Summary of Contents for Furrion DV3050

  • Page 2 CCD-0005532 | REV DATE: 11.29.22...

  • Page 3: Redial Button

    Locations and Names of the Controls 12 13 14 15 16 9. AUX IN SOCKET 1. NFC DETECTION AREA 2. IR REMOTE CONTROL SENSOR 10. HEADPHONE SOCKET 3. 1/2/3 BUTTON 11. USB SOCKET 1 TEL /REDIAL BUTTON 12. BT MODE BUTTON/EQ BUTTON 2 HANG UP BUTTON 13.
  • Page 4 The remote control description 1. Power button 2. APS button 3. SCAN button 4. CLOCK button 5. BAND button 6. MODE button 7. NUMBER buttons(0~9) 1/PAUSE/PLAY button 2/ INT button 3/RPT button 4/RDM button button 9. M UTE button 10. T-M button 11.
  • Page 5 5. To mute or resume sound Press MUTE button on the remote control to eliminate or resume sound immediately during playback. 6. To select and adjust the mode of the sound and menu Press SEL button repeatedly to select the mode of AF ON/AF OFF mode, TA ON/TA OFF PTY NEWS/PTY MUSICS, NEWS/POP M, BASS,TRE(treble), LIR(balance), LOUD OFF/LOUD ON, VOL LAST/VOL DEFA, BEEP ON/BEEP OFF, DX/LOCAL (in RADIO mode), STEREO/MONO(in RADIO mode), SUBW ON...
  • Page 6 Radio Operation 1. FREQUENCY SELECT In RADIO mode. Press and hold PLAY/PAUSE button for about 5 seconds to select your desired frequency EUROPE, USA1, USA2 or AUSTRALIA. 2. AM/FM BUTTON I n RADIO mode, press and hold INPUT MODE button on the front panel or briefly press BAND button on the remote control to select your desired radio band of FM1, FM2, FM3, AM1, AM2, and the selected band will be displayed on the LCD of the front panel.

  • Page 7: Af [Alternative Frequencies] Function

    7. LOC BUTTON 1) In RADIO mode, when the signal of the distance radio station are very weak and the receiving effect is bad during tuning, press LOC button on the remote control to turn off the LOC function, then tune again for the distance radio station; 2) In RADIO mode, when the signals from the local radio stations are too strong, this could lead to interference.
  • Page 8 USB Operation 1. Pause Playback During playback, press PLAY/PAUSE button on the front panel or remote control to pause the playback, press PLAY/PAUSE button again to resume normal playback. 2. Stop Playback During playback, press STOP button once to pause the playback, then press the PLAY/PAUSE button to resume the normal playback;...
  • Page 9 2)Select the item of Finding the Bluetooth Device and enter it. After finishing the finding,it will show the name of the Bluetooth Device FURRION DV3050-XXXX (where X can be any character A-Z or number 0-9).Select it and enter it, then it will show an interface that ask you to input a password, input the password 0000 and enter it.
  • Page 10 2 button on the front panel to end the call. Note: When an incoming call is present the LCD of the DV3050 will display CALL IN. 6. In BT mode, press CALL LOG button to check the LAST DIAL, LAST IN, LAST MISS phone numbers(press + or - button to cycle).
  • Page 11 Installing the unit * Before finally installing the unit, connect the wiring temporarily and make sure the unit and the system work properly. *Fix the unit with screw according to following diagram. SCREW PLASTIC SHELL OF THE FRONT PANEL SCREW 1.

  • Page 12: Subwoofer Out

    Wiring Diagram AV OUT AV IN SUBWOOFER OUT IR REMOTE JACK ANTENNA AUDIO IN WIRING CONNECTING SOCKET Wiring connecting socket view PIN NO COLOR FUNCTION GREY FRONT RIGHT SPEAKER (+) GREY/BLACK FRONT RIGHT SPEAKER (-) WHITE FRONT LEFT SPEAKER (+) WHITE/BLACK FRONT LEFT SPEAKER (-) GREEN/BLACK...
  • Page 13 CCD-0005532 | REV DATE: 11.29.22...
  • Page 14 CCD-0005532 | REV DATE: 11.29.22...
  • Page 15 CCD-0005532 | REV DATE: 11.29.22...
  • Page 16 The contents of this manual are proprietary and copyright protected by Lippert. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert.
