- Page 1 32” Furrion Sense™ HD DLED All-In-One Entertainment System Instruction Manual *Product picture is for reference only. Model: FDHK32V1A...
-
Page 2: Welcome
Welcome Thank you for purchasing this 32” Furrion Sense™ HD DLED All-In-One Entertainment System. Before operating your new product, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the product. The manufacturer does not accept responsibility for any damages due to not observing these instructions. -
Page 3: Table Of Contents
Contents Welcome ....................2 Contents ....................3 Safety Warnings ..................4 Compliance ..............................7 Safety Precautions..........................8 Input & Output ports ..........................9 Front Panel .............................10 Remote Control ...........................13 About Your TV ..................15 Features ..............................15 Power Source ............................15 Before Operation ................. 16 What’s in the box ..........................16 Prepare your Remote Control ......................16 Getting Started .................. -
Page 4: Safety Warnings
Safety Warnings 7. Do not block any of the ventilation CAUTION openings. Install in accordance with the manufacturer’s instructions. RISK OF ELECTRIC SHOCK 8. Do not install near any heat sources such DO NOT OPEN as radiators, heat registers, stoves or CAUTION: TO REDUCE THE RISK OF ELECTRIC other apparatus (including amplifiers) that SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 5 Safety Warnings 16. An outside antenna system should not 20. NOTE TO CABLE/TV INSTALLER: This be located in the vicinity of overhead reminder is provided to call the CATV power lines or other electric light or power system installer’s attention to Article 820- circuits, or where it can fall into such 40 of the National Electric Code (U.S.A.).
- Page 6 ● If the liquid gets in your mouth, NOTE: Please make sure to insert the cord immediately rinse and consult with your securely at both the Furrion Sense™ TV and doctor. Also, if the liquid gets in your eyes 12V outlet.
-
Page 7: Compliance
Safety Warnings WARNING: turning the equipment off and on, the user is ● Do not connect this unit to the power encouraged to try to correct the interference using any device other than the supplied by one or more of the following measures: 12V cigarette adapter. -
Page 8: Safety Precautions
Safety Warnings RADIATION EXPOSURE STATEMENT If your existing television set is being retained This equipment complies with FCC’s and IC’s and relocated, the same considerations as RF radiation exposure limits set forth for an above should be applied. uncontrolled environment. The antenna(s) The unit emits heat when in operation. -
Page 9: Input & Output Ports
AM/FM Connect to the AM/FM antenna. ANTENNA Connect to the IR EXT port of IR EXT another Furrion Sense™ TV. ZONE 2 ZONE 2 OUT Connect to Zone 2 Speaker. Connect to the COMPOSITE AUDIO OUT ports of a DVD... -
Page 10: Front Panel
Function Overview Front Panel Item Description Item Description ● In radio mode, press and hold Display the audio source, mode or screen status. this button to store the current frequency as the preset station ● In radio mode, press and hold No.3. - Page 11 ● In radio mode, press this touching last time. (BT name: Furrion Sense 32" TV). key to move up the radio ● Press and hold it for 6 seconds to frequency one step at a time.
- Page 12 Function Overview Item Description ● In radio mode, press and hold this button to store the current frequency as the preset station No.6. Press it briefly to recall the preset station 6. ● In non-radio mode, press and hold it to select BL LOW, BL MID or BL HIGH to adjust the brightness.
-
Page 13: Remote Control
Function Overview Remote Control Item Button Function Press briefly to switch between ZONE 1 and ZONE 2. ZONE Press and hold it to turn off the ZONE current zone. Turn on/off the whole unit. NUMBER Enter numbers or select BUTTONS channels. - Page 14 Display available aspect ratios. Mono sound. Switch between the current PROG No function for this Sense TV. and previous channel. Control another Furrion IR-EXT Sense™ TV when IR external No function for this Sense TV. cable connected. Start, Pause or restart SETUP No function for this Sense TV.
-
Page 15: About Your Tv
About Your TV Features Power Source TV with integrated Soundbar system - NOTE: You can operate the TV from the sources ● Please make sure to insert the cord of HDMI, DTV/ATV, USB (audio & pictures securely at both the LED TV and the wall only) or CVBS with the decoded audio being outlet. -
Page 16: Before Operation
NOTE: Use two “AAA” size batteries. The batteries may last approximately one year depending on usage. For best performance, Thanks for purchasing this Furrion Sense™ it is recommended the batteries should HD LED TV. This manual will help you set up be replaced on a yearly basis, or when the and begin using your TV. -
Page 17: Getting Started
Getting Started The Setup Wizard window appears the first 4. Use on the remote control to highlight Time Zone, then press time you turned on the TV. It will assist you to configure the TV and scan for available select desired time zone. channels. -
Page 18: Tv Settings
TV Settings Setup Settings 1. Press MENU button on the remote control to display the main menu. 2. Use highlight Setup mode. 3. Use to highlight the item you would like to reset, then press to select the settings. 4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting. - Page 19 TV Settings Setup Menu Reset the unit Restore to factory Press to select Yes or No. Default defaults CEC Control to select Off or On. Press Press to select Off or On. Device Auto Power * If On, when the TV is turned off, all HDMI CEC connected devices will enter standby mode.
-
Page 20: Picture Settings
TV Settings Picture Settings 1. Press MENU button on the remote control to display the main menu. 2. Use to highlight Picture mode. 3. Use to highlight the item you would like to reset, then press to select the settings. 4. -
Page 21: Audio Settings
TV Settings Audio Settings 1. Press MENU button on the remote control to display the main menu. 2. Use to highlight Audio mode. 3. Use to highlight the item you would like to reset, then press select the settings. 4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting. -
Page 22: Time Settings
TV Settings Time Settings 1. Press MENU button on the remote control to display the main menu. to highlight Time mode. 2. Use 3. Use to highlight the item you would like to reset, then press to select the settings. 4. -
Page 23: Lock Settings
TV Settings Lock Settings 1. Press MENU button on the remote control to display the main menu. 2. Use to highlight Lock mode. to highlight “Enter Password” and input “0000” to enter the setup window. 3. Use 4. Use to highlight the item you would like to reset, then press to select the settings. - Page 24 TV Settings Lock Menu Use the Number Buttons (0~9) to enter the password, then the Lock menu will appear. Enter Input the password to access the Password Lock menu * Default password is 0000. * If you forgot the password, use 8888 to enter any locked menu. Enter New Use Number buttons (0-9) to enter a new password.
- Page 25 TV Settings Genre Fantasy Violence Violence Language Dialogue Canadian Rating System (English) Exempt from the ratings (All ages) Suitable for children age of 0–7 years TV-Y All Children Suitable for children age over 8 years TV-Y7 Suitable for 7 years old or above General Audience TV-G General Audience...
-
Page 26: Channel Settings
TV Settings Channel Settings 1. Press MENU button on the remote control to display the main menu. 2. Use to highlight Channel mode. 3. Use to highlight the item you would like to reset, then press select the settings. 4. Press OK to confirm your selections or settings and enter the sub menus. -
Page 27: Usb Mode
TV Settings USB Mode 1. After connecting a USB storage device For photos, you can use the tools on the to front USB port, press button on the photo viewer to control slide show, view remote control and select USB as the photos and show file information. -
Page 28: Soundbar Operation
Soundbar Operation * The built-in Soundbar could be operated separately even when the TV is turned off. Radio Operation General Operation Press and hold AM|FM to select Press POWER button at the bottom of Select Radio the radio region USA1, USA2, the TV front panel or button on the Region... - Page 29 Forward with the last paired device. Connect or (BT name: Furrion Sense 32” TV) Disconnect Press on the front panel to Pause Press and hold the button BT on the temporarily stop playback.
-
Page 30: Specification
Specification MODEL, DIMENSION & RESOLUTION Dimension without Stand TV Model Max Resolution (L*H*W) 29” x 21 13/16” x 4 5/16” FDHK32V1A 1280 x 720 @ 60Hz HD (736.7 x 554.2 x 109.4 mm) INPUT & OUTPUT CONNECTIONS AM/FM Audio Audio Zone 2 Component HDMI... - Page 31 (168.4 mm) VESA MOUNTING PATTERN Model Width (mm) Height (mm) Screw Size Screw Quantity FDHK32V1A M 6 * 12mm FURRION MOUNTING PATTERN Model Width (mm) Height (mm) Screw Size Screw Quantity FDHK32V1A M 6 * 12mm CCD-0005548 | REV DATE: 11.30.22...
- Page 32 Specification Category Item General Specification Panel Size 32” Resolution / Display Type 1366 × 768 / FWXGA / D-LED Refresh Rate 60Hz PANEL DISPLAY Contrast Ratio (CR ≥ 10) 3000 (min.: 2100) : 1 View Angle H:178°, V:178° Aspect Ratio 16 : 9 Brightness ≥...
-
Page 33: Troubleshooting
Troubleshooting Problem Solution/Issue ● Make sure the power cord is plugged in. ● Try another DC outlet. TV does not ● Power is off, check fuse or circuit breaker. operate ● Unplug unit for an hour, then plug it back in. ●... - Page 34 The contents of this manual are proprietary and copyright protected by Lippert. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert.
