Multitech MT2834MR Product Update

MMMStarter-E/A 115v/RJ11 Chassis
Product Update
PN 82058410, Rev. A
1/19/00
With the MMMStarter-E/A 115V/RJ11 (rack configuration for RJ11 connections), there are six
RJ11 connectors for each modem slot. The current manual (page 2-7) shows the older RJ11
chassis with three RJ11's per modem slot. It does not refer to the current models with six
RJ11connectors per modem slot.
When you use an MT2834MR6 modem, there is one RJ11 connector for each modem on the card.
To use MT2834MR6 modems, you need a special cable for the RS232 connectors. Three of these
cables ship with the MT2834MR6 modems. Each cable has one male DB25 connector on one end
and two female DB25 connectors on the other end.
RJ11 Jack MT2834MR6
[1] Modem A
[2] Modem B
[3] Modem C
[4] Modem D
[5] Modem E
[6] Modem F
When you use an MT2834MR modem, the top three RJ11 jacks connect to the PTSN (dial-up)
connections on the modem card, the bottom three RJ11's connect to the 2 wire leased-line
connections of the MT2834MR card.
RJ11 Jack MT2834MR
[1] Modem A (dialup)
[2] Modem B (dialup)
[3] Modem C (dialup)
[4] Modem A (2 wire leased line)
[5] Modem B (2 wire leased line)
[6] Modem C (2 wire leased line)
1
