Coleman 2000001088 Installation Manual

Before you begin
Read all instructions before set up.
• Select a level campsite clear of rocks, branches, and other hard
or sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
• Do not set up your tent under trees.
• For best results in windy conditions, position end of tent into
the wind.
• Enlist the help of at least one other person to assist you when
it is time to assemble the tent.
To Set Up Tent
1. Unfold tent and spread out on a clean, level surface with the door facing the desired direction. (Fig. 1)
2. Assemble black main tent pole and both gray side poles by interlocking, shock-corded, sections.
3. Insert main pole through center sleeve (trimmed in black); then insert the two side poles through the outer sleeves (trimmed in
gray) as shown. (Fig. 1)
Black, Shock-corded
Main Pole
Gray, Shock-corded
Side Poles
4. Insert one end of main pole into center pin on side of tent; then the gray side poles into the other remaining side pins
(Fig. 2, 2A, & 2B). NOTE: The side poles should be on top of the black main pole.
5. Go to opposite end of each pole and gradually apply pressure to the pole forming an arch. Insert the pins into the poles end at
the other side of tent. The side poles will form an "X" on top of the black main pole when properly installed. (Fig. 2, 2A, & 2B)
6. Wrap the strap, on each side of the tent, around the three poles & secure by placing toggle through loop in strap. (Fig. 2B & 2C)
7. Stretch web straps at corners and loops on sides of tent until floor is taut; then hammer stakes through loops to secure. (Fig. 2D)
2D
THE SLEEPY OWL
Door
(continued on other side)
TM TENT 8' X 7'
MODEL 2000001088
Parts and Components
Description
Main Pole, Black (1)
Side Poles, Gray (2)
Rainfly
Door
Part Number
5010000372
5010000370
5010000371
Sleeve with Gray Trim
Sleeve with Black Trim
Sleeve with Gray Trim
Fig. 1
2C
Strap &
Toggle
2B
2A
Fig. 2
