55 Label 1 Label 4 V07M07Y 4 MODELS Label 5 V01M01Z V07M05Y Label 2 Label 6 V01M06Z V01M02Z Label 7 Label 3 V01M07Z V07M06Y SAFETY INFORMATION...
  • Page 56 Label 8 Label 9 V07M04Y Label 10 V07M02Y V07M03Y Label 11 V07M08L SAFETY INFORMATION...

  • Page 57: Vehicle Information

    VEHICLE INFORMATION...

  • Page 58: How To Identify Your Atv

    These numbers are required by the authorized Bombardier ATV dealer to complete war- ranty claims properly. No warranty will be allowed by Bombardier Inc. if the engine identification number (EIN) or vehicle identification number (VIN) is removed or mutilated in any way.

  • Page 59: Emission Requirements

    EMISSION REQUIREMENTS The California Air Resources Board (CARB) requires that your ATV complies with applicable exhaust emissions standards during its useful life, when operated and maintained according to the instructions supplied. A non-compliance Red Label (as well as a Green Label) is obtained annually during California Vehicle registration.

  • Page 60: Controls/Instruments/Equipments

    CONTROLS/INSTRUMENTS/EQUIPMENTS NOTE: Some controls/instruments/equipments are optional. 14 3 V07A06N...
  • Page 61 25, 27 25, 27 V07A09M...

  • Page 62: Throttle Lever

    While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious injury or death. NOTE: This section gives basic func- tions of the various controls of your ATV. For more details of how to oper- ate one control in conjunction with some others, refer to OPERATING IN- STRUCTIONS further in this section.

  • Page 63: Brake Lever

    3) Brake Lever WARNING Located on the left side of handlebar. Make sure brake lever lock is fully When the brake lever is compressed, disengaged before operating the the front and rear brakes are applied. ATV. When released, the brake lever should automatically return to its original posi- When you ride the vehicle, brakes tion.
  • Page 64 5) Transmission Lever P: Park This position locks the transmission to Located on the right side of vehicle. A help prevent vehicle movement. Al- 5-position lever: P, R, N, H and L. ways use when the vehicle is not in operation.
  • Page 65 6) Multi-Function Switch NOTE: Place ignition switch to ON “without light” position to close the The multi-function switch is located on headlamp. the left side of handlebar. V07I11Y V07I02Y 1. Multi-function switch ON POSITION “WITHOUT LIGHT” The controls located on this multi- Engine Stop Switch function switch are: Located at the middle of multi-function...
  • Page 66 To stop engine, fully release throttle le- This button is used to override the re- ver then use the engine stop switch. verse speed limiter system and while power backing up. To do this, press the Start Button override button. Located above engine stop switch.
  • Page 67 The full choke position is used for lower engine temperature. V07I0AY V07I09Y 1. Display selector button CHOKE LEVER IN THE FULL CHOKE POSITION 2. Display 3. 4WD indicator lamp (4 x 4 models) The other positions between OFF and 4. Oil pressure indicator lamp 5.
  • Page 68 Depressing display selector button again will change display for the hour- meter. Push display selector button again to return to odometer. Odometer Odometer records the total distance travelled either in miles or kilometers. Trip Meter The trip meter records distance travel- led since it has been reset.
  • Page 69 Check engine oil level. Refill if necessary. If the oil level is good, see an au- thorized Bombardier ATV deal- er. Do not use the vehicle until V07I0CY repaired. 1. Ignition switch...
  • Page 70 10) Fuel Gauge WARNING Located on the left side of the rear fender Always stop engine before refuel- near fuel tank cap, the gauge shows an ing. Open cap slowly. If a differen- approximate amount of the fuel in tank. tial pressure condition is noticed (whistling sound heard when loosening fuel tank cap) have ve-...
  • Page 71 11) Fuel Valve When down to the reserve, refuel as soon as possible. Ensure to turn the Located on left side panel under con- valve back to the ON position after re- sole. 3-position rotary valve: OFF, ON, fuelling. RES. Rotate the knob to align its pointer CAUTION: Improper opening of fuel with ON, OFF or RES.
  • Page 72 13) Footpeg Located on footrest. Use this area to maintain your feet stable. V07A0AY 1. Rear brake fluid reservoir 2. Radiator cap 3. Coolant reservoir 4. Tool box 15) Rear Storage V07L01Y Compartment 1. Footpeg Located in rear of vehicle. Convenient 14) Access Panel location to carry personal articles such as a spare spark plugs, first aid kit, etc.
  • Page 73 Seat Installation WARNING Insert front tabs of seat into frame When engine is running, always hook. When seat rests in its position, engage the PARK position on the firmly push seat down to latch. transmission lever before open- ing cover. Never leave any heavy or loose breakable objects in the storage basket.
  • Page 74 18) Trailer Hitch Located near rear axle. Convenient hitch to install a ball to tow a trailer or other equipment. Install the proper ball size as per trailer manufacturer recom- mendations. Refer to SPECIFICA- TIONS for carrying loads and towing recommendations.
  • Page 75 The fuse holders are located in the ser- Follow the usual starting procedure; vice compartment (behind tool box). but use the rewind starter instead of the electric starter. Located on right side of vehicle. Auto- rewind type. To engage mechanism, pull handle slowly until a resistance is felt then continue to slowly pull the handle until the compression stroke...
  • Page 76 25) Winch 27) Fairlead XT Models XT Models Located behind front skid plate. Located on the front of skid plate. The fairlead is used to prevent the damages to the vehicle and guide the wire rope into the winch. V07A0PY 1.
  • Page 77 SG, SH or SJ. Only use high- quality high-detergent oil. NOTE: The same oil lubricates both engine and transmission. For improved overall performance and wear protec- tion use Bombardier synthetic oil 5W40 (P/N 293 600 039).
  • Page 78 Oil Viscosity SAE 5W30 is recommended for all seasons. However, during the hottest days of the summer and bitter cold days of the winter, refer to the following chart to select the proper viscosity. °C °F V01A38L...
  • Page 79 3. Remove and check oil level. It should Cooling system must be filled with wa- be near or equal to the upper mark. ter and antifreeze solution (50% water, 50% antifreeze) or with Bombardier premixed coolant (P/N 293 600 038). Coolant Level WARNING Check coolant level with engine cold.
  • Page 80 NOTE: A cooling system that frequent- ly requires coolant is the indication of leaks or engine problems. See an au- thorized Bombardier ATV dealer. Coolant Replacement Refer to MAINTENANCE section. V07I02Z...
  • Page 81 Brake Pedal Fluid Reservoir V07G03Y 1. Battery 2. Holding strap Installation V07A0CY Reinstall battery in vehicle. Battery WARNING This vehicle is equipped with a dry Connect RED (+) cable first then type battery that requires no mainte- BLACK (-) cable. Always connect nance.
  • Page 82 Bombardier ATV dealer. This in- Continued wide open throttle acceler- spection will give you the opportunity ations, prolonged cruising speeds and...
  • Page 83 PARK position. Correct any problem you may have • Check fuel, oil and coolant levels. found. See an authorized Bombardier • Check for oil leaks on the engine/ ATV dealer as necessary. transmission and drive train compo-...
  • Page 84 OPERATING INSTRUCTIONS General Press the start button and hold until the engine starts. The transmission lever must be on CAUTION: Do not hold the start but- PARK or NEUTRAL to allow engine to ton more than 30 seconds. A rest pe- start.
  • Page 85 Warm Engine Starting Start the engine as explained above but without the choke. If the engine does not start after two 5-second at- tempts with the electric starter, pull the choke lever and place it between the ON and the OFF position. Start the engine without activating the throttle lever.
  • Page 86 CAUTION: Make sure parking brake is fully disengaged before operating the ATV. Gradually press the throttle lever to in- crease engine speed and thus engag- ing the continuously variable transmis- sion (CVT). At the opposite, when the throttle le- ver is released, the engine speed de- creases.
  • Page 87 If it does not work: engine is hot. Clean the spark plug cap area then re- move it. Remove the spark plug (tools See an authorized Bombardier ATV deal- are supplied in tool box). er as soon as possible. WARNING...
  • Page 88 If the oil pressure light stays ON after starting engine, stop engine and see an authorized Bombardier ATV dealer as soon as possible. ATV Immersion Should the ATV become immersed, it...
  • Page 89 CARGO AND TRANSPORTATION While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious injury or death. Cargo WARNING The vehicle handling, stability and braking distance are affected when loading racks and using the vehicle. Correct loading and weight distribu- tion are therefore important.
  • Page 90 Transportation Front Location When transporting a vehicle, secure vehicle to trailer or in pickup box with suitable tie-downs. Using ordinary ropes is not recommended. WARNING V07A0EY Rear Location V00A174 Never tip this vehicle on end for transporting. We recommend that you carry the vehicle in its normal operating position (on all four wheels).
  • Page 91 MAINTENANCE INFORMATION...
  • Page 92 MAINTENANCE CHART The maintenance is very important, if you are not familiar with safe service prac- tices and adjustment procedures, see your authorized Bombardier ATV dealer. EVERY LUBRICATION AND MAINTENANCE CHART I: Inspect, verify, clean, adjust, lubricate, replace if necessary...
  • Page 93 Vehicle cleaning and protection CUSTOMER ➀ To be performed by an authorized Bombardier ATV dealer. The initial maintenance is very important and must not be neglected. ➁ Every 100 hours, check coolant strength. ➂ More often under severe use such dusty area, sand, snow, wet or muddy conditions.
  • Page 94 The following covers the maintenance items that can be performed by the cus- tomer if desired. Other items found in maintenance chart must be performed by an authorized Bombardier ATV dealer. NOTE: Among other things, this sec- V07C03Y tion gives the procedures to replace the liquids.
  • Page 95 Oil Strainer Cleaning V07C06Y The oil strainer must be cleaned every 200 hours or every 2 years or every 1. Coolant drain plug 6000 km (3730 m.). NOTE: Do not unscrew the coolant Contact an authorized Bombardier ATV drain plug completely. dealer.
  • Page 96 30 mm (1-3/16 in), or if flat stall the coolant drain plug. spots, cracks or other damages are vis- ible, see an authorized Bombardier Pinch hose between radiator and ther- ATV dealer to replace the drive belt. mostat housing with a large hose pincher (P/N 529 032 500).
  • Page 97 SURE ONLY, NEVER USE A HIGH out of the muffler. PRESSURE WASHER. Stop engine and allow muffler to cool. See an authorized Bombardier dealer Reinstall the clean-out plug. to check the performance of the cool- ing system.
  • Page 98 Carburetor Remove air filter as explained below. See an authorized Bombardier ATV Air Filter Removal dealer each year to verify and clean the CAUTION: Never remove or modify fuel system. any component in the air box. Oth- erwise, engine performance degra- Air Intake System dation or damage can occur.
  • Page 99 Pour cleaning solution (P/N 293 600 059 or an equivalent) into a bucket. Put the filter in to soak. While filter soaks, clean inside the air box. Rinse the filter with warm water until all cleaning solution disappears. Then, let the filter dry completely. When the filter is dried, re-oil with air fil- ter oil (P/N 293 600 058 or an equiva- lent).
  • Page 100 Unplug connector from headlamp. V04G02Z V04G02Y 1. Headlamp cover Rotate the bulb socket counterclock- 2. Beam height adjustment 3. Beam side adjustment wise then remove headlamp. Taillight Unscrew lens screws to expose bulb. V04G03Y 1. Unlock V07G04Y 2. Lock 1. Lens Properly reinstall removed parts in the 2.
  • Page 101 Wheel Bearing Condition Push and pull the wheels from the up- per edge to feel the play. See an autho- rized Bombardier ATV dealer if there is any play. V07H01Y 4 x 4 MODELS — FRONT OF VEHICLE 1. Drive shaft protector 2.
  • Page 102 For your convenience, a pressure gauge CAUTION: Always use the recom- is supplied in tool box. mended wheel nuts (P/N 250 100 039). Using a different nut could cause TIRE PRESSURE damages to the rim. FRONT REAR Steering/Control Systems RECOMMENDED 28 kPa 31 kPa Throttle Cable Lubrication...
  • Page 103 V07I0GY 1. Cable protector 2. Throttle cable adjuster V07I0IY 3. Lock nut 4. Throttle lever housing Remove the carburetor side cover. Screw in the throttle cable adjuster. Remove: – inner housing protector V07F04Y Insert the needle of lubricant can in the end of throttle cable adjuster.
  • Page 104 Bombardier ATV dealer as necessary. Rear Suspension Inspect shock absorber for oil leaks and fasteners for tightness. See an autho- rized Bombardier ATV dealer as neces- sary. Trailing arms Check trailing arms for distortion, cracks or bending. See an authorized Bombardier ATV dealer if any problem is detected.
  • Page 105 Check A-arms for cracks, bending or Front and Rear Brakes other damages. See an authorized The front and rear brakes are hydraulic Bombardier ATV dealer as necessary. disc types. These brakes are self- adjusting and require no adjustment. Adjustment The brake lever and the brake pedal re- Rear Shocks quire no adjustment.
  • Page 106 Retighten as required. Seat Fasteners Remove seat and check latch mecha- nism and pin for wear. See an autho- rized Bombardier ATV dealer for parts replacement if damaged. Vehicle Cleaning and Protection Never use the high pressure washer to clean the vehicle USE LOW PRES- SURE ONLY (like a garden hose).
  • Page 107 4. Weak battery or loose connec- Check charging system fuse. Check connections tions. and terminals condition. Have the battery checked. Contact an authorized Bombardier ATV dealer. SYMPTOM: Engine turns over but fails to start POSSIBLE CAUSES WHAT TO DO 1. Burnt fuse.
  • Page 108 2. Lack of fuel to engine. Check item ENGINE TURNS OVER BUT FAILS TO START. 3. Carburetor adjustments. Contact an authorized Bombardier ATV dealer. 4. Engine is overheating. Check ENGINE OVERHEAT in SPECIAL PROCE- DURES. If overheating persists, contact an autho- rized Bombardier ATV dealer.
  • Page 109 2. Engine idle speed is set too high. Adjust the idle speed. Refer to the SPECIFICATION. 3. CVT dirty or wear. Contact an authorized Bombardier ATV dealer. SYMPTOM: The RPM increases but the vehicle does not move POSSIBLE CAUSES WHAT TO DO 1.
  • Page 110 SPECIFICATIONS OUTLANDER™ 330 H.O. VEHICLE MODEL 2 x 4 4 x 4 ENGINE BOMBARDIER-ROTAX ® 4-TEC, 4-stroke. Type Over Head Camshaft (OHC), liquid cooled Number of cylinder Single cylinder Number of valve 4 valves with mechanical lifters (adjustable) Displacement 325 cc (19.8 cu. in)
  • Page 111 OUTLANDER™ 330 H.O. VEHICLE MODEL 2 x 4 4 x 4 ELECTRICAL Magneto generator make and type Denso, 400 W @ 6000 RPM Ignition type CDI (Capacitor Discharge Ignition) Ignition timing Not adjustable Engine RPM limiter 8000 RPM (any gear in forward) Vehicle speed limiter 15 km/h (9 MPH) in reverse Spark plug make and type...
  • Page 112 OUTLANDER™ 330 H.O. VEHICLE MODEL 2 x 4 4 x 4 WHEELS Front 12 x 6 Size Rear 12 x 7.5 Wheel nut torque 70 N•m (52 lbf•ft) BRAKES Front Hydraulic, 2 discs Rear Hydraulic, 1 disc Park through transmission. Parking LH brake lever includes a lock LOADING CAPACITY...
  • Page 113 300 mL (10 U.S. oz) N.A.: Not available Because of our ongoing commitment to product quality and innovation, Bombardier reserves the right, at any time, to make changes in design and specifications and/or to make additions to, or improvements in its products without imposing...
  • Page 114 OUTLANDER™ 400 H.O. VEHICLE MODEL 2 x 4 4 x 4 XT 4 x 4 ENGINE ® BOMBARDIER-ROTAX 4-TEC, 4-stroke. Type Over Head Camshaft (OHC), liquid cooled Number of cylinder Single cylinder Number of valve 4 valves with mechanical lifters (adjustable) Displacement 400 cc (24.4 cu.
  • Page 115 OUTLANDER™ 400 H.O. VEHICLE MODEL 2 x 4 4 x 4 XT 4 x 4 ELECTRICAL Magneto generator make and type Denso, 400 W @ 6000 RPM Ignition type CDI (Capacitor Discharge Ignition) Ignition timing Not adjustable Engine RPM limiter 8000 RPM (any gear in forward) Vehicle speed limiter 15 km/h (9 MPH) in reverse...
  • Page 116 OUTLANDER™ 400 H.O. VEHICLE MODEL 2 x 4 4 x 4 XT 4 x 4 WHEELS Front 12 x 6 Size Rear 12 x 7.5 Wheel nut torque 70 N•m (52 lbf•ft) BRAKES Front Hydraulic, 2 discs Rear Hydraulic, 1 disc Park through transmission.
  • Page 117 300 mL (10 U.S. oz) N.A.: Not available Because of our ongoing commitment to product quality and innovation, Bombardier reserves the right, at any time, to make changes in design and specifications and/or to make additions to, or improvements in its products without imposing...
  • Page 118 SI* METRIC INFORMATION GUIDE BASE UNITS DESCRIPTION UNIT SYMBOL length ..........meter ........ mass ..........kilogram ......force........... newton......liquid ..........liter ........temperature ........Celsius ......°C pressure ..........kilo pascal......torque ..........newton-meter ....N•m land velocity ........kilometer per hour.....
  • Page 119 WARRANTY...
  • Page 120 All genuine BOMBARDIER parts and accessories, installed by an authorized BOMBARDIER ATV dealer (as hereinafter defined) at the time of delivery of the 2004 BOMBARDIER ATV, carry the same warranty as that of the ATV.
  • Page 121 4. WHAT TO DO TO OBTAIN WARRANTY COVERAGE The customer must notify a servicing BOMBARDIER ATV dealer within two (2) days of the appearance of a defect, and provide it with reasonable access to the product and reasonable opportunity to repair it.
  • Page 122 9. CONSUMER ASSISTANCE a) In the event of a controversy or a dispute in connection with this BOMBARDIER LIMITED WARRANTY, BOMBARDIER suggests that you try to resolve the issue at the dealership level. We recommend discussing the issue with the authorized deal- er’s service manager or owner.
  • Page 123 All genuine BOMBARDIER parts and accessories, installed by an authorised BOMBARDIER distributor/dealer (as hereinafter defined) at the time of delivery of the 2004 BOMBARDIER ATV, carry the same warranty as that of the ATV. Use of the product for racing or any other competitive activity, at any point, even by a previous owner;...
  • Page 124 5. WHAT BOMBARDIER WILL DO BOMBARDIER’s obligations under this warranty are limited to, at its sole discre- tion, repairing parts found defective under normal use, maintenance and service; or replacing such parts with new genuine BOMBARDIER parts without charge for parts and labour, at any authorised BOMBARDIER distributor/dealer.
  • Page 125 BOMBARDIER. 9. CONSUMER ASSISTANCE a) In the event of a controversy or a dispute in connection with this BOMBARDIER LIMITED WARRANTY, BOMBARDIER suggests that you try to resolve the issue at the dealership level. We recommend discussing the issue with the autho- rised dealer’s service manager or owner.
  • Page 126 North America. Your registration card will provide the dealer with all the necessary data to complete warranty claim forms. b) Be advised by Bombardier Inc. should there be a safety recall or a par- ticular warranty campaign. c) Be contacted much faster by the police, in the event that they find your vehicle subsequent to a theft.
  • Page 127 Q: Are “Genuine” Bombardier replacement parts used in warranty repairs also covered by the limited warranty coverage? A: Yes. When installed by an authorized Bombardier ATV dealer, any “Genuine” Bombardier part used in warranty repairs assumes the remaining warranty that exists on the vehicle.
  • Page 128 If you prefer not to have your name and address released, please let us know by writing to the address below: Bombardier Inc. Recreational Products Warranty Department 75 J.A. Bombardier Street Sherbrooke, Québec J1L 1W3 Canada Fax Number: (819) 566-3590...
  • Page 129 Please provide your name, address, phone number, vehicle identification num- ber and date it was stolen. Bombardier will provide a list of stolen units to all ATV dealers on a monthly basis to aid in recovery of such units to their owners.
  • Page 130 CHANGE OF ADDRESS OTE: This card is strictly for change of address only. CHANGE OF ADDRESS ✁ AFFIX PROPER POSTAGE BOMBARDIER RECREATIONAL PRODUCTS WARRANTY DEPARTMENT 75, J.A. BOMBARDIER ST. SHERBROOKE (QUÉBEC) CANADA J1L 1W3...
  • Page 131 To be completed by the dealer at the time of the sale. DEALER IMPRINT AREA Please verify with your selling dealer to ensure your ATV has been regis- tered with Bombardier. WARNING Indicates a potential hazard that, if not avoided, could result in serious...
