Summary of Contents for Euhomy CF-35
- Page 1 Car Refrigerator Instruction Manual SKU：CF-35/45/55 Email：support@euhomy.com Facebook：@Euhomy.Official...
- Page 3 Email: support@euhomy.com Facebook: @Euhomy.Official The Euhomy team is available 24/7 to address your questions, comments, and concerns. Your satisfaction is our ultimate goal. We want to make everything right so you'll share your positive experience with other shoppers on Amazon.
-
Page 5: Table Of Contents
Contents SAFETY PRECAUTIONS 02-03 INSTALLATION APPLICATION & OPERATION 05-07 TEMP CONTROL/GENERAL OPERATION 08-09 TIPS & MAINTENANCE 10-11 12-13 TROUBLESHOOTING SPECIFICATIONS WARRANTY OPERATING PANEL & APP... -
Page 7: Safety Precautions
Safety Precautions ELECTRICAL SAFETY & CORD HANDLING Correct voltage: Make sure your local outlet voltage and circuit frequency correspond to the values indicated on the appliance's rating label. Note: Correct voltage: Make sure your local outlet voltage and circuit frequency correspond to the values indicated on the appliance's rating label. - Page 8 Safety Precautions Note: This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 9: Installation
Control panel LED lnner Light Radiator Cover STANDARD PACKING LIST 1. Euhomy car refrigerator 2. DC power cord (12/24 V) 3. AC adapter After unpacking the fridge, check that no parts are missing. Set up the unit in a dry place that is protected from splashing water. -
Page 10: Application & Operation
APPLICATION & OPERATION OPERATING YOUR FRIDGE/FREEZER POWER REQUIREMENTS The fridge is designed to operate on AC or DC voltage. AC input 110–240 V AC at 50 Hz to AC adaptor (e.g., electrical socket) DC input 12V/24 V DC (e.g., vehicle cigarette lighter or car battery) If the fridge is operating when the vehicle ignition is switched off, the fridge will switch off automatically unless the vehicle is fitted with a dual-battery system. - Page 11 Operation & Installation APPLICATION & OPERATION The fridge is equipped with a multilevel battery monitor that protects your vehicle battery against excessive discharging when the fridge is connected to a 12V or 24V DC power source. IMPORTANT: When running the fridge on DC power, we recommend setting the battery monitor to LOW if the fridge is not running on a crank battery.
- Page 12 APPLICATION & OPERATION OPERATING WITH 110–240V AC Turn off the cooler. Hold the settings button until it displays E1. Press the settings button repeatedly to cycle through all 9 settings in order, as shown in the table below. Choose the setting you need and press the up arrow or down arrow to change and set the parameters.
-
Page 13: Temp Control/General Operation
TEMP CONTROL/GENERAL OPERATION When your fridge is first connected to AC or DC power, the appliance will automatically switch on. The LCD control panel will display the current cabinet temperature, battery monitor, and ECO setting as well as the current input voltage. The temperature controller provides the ability to set the desired temperature level and display the current cabinet temperature. - Page 14 TEMP CONTROL/GENERAL OPERATION The fridge is designed to either refrigerate or freeze food. The unit is suitable for outdoor use, such as camping and tailgating. If you wish to refrigerate medicines, first check to ensure the fridge’s cooling capacity meets the required temperatures for the respective medicines. The fridge is designed to operate in ambient temperatures between 50°...
-
Page 15: Tips & Maintenance
TIPS & MAINTENANCE CLEANING AND MAINTAINING YOUR ICE MAKER Fresh and frozen foods should not be stored next to each other in the compartment. Doing so may cause fresh foods to freeze and spoil. When the unit is set at 32 °F or lower, do not store glass bottles or liquids such as beer, milk, juice, or soft drinks in the unit as these may freeze and shatter, leak, or burst. - Page 16 TIPS & MAINTENANCE Clean the fridge inside and out with a damp cloth. For stubborn dirt, use baking soda dissolved in lukewarm water. After washing, rinse with clean water and dry carefully. When storing your fridge for an extended time, DO NOT fully close the lid. This will prevent mold and odors from forming.
-
Page 17: Troubleshooting
TROUBLESHOOTING Issue Possible Solutions Check that the unit is switched on. Press the power button to turn on the unit. Check the power source (voltage may be too low). Check the power cable and all connections from The fridge will not turn on. the power source to the fridge. - Page 18 TROUBLESHOOTING Connected to DC power source, the Fridge/ Freezer has switched off. This may be due to setting low voltage. Check Battery Monitor setting is on Low. The display shows an error message (F1). Re-start vehicle to increase battery voltage level. The fridge has switched off due to an internal fault.
-
Page 19: Specifications
SPECIFICATIONS CF-35 CF-45 CF-55 Capacity 37qt 48qt 59qt –20°C to 20°C Cooling performance –4°F to 68°C Average power consumption DC fuse Rated current for DC 5.0A(12V)/2.5A(24V) Net weight 27.3 lbs 29.3 lbs 32.0 lbs Unit dimensions 690*345*382mm 690*345*462mm 690*345*524mm L*W*H 27.17*13.6*15.1in... -
Page 20: Warranty
If you have an issue with a Euhomy product, please contact us (support@euhomy.com), and we will do our best to resolve it for you. -
Page 21: Operating Panel & App
4. Search for local equipment and choose the fridge. 5. Check the fridge’s display panel. It should show “AP”. 6. Press the settings button “ ” to connect the fridge to your device. Android TIPS AND SUGGESTIONS CHAT WITH US EMAIL US euhomy.com/chat support@euhomy.com... - Page 24 Email：support@euhomy.com Facebook：@Euhomy.Official...
