Drivecon XS Series Quick Setup Guide

Navigating the Keypad

While navigating the menu structure, the first character displayed in the parameter addresses is a letter and should be
ignored. This letter has no practical relationship to your location in the menu structure. Navigation is determined by the
numbers alone. Focus on the numbers and the decimal points separating them. Please note that no letter is displayed
while viewing a parameter value. (Example: In parameter 2.10 below, the value of your output frequency is 0.00Hz)
Parameter 2.10 – Default Screen
Programming your Drive's Parameters
When viewing a parameter value you want to change, press
keypad. Use and
press again to select an individual digit and use the
selection is achieved, press
when the parameter value stops flashing.
1. Check all power and control connections to the drive.
Ensure all are correct and there are no loose wires.
2. Apply power to the drive.
The keypad should turn on and display an output frequency monitoring page with a value of "0.00". If the drive
displays a fault code, check the service manual for troubleshooting information.
3. Navigate to and enter the password parameter.
a) From the output frequency parameter 2.10, press
b) Press
c) Press
d) Press
the screen will display "00". Press
e) Using all four arrow keys, you can freely enter the value "2156". Press
to select between the available preset values. If the parameter is a numeric value, you can
to save the change to the drive's memory. A successful parameter change is confirmed
to change the parameter number to 1. Press
to display the current value of parameter 1.1.1.
to modify the parameter value, as indicated by a flashing '0'. Press
to edit it. The value of the parameter will flash on the
and to increase or decrease its value. Once the desired
until only the '2' remains on the display.
twice to display parameter 1.1.1.
three times and the screen will display "0000".
again and
to store to memory.
