ZYXEL NXC2500 - Wireless LAN Controller Quick Start Guide

Hardware Installation

Hardware Installation

  1. Connect to a PC for initial configuration.
    Connect to a modem/router for Internet access.
    Connect to a PoE switch to supply power over Ethernet to a managed AP.
  2. To configure the NXC2500 using commands, connect to a PC with terminal emulation software configured to the following parameters:
  • VT100 terminal emulation
  • 115200 bps
  • No parity, 8 data bits, 1 stop bit
  • No flow control
  1. Connect to an appropriate power source.

Initial Configuration

http://192.168.1.1
Username : admin
Password : 1234 (default)

Initial Configuration

  1. Open your web browser.
  2. Log in and use the wizard to set up your NXC2500.

Rack Mounting

Rack Mounting

  1. M4 flat head screws (included).
  2. Rack-mounting screws that come with the rack.

Support Information

North America USA
+ 1 800 255 4101 s
upport@zyxel.com

UK
+ 44 (0) 118 912 1700
support@zyxel.co.uk

Germany
+ 49 (0) 2405 69 09 69
support@zyxel.de

France
+ 3 3 (0) 4 72 52 97 97
support@zyxel.fr

Italy
+ 39 011 2308000
support@zyxel.it

EU Importer
Zyxel Communications A/S
Gladsaxevej 378, 2. th. 2860 Søborg, Denmark
http://www.zyxel.dk

US Importer
Zyxel Communications, Inc
1130 North Miller Street Anaheim, CA 92806-2001
http://www.us.zyxel.com

Copyright © 2018 Zyxel Communications Corp. All Rights Reserved.
