RKC INSTRUMENT Z-COM Instruction Manual

Communication extension module

Table of Contents

Quick Links

Download this manual

Module Type Controller SRZ

Communication Extension

Module

Z-CO M

Instruction Manual

(PLC/Host Communication)

www.rkc-usa.com

(800) 576 - 6308

Distributed By

Inc,

Table of Contents

Need help?

Do you have a question about the Z-COM and is the answer not in the manual?

Questions and answers

Summary of Contents for RKC INSTRUMENT Z-COM

Page 1 Module Type Controller SRZ Communication Extension Module Z-CO M Instruction Manual (PLC/Host Communication) www.rkc-usa.com (800) 576 - 6308 Distributed By Inc,...
Page 2 The name of each programmable controller (PLC) means the products of each manufacturer. Company names and product names used in this manual are the trademarks or registered trademarks of the respective companies. All Rights Reserved, Copyright  2006, RKC INSTRUMENT INC.
Page 3 Thank you for purchasing this RKC instrument. In order to achieve maximum performance and ensure proper operation of your new instrument, carefully read all the instructions in this manual. Please place this manual in a convenient location for easy reference.
Page 4 CAUTION This is a Class A instrument. In a domestic environment, this instrument may cause radio interference, in which case the user may be required to take adequate measures. This instrument is protected from electric shock by reinforced insulation. Provide reinforced insulation between the wire for the input signal and the wires for instrument power supply, source of power and loads.
Page 5: Table Of Contents
2.2 Only When Use Host Communication ............2-8 2.3 When Use Loader Communication.............2-13 3. COMMUNICATION SETTING ...........3-1 3.1 Communication Setting Procedures .............3-2 3.2 Communication Setting of Z-COM Module ...........3-3 3.2.1 SRZ unit address setting..................3-3 3.2.2 Communication speed and communication protocol setting by DIP switch.......................3-6 3.2.3 Communication speed and communication protocol setting via...
Page 6 6.2.1 When SRZ unit is connected to a host computer with RS-422A ......6-4 6.2.2 When SRZ unit is connected to a host computer with RS-485........6-7 6.2.3 Multiple SRZ unit connections................6-11 6.2.4 Termination resistor of Z-COM module ..............6-13 6.2.5 Connections for loader communication ..............6-14 6.3 Communication Requirements ..............6-15 6.4 RKC Communication Protocol ..............6-17...
Page 7 7.6.7 PLC setting ......................7-64 7.6.8 Initial setting ......................7-66 7.6.9 Data setting......................7-67 8. COMMUNICATION DATA DESCRIPTION .......8-1 8.1 Reference to Communication Data Contents ..........8-2 8.2 Communication Data of Z-COM Module............8-3 9. TROUBLE SHOOTING ............9-1 10. SPECIFICATIONS ............10-1 10.1 Communication Specifications..............10-2 10.2 Product Specifications ................10-6...
Page 8 MEMO IMS01T07-E1...
Page 9: Outline
OUTLINE This chapter describes features, package contents, model code, and system configuration, etc. 1.1 Features ...................1-2 1.2 Checking the Product ...............1-4 1.3 Model Code ..................1-5 1.4 Parts Description ................1-6 1.5 Example of System Configuration.............1-8 1.5.1 When one SRZ unit is connected ..............1-8 1.5.2 Multi-drop connection by PLC communication...........1-9 1.5.3 Multi-drop connection by host communication.........1-10 IMS01T07-E1...
Page 10: Features
The SRZ unit sets all of the data items via communication. Therefore before operation, it is necessary to set value of each data item via communication. The Z-COM module is connected to an SRZ functional module* (hereafter called “functional module”) for the purpose of performing programmable controller communication (hereafter called “PLC communication”) or host communication.
Page 11 Z-COM module Number of temperature control • Up to 16 Z-TIO modules can be connected to one Z-COM module. For example, when up to 16 Z-TIO modules (4-channel type) are connected to one Z-COM module, the maximum number of temperature control channels per one unit becomes 64.
Page 12: Checking The Product
Check that all of the items delivered are complete. (See below) Name Q’TY Remarks Z-COM module  Z-COM Installation Manual (IMS01T05-E ) Enclosed with instrument Z-COM PLC Communication Quick Instruction Enclosed with instrument Manual (IMS01T06-E ) Z-COM Host Communication Quick Instruction...
Page 13: Model Code
Check whether the delivered product is as specified by referring to the following model code list. If the product is not identical to the specifications, please contact RKC sales office or the agent. Z-COM module Z - COM - A -...
Page 14: Parts Description
1. OUTLINE 1.4 Parts Description Z-COM module mainframe Loader Indication lamp communication (FAIL/RUN) DIP switch connector Address setting switch Indication lamp Communication port (RX1/TX1) COM. PORT1 Communication 1 COM. PORT2 Module mainframe Indication lamp Communication port (RX2/TX2) COM. PORT3 Communication 2 Base COM.
Page 15 Customer must provide the M3 screws. Joint connector Used to mechanically and electrically connect each module. Power supply terminals These are terminals to supply power to the Z-COM module and joined function modules. Terminal number Signal name 24 V DC (+) 24 V DC (−)
Page 16: Example Of System Configuration
• When joining functional modules of the same type to Z-COM module Up to 16 functional modules (Z-TIO, Z-DIO) can be connected to one Z-COM module with SRZ unit. As the number of temperature control channels per Z-TIO module is 4, the maximum number of temperature control channels per unit becomes 64 (4-channel ×...
Page 17: Multi-Drop Connection By Plc Communication
• For PLC communication, up to four units (i.e. four Z-COM modules) can be multi-drop connected to one PLC communication port. • As up to 16 Z-TIO modules can be connected to one Z-COM module, temperature control of up to 256 channels can be performed. (4-channel × 16 Z-TIO modules × four SRZ units) Example Communication 1 (COM.
Page 18: Multi-Drop Connection By Host Communication
• For host communication, up to 16 units (i.e. 16 Z-COM modules) can be multi-drop connected to one host communication port. • As up to 16 Z-TIO modules can be connected to one Z-COM module, temperature control of up to 1024 channels can be performed. (4-channel × 16 Z-TIO modules × 16 SRZ units) Example Communication 1 (COM.
Page 19: Setting Procedure To Operation
SETTING PROCEDURE TO OPERATION 2.1 When Use PLC Communication and Host Communication....2-2 2.2 Only When Use Host Communication ..........2-8 2.3 When Performing Operation Setting via Loader Communication ...2-13 IMS01T07-E1...
Page 20: When Use Plc Communication And Host Communication
2. SETTING PROCEDURE TO OPERATION When Use PLC Communication and Host Communication Conduct necessary setting before operation according to the procedure described below. Checking the Product Remove the product from its packaging and verify that no parts are missing. See 1.2 Checking the Product (P. 1-4). Preparation of host communication program To perform host communication, a communication program must be created.
Page 21 Configure the module addresses of the functional modules (Z-TIO and Z-DIO modules) that will be joined to the Z-COM module. See 3.3 Communication Setting of the Functional Modules (P. 3-14). Mounting Mount the Z-COM module and functional modules on the DIN rail or panel. See 4. MOUNTING (P. 4-1). IMS01T07-E1...
Page 22 If you will use host communication to configure the communication data of the functional modules (Z-TIO and Z-DIO modules), do so after data collection is finished. Z-COM module system data (setting items) can be configured immediately after the power is turned IMS01T07-E1...
Page 23 2. SETTING PROCEDURE TO OPERATION Setting of PLC communication environment (system data) For PLC communication, set a necessary system data (setting item) via host communication. (Station number, Register type or Register start number, etc.) For MELSEC series, see 7.2.3 PLC communication environment setting (P. 7-11). For SYSMAC series, see 7.3.3 PLC communication environment setting (P.7-25).
Page 24 In addition, writing of the system data (monitor items) begins after the PLC communication start time (factory set value is five seconds) has passed. When collection of the data is completed, the Z-COM module begins writing the communication data of monitor group to the PLC.
Page 25 2. SETTING PROCEDURE TO OPERATION PLC communication initial setting Before changing the SRZ unit data from PLC, always read it into the PLC once. The initial setting must always conduct. If each set value of SRZ unit is changed from the PLC without setting the initial values, it is re-written to 0 with each set value of the PLC at that time set to 0.
Page 26: Only When Use Host Communication
2. SETTING PROCEDURE TO OPERATION 2.2 Only When Use Host Communication Conduct necessary setting before operation according to the procedure described below. Checking the Product Remove the product from its packaging and verify that no parts are missing. See 1.2 Checking the Product (P. 1-4). Preparation of host communication program To perform host communication, a communication program must be created.
Page 27 Configure the module addresses of the functional modules (Z-TIO and Z-DIO modules) that will be connected to the Z-COM module. See 3.3 Communication Setting of the Functional Modules (P. 3-14). Mounting Mount the Z-COM module and functional modules on the DIN rail or panel. See 4. MOUNTING (P. 4-1). IMS01T07-E1...
Page 28 See 6.2 Wiring (P.6-3). Power ON (host computer and SRZ unit) The Z-COM module starts collecting data on functional modules (Z-TIO and Z-DIO modules) jointed from the time when the power is turned on. Data collection takes about eight seconds.
Page 29 (P. 6-71). For function description of communication data, SRZ Instruction Manual (IMS01T04-E ). Will you change the communication settings of the Z-COM module (When performing communication by the DIP switch setting) by host communication? Set the communication settings via host communication.
Page 30 When the power of the SRZ unit is turned on, communication will start using the changed communication settings. The Z-COM module starts collecting data on functional modules (Z-TIO and Z-DIO modules) jointed from the time when the power is turned on.
Page 31 See ■ Address setting for loader communication (P. 3-5). Module address setting of the functional modules Configure the module addresses of the functional modules (Z-TIO and Z-DIO modules) that will be connected to the Z-COM module. See 3.3 Communication setting of the Functional Modules (P. 3-14). 2-13 IMS01T07-E1...
Page 32 See 6.2.5 Connections for Loader Communication. (P. 6-14). Power ON (host computer and SRZ unit) The Z-COM module starts collecting data on functional modules (Z-TIO and Z-DIO modules) jointed from the time when the power is turned on. Data collection takes about eight seconds.
Page 33 (System data for PLC communication, engineering data of Z-TIO and Z-DIO modules, operation data, etc.) Some of the communication data of the Z-COM module will not take effect until the power is turned on or control is switched from STOP to RUN.
Page 34 MEMO 2-16 IMS01T07-E1...
Page 35 This chapter describes communication setting of the SRZ unit. Set communication setting before mounting and wiring. 3.1 Communication Setting Procedures ..........3-2 3.2 Communication Setting of Z-COM Module ........3-3 3.2.1 SRZ unit address setting ................3-3 3.2.2 Communication speed and communication protocol setting by DIP switch ....................3-6...
Page 36: Communication Setting
Set the communication protocol Configure communication settings for the functional modules to be joined to and data bit configuration of the the Z-COM module. (P. 3-14) communication 1. (P. 3-7) Communication setting Set the communication speed of the communication 2.
Page 37: Communication Setting Of Z-Com Module
This becomes the unit address of the SRZ unit. (The unit address is common to the PLC and host communications.) Set an address for the SRZ unit (address for Z-COM module) using a small blade screwdriver. To avoid problems or malfunction, do not duplicate an address on the same communication line.
Page 38 3. COMMUNICATION SETTING Address setting for PLC communication Up to four Z-COM modules can be connected to a PLC communication port. Therefore the unit address uses the four Z-COM modules as a group. For Z-COM modules which are multi-drop connected to the same PLC communication port, use successive numbers assigned to any one of four groups shown in the following table as their addresses.
Page 39 3. COMMUNICATION SETTING Address setting for host communication (RKC communication or Modbus) Differently from PLC communication, there are no group restrictions. Free settings can be made in the range of 0 to F. For Modbus, the value obtained by adding “1” to the set address corresponds to the address used for the actual program.
Page 40: Communication Speed And Communication Protocol Setting By Dip Switch
3.2.2 Communication speed and communication protocol setting by DIP switch Use the DIP switch on the right side of Z-COM module to select communication speed, data bit, configuration and protocol. The data change become valid the power of the Z-COM module is turned on again or when control is switched from STOP to RUN.
Page 41 3. COMMUNICATION SETTING Communication protocol and Data bit configuration (switch No. 3) Use switch No. 3 to set the communication protocol and data bit configuration for Communication 1. DIP switch Communication protocol and Data bit configuration (Communication 1) Communication protocol and Data bit configuration (Communication 1) Host communication (RKC communication) Data 8-bit, without parity, Stop 1-bit (Factory set value *)
Page 42 3. COMMUNICATION SETTING Communication protocol and Data bit configuration (switch No. 5, 6 and 7) Use switch No. 5, 6 and 7 to set the communication protocol and data bit configuration for Communication 2. DIP switch Communication protocol and Data bit configuration (Communication 2) Communication protocol and Data bit configuration (Communication 2) Host communication (RKC communication)
Page 43 3. COMMUNICATION SETTING (3) DIP switch setting validity/invalidity Validity/invalidity of DIP switch setting (switch No. 8) Set switch No.8 to “ON” when performing communication by the communication settings set via host communication or loader communication. When set to “ON,” the DIP switch settings are disabled. DIP switch DIP switch setting validity/invalidity DIP switch setting validity/invalidity...
Page 44: Communication Speed And Communication Protocol Setting Via Host Communication
3. COMMUNICATION SETTING 3.2.3 Communication speed and communication protocol setting via host communication In order to use host communication to change the communication speed, communication protocol, or data bit configuration of the SRZ unit, host computer and SRZ unit communication must first be enabled in the DIP switch communication settings.
Page 45 3. COMMUNICATION SETTING Setting example When changing the data bit configuration of communication 1 for SRZ unit: (Change the data bit configuration from “data 8-bit, no parity, stop 1-bit” to “data 8-bit, even parity, stop 1-bit.”) 1. Change the data bit configuration of SRZ unit on the host computer. Change to “1: data 8-bit, even parity, Stop 1-bit.”...
Page 46 3. COMMUNICATION SETTING 4. Remove the mainframe of Z-COM module from the base. Then, set the DIP switch No.8 to “ON (Invalid).” DIP switch Remove the mainframe of Z-COM module from the base. DIP switch setting validity/invalidity: ON (Invalid) Host computer...
Page 47: Communication Setting For Loader Communication
3.2.4 Communication setting for loader communication When loader communication is used, the communication speed, communication protocol, and data bit configuration of the Z-COM module are fixed. (There is no need to configure the communication settings of the Z-COM module.) Set the communication settings of the host computer to the same settings as the Z-COM module.
Page 48: Communication Setting Of The Functional Modules
Only make the module address setting to make the functional module (Z-TIO, Z-DIO, etc.) communication settings. The SRZ unit performs internal communication between the Z-COM module and the functional module, so the communication protocol, communication speed, and data bit configuration do not need to be set.
Page 49: Temperature Control Channel Of The Srz Unit
3. COMMUNICATION SETTING Address setting example of functional module (16 Z-TIO module, 15 Z-DIO module): Setting of the address setting switch Z-TIO Z-TIO Z-TIO Z-DIO Z-DIO module 1 module 3 module 16 module 2 module 15 Z-TIO Z-TIO Z-DIO Z-DIO module 2 module 4 module 1...
Page 50: Digital Input/Output Channel Of Z-Dio Module
3. COMMUNICATION SETTING 3.3.3 Digital input/output channel of Z-DIO module Setting the Z-DIO module address determines the digital input/output channel number of SRZ unit. To each Z-DIO module address, the relevant digital input/output channel is assigned. Each digital input/output channel can be calculated from the following equation. Digital input/output channel number = Setting of the address setting switch * ×...
Page 51: Mounting
MOUNTING This chapter describes method of module joining and the SRZ unit mounting. 4.1 Mounting Cautions................4-2 4.2 Dimensions..................4-5 4.3 Joinable Number of Modules ............4-6 4.4 DIN Rail Mounting................4-7 4.5 Panel Mounting.................4-9 4.6 Removing from the DIN Rail ............4-10 IMS01T07-E1...
Page 52: Mounting Cautions
4. MOUNTING 4.1 Mounting Cautions WARNING To prevent electric shock or instrument failure, always turn off the power before mounting or removing the instrument. (1) This instrument is intended to be used under the following environmental conditions. (IEC61010-1) [OVERVOLTAGE CATEGORY II, POLLUTION DEGREE 2] (2) Use this instrument within the following environment conditions.
Page 53 4. MOUNTING • Space required between each module vertically When the module is mounted on the panel, allow a minimum of 50 mm at the top and bottom of the module to attach the module to the mainframe. (Unit: mm) 50 or more •...
Page 54 Mount the SRZ unit in the direction specified as shown below. Bottom • Be sure the Z-COM module and functional modules (Z-TIO, Z-DIO) are joined when using them. • Joining position of Z-COM module Z-COM module connected inside the same unit can be placed in any position.
Page 55: Dimensions
4. MOUNTING 4.2 Dimensions Dimensions (Z-COM module) (Unit: mm) 76.9 For dimension of the functional module, see Instruction Manual of each functional module. IMS01T07-E1...
Page 56: Joinable Number Of Modules
[Example] When only the Z-TIO module is jointed SRZ unit Functional module (Up to 16 modules) Z-COM module: one module Z-TIO module When joining functional modules of two or more different types: Up to 31 modules (However, the maximum joinable number of functional modules of the same type is 16.)
Page 57: Din Rail Mounting
1. Pull down the mounting bracket at the bottom of the module (A). Attach the hooks on the top of the module to the DIN rail and push the lower section into place on the DIN rail (B). 2. Slide the mounting bracket up to secure the module to the DIN rail (C). Z-COM module Z-COM module DIN rail...
Page 58 4. MOUNTING 5. Connect the required number of functional modules. 6. Install a plastic cover on the connector on both sides of the mounted modules for protection of connectors. Joint connector cover 7. Secure both ends of the modules jointed together with the end plates. End plate End plate IMS01T07-E1...
Page 59: Panel Mounting
4. MOUNTING 4.5 Panel Mounting Mounting procedures 1. Refer to the mounting dimensions below when selecting the location. (30) (Unit: mm) 30±0.2 Recommended screw: M3 × 10 Recommended tightening torque: 0.3 N･m (3 kgf･cm) Base Mounting dimensions 2. Remove the base from the module (B) while the lock is pressed (A). (Fig.1) Lock (Bottom of the module mainframe) Fig 1: Removing the base...
Page 60: Removing From The Din Rail
4. MOUNTING 4.6 Removing from the DIN Rail Removing procedures 1. Pull down a mounting bracket with a blade screwdriver (A). 2. Lift the module from bottom, and take it off (B). (B) Lift and take off (A) Pull down 4-10 IMS01T07-E1...
Page 61: Wiring
WIRING This chapter explains the procedures for connecting the power supply wiring to the SRZ unit. For information on connecting input/output wiring to functional modules, see the manual for each functional module. 5.1 Wiring Cautions ................5-2 5.2 Wiring of Power Supply ..............5-3 5.2.1 Terminal configuration (base) ..............5-3 5.2.3 Wiring method ...................5-3 IMS01T07-E1...
Page 62: Wiring Cautions
• Select the power capacity which is appropriate for the total power consumption of all joined modules and the initial current surge when the power is turned on. Power consumption (at maximum load): 30 mA max. (at 24 V DC) [Z-COM module] Rush current: 10 A or less •...
Page 63: Wiring Of Power Supply
In addition, do not use terminals 3, 4, and 5 of functional modules. 5.2.2 Wiring method When using the Z-COM module connected to functional modules, the power supply wiring is connected to any one of the modules. Power is supplied from the module with the power wiring to the other modules.
Page 64 5. WIRING 3. Return the module mainframe to the base. This completes the wiring work. Z-COM module Return the module mainframe to the base. IMS01T07-E1...
Page 65: Host Communication
6.2.1 When SRZ unit is connected to a host computer with RS-422A....6-4 6.2.2 When SRZ unit is connected to a host computer with RS-485 ....6-7 6.2.3 Multiple SRZ unit connections ..............6-11 6.2.4 Termination resistor of Z-COM module............6-13 6.2.5 Connections for loader communication ...........6-14 6.3 Communication Requirements............6-15 6.4 RKC Communication Protocol ............6-17...
Page 66: Outline
6. HOST COMMUNICATION 6.1 Outline The following two communication systems of Z-COM module are available. • Communication 1 (COM. PORT1, COM. PORT2) • Communication 2 (COM. PORT3, COM.PORT4) Both communication 1 and communication 2 are available as host communication. It is also possible to use only Communication 1 or only Communication 2.
Page 67: Wiring
6. HOST COMMUNICATION 6.2 Wiring WARNING To prevent electric shock or instrument failure, turn off the power before connecting or disconnecting the instrument and peripheral equipment. CAUTION To avoid noise induction, keep communication signal wire away from instrument power line, load lines and power lines of other electric equipment.
Page 68: When Srz Unit Is Connected To A Host Computer With Rs-422A
W-BF-28-3000 (RKC product, Sold separately) [Standard cable length: 3 m] Connection cable W-BF-02 * and W-BF-28 (RKC product) can use to connect the host computer. * Shield of the cable are connected to SG (No. 6 pin) of the Z-COM modular connector. Recommended RS-232C/RS-422A converter: COM-A (RKC product) For the COM-A, see COM-A/COM-B Instruction Manual (IMSRM33-E ).
Page 69 Send data T (A) Signal ground The 6-pin type modular connector should be used for the connection to the Z-COM module. Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD.,) When the interface of host computer is RS-422A (1-to-1 connection)
Page 70 * COM. PORT1 and COM. PORT2 are internally connected. The method wiring of COM. PORT3 and COM. PORT4 is the same as a figure above. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13).
Page 71 * COM. PORT1 and COM. PORT2 are internally connected. The method wiring of COM.PORT3 and COM.PORT4 is the same as a figure above. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). When the host computer (master) uses Windows95/98/Me/NT/2000/XP, use a RS-232C/RS-485 converter with an automatic send/receive transfer function.
Page 72 Send/receive data T/R (A) Send/receive data T/R (B) Signal ground  Unused  Unused Signal ground The 6-pin type modular connector should be used for the connection to the Z-COM module. Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD.,) IMS01T07-E1...
Page 73 * COM. PORT1 and COM. PORT2 are internally connected. The method wiring of COM. PORT3 and COM. PORT4 is the same as a figure above. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13).
Page 74 R2: Z-COM (Sold separately) T/R (B) [120 Ω 1/2 W] COM. PORT2 * * COM. PORT1 and COM. PORT2 are internally connected. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). 6-10 IMS01T07-E1...
Page 75: Multiple Srz Unit Connections
When the interface is RS-422, can be connected by our cable (sold separately: W-BF-02). Cable type: W-BF-02-3000 (Sold separately) [Standard cable length: 3 m] COM. PORT1 and COM. PORT2 are internally connected. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). 6-11...
Page 76 When the interface is RS-422, can be connected by our cable (sold separately: W-BF-02). Cable type: W-BF-02-3000 (Sold separately) [Standard cable length: 3 m] COM. PORT3 and COM. PORT4 are internally connected. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). 6-12...
Page 77: Termination Resistor Of Z-Com Module
When the COM. PORT3 is used: Insert the termination resistor to COM. PORT4. When two or more SRZ units are connected, connect a termination resistor to the Z-COM module at the farthest end of the communication line. Host computer SRZ unit 1...
Page 78: Connections For Loader Communication
6. HOST COMMUNICATION 6.2.5 Connections for loader communication Z-COM module is equipped standard with a loader communication connector. The module loader communication connector, our COM-K USB communication converter (sold separately) *, and a personal computer can be connected with the appropriate cables.
Page 79: Communication Requirements
6. HOST COMMUNICATION 6.3 Communication Requirements Processing times during data send/receive When the host computer is using either the polling or selecting procedure for communication, the following processing times are required for SRZ unit to send data: - Response wait time after SRZ unit sends BCC in polling procedure - Response wait time after SRZ unit sends ACK or NAK in selecting procedure RKC communication (Polling procedure) Procedure details...
Page 80 6. HOST COMMUNICATION RS-485 (2-wire system) send/receive timing RS-485 communication is conducted through two wires, therefore the transmission and reception of data requires precise timing. Polling procedure Possible Send data Host (Possible/Impossible) Impossible computer Sending status - - - - - Possible Send data (Possible/Impossible)
Page 81: Rkc Communication Protocol
6. HOST COMMUNICATION 6.4 RKC Communication Protocol RKC communication uses the polling/selecting method to establish a data link. The basic procedure is followed ANSI X3.28 subcategory 2.5, B1 basic mode data transmission control procedure (Fast selecting is the selecting method used in SRZ unit). •...
Page 82 6. HOST COMMUNICATION (1) Data link initialization Host computer sends EOT to the controllers to initiate data link before polling sequence. (2) Data sent from host computer - Polling sequence The host computer sends the polling sequence in the following two types of formats: •...
Page 83 6. HOST COMMUNICATION 3. Identifier (2 digits) The identifier specifies the type of data that is requested from the SRZ unit. Always attach the ENQ code to the end of the identifier. See 6.4.5 Communication data list (P. 6-31). 4. ENQ The ENQ is the transmission control character that indicates the end of the polling sequence.
Page 84 6. HOST COMMUNICATION Memory area soak time monitor and area soak time become the following data: • When data range is 0 hour 00 minute to 99 hours 59 minutes: Data range is 0:00 to 99:59, punctuation of time unit is expressed in colon “: (3AH).” •...
Page 85 6. HOST COMMUNICATION (6) ACK (Acknowledgment) An acknowledgment ACK is sent by the host computer when data received is correct. When the SRZ unit receives ACK from the host computer, the SRZ unit will send any remaining data of the next identifier without additional action from the host computer.
Page 86 6. HOST COMMUNICATION Polling procedure example (When the host computer requests data) Normal transmission Host computer send Host computer send 04H 30H 31H 4BH 31H 53H 31H 05H … Identifier Memory Address area number 02H 53H 31H 30H 30H 31H 20H 20H 20H 34H 30H 30H 2EH 30H 2CH Identifier Channel No.
Page 87: Selecting Procedures
6. HOST COMMUNICATION 6.4.2 Selecting procedures Selecting is the action where the host computer requests one of the connected SRZ units to receive data. An example of the selecting procedure is shown below: Host computer Host computer send SRZ unit send send No response [BCC]...
Page 88 6. HOST COMMUNICATION • When the memory area number is specified Memory area Identifier Data number Memory area Identifier Data number For the STX, Memory area number Identifier, Data, ETB, ETX and BCC, see 6.4.1 Polling procedures (P. 6-17).. If the length of send data (from STX to BCC) exceeds 128 bytes, it is divided into blocks by ETB. In this case, the succeeding divided data is sent after STX.
Page 89 6. HOST COMMUNICATION The data that receipt of letter is impossible The SRZ unit sends NAK when received a following data. Plus sign and the data that gained plus sing − Only minus sign (there is no figure) −. Only minus sign and decimal point (period) (4) ACK (Acknowledgment) An acknowledgment ACK is sent by the SRZ unit when data received is correct.
Page 90 6. HOST COMMUNICATION Selecting procedure example (when the host computer sends data) Normal transmission Host computer send … 04H 30H 31H 02H 4BH 31H 53H 31H 30H 30H 31H 20H 20H 20H 34H 30H 30H 2EH 30H Address Identifier Channel No. Memory Data area...
Page 91: Communication Data Structure
6. HOST COMMUNICATION 6.4.3 Communication data structure Data description ......................Data Part of the data above is shown below. Data for each unit (Without channel) Data length 7 digits Data length 1 digit Data Identifier Identifier Data Example) Data structure for control RUN/STOP switching in each SRZ unit S R 1 Identifier Data Data for each module...
Page 92 6. HOST COMMUNICATION Data for each channel Data length 7 digits Data Memory Data Identifier Channel No. Channel No. area number * Space Comma Data length 1 digit Memory Data Data Identifier Channel No. Channel No. area number * Space Space Comma * To select data corresponding to a memory area, specify the number of the appropriate memory area.
Page 93: Channel Number Of Communication
The method of calculating the channel number is explained below using the example of an SRZ unit configuration. Host computer Setting of the address setting switch Example of system configuration: RKC communication Z-COM module: 1 module Z-TIO module: 3 modules Z-DIO module: 2 modules Z-COM module Z-TIO module 1...
Page 94 6. HOST COMMUNICATION (2) Data for each module (Communication data particular to one module) Computing equation : Channel number of communication = Setting of the address setting switch + 1 Example) Channel number of digital input (DI) state 1 (Identifier: L1) of Z-DIO module Setting of the address setting switch Channel number of communication Z-DIO module 2 ------- 1 + 1 = 2...
Page 95: Rkc Communication Data List
Least significant digit (7) Factory set value: Factory set value of communication data Some of the communication data of the Z-COM module will not be enabled until the power is turned on again, or control is switched from STOP to RUN.
Page 96 • No. 11 to 15: System data (monitoring item) for PLC communication • No. 27 to 35, No. 37: System data (setting item) for PLC communication For the communication data of Z-COM module, see Chapter 8 COMMUNICATION DATA DESCRIPTION (P. 8-1). Iden...
Page 97 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value  PLC communication error Bit data code b0: PLC register read/write error b1: Slave communication timeout b2: Unused b3: Internal communication error b4: Master communication timeout b5 to b15: Unused...
Page 98 Number of connected 0 to 16 modules This is the maximum address of the Z-TIO module (Z-TIO module) that is connected to the Z-COM module.  Number of connected 0 to 16 modules This is the maximum address of the Z-DIO module (Z-DIO module) that is connected to the Z-COM module.
Page 99 6. HOST COMMUNICATION Communication data of Z-TIO module For details of Z-TIO module communication data, see SRZ Instruction Manual (IMS01T04-E ). Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value  Measured value (PV) Input scale low to Input scale high ...
Page 100 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value  Memory area soak time 0 minutes 00 seconds to 199 minutes 59 seconds: monitor 0:00 to 199:59 (min:sec) 0 hours 00 minutes to 99 hours 59 minutes: 0:00 to 99:59 (hrs:min) Data range of Area soak time can be selected on the Soak...
Page 101 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value TC/RTD inputs: Proportional band TC/RTD: 30 0 (0.0) to Input span (Unit: °C [°F]) [heat-side] V/I: 30.0 Varies with the setting of the decimal point position selection. ★...
Page 102 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value −100.0 to +100.0 % Manual reset ★ If the integral function is valid, set to RO (Only reading data is possible).
Page 103 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value Relay contact Proportional cycle time 0.1 to 100.0 seconds output: This item becomes RO (Only reading data is possible) for the 20.0 seconds voltage/current output specification.
Page 104 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 0 to 10 times EDS value learning times (0: No learning mode) 0: EDS start signal OFF EDS start signal 1: EDS start signal ON (for disturbance 1) 2: EDS start signal ON (for disturbance 2) 0: Unused...
Page 105 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 0: No decimal place 3: Three decimal places Decimal point position Depends on 1: One decimal place 4: Four decimal places model code 2: Two decimal places When not...
Page 106 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 1: Channel 1 Event 1 channel setting 2: Channel 2 3: Channel 3 4: Channel 4 This function is valid when "deviation between channels" is selected.
Page 107 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 1: Channel 1 Event 2 channel setting 2: Channel 2 3: Channel 3 4: Channel 4 This function is valid when "deviation between channels" is selected.
Page 108 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 1: Channel 1 Event 3 channel setting 2: Channel 2 3: Channel 3 4: Channel 4 This function is valid when "deviation between channels" is selected.
Page 109 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 1: Channel 1 Event 4 channel setting 2: Channel 2 3: Channel 3 4: Channel 4 This function is valid when "deviation between channels" is selected.
Page 110 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value 0: MV in Auto mode is used. MV transfer function [Balanceless-bumpless function] [Action taken when changed to Manual mode 1: MV in previous Manual mode is used.
Page 111 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value −5.0 Output limiter (low) −5.0 % to Output limiter (high) [heat-side] ♣ Position proportioning control: Becomes valid only when there is feedback resistance (FBR) input and it does not break.
Page 112 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value Integral time limiter (high) PID control or heat/cool PID control: 3600 [heat-side] ♣ 0 to 3600 seconds or 0.0 to 1999.9 seconds Position proportioning control: PID control, Integral time limiter (low)
Page 113 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value ST derivative time 0.01 to 10.00 times 1.00 adjusting factor ♣ ST start condition 0: Activate the startup tuning (ST) function when the ♣...
Page 114 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value −1 −1 Remote SV function (Master channel is selected from itself) master channel module 0 to 99 (Master channel is selected from other modules) address Remote SV function 1 to 99...
Page 115 6. HOST COMMUNICATION Communication data of Z-DIO module Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value  Digital input (DI) state 1 Least significant digit: DI1 state 2nd digit: DI2 state 3rd digit: DI3 state 4th digit: DI4 state 5th digit to Most significant digit: Unused...
Page 116 6. HOST COMMUNICATION Continued from the previous page. Iden Attri- Struc- Factory Name DIgits Data range tifier bute ture set value −1, 0 to 99 DO signal assignment −1 module address 2 When “-1” is selected, all of the signals of the same type (except temperature rise completion and DO manual output [DO5 to DO8] value) are OR-operated and produced as outputs from DO.
Page 117 6. HOST COMMUNICATION Table 1: DI assignment table Set value No assignment AUTO/MAN REM/LOC Interlock release EDS start signal 1 Soak stop RUN/STOP REM/LOC AUTO/MAN EDS start signal 1 Operation mode Soak stop RUN/STOP EDS start signal 1 REM/LOC Soak stop RUN/STOP Memory area transfer (1 to 8) Area set...
Page 118 6. HOST COMMUNICATION Table 2: DO assignment table [DO1 to DO4] Set value No assignment DO1 manual output DO2 manual output DO3 manual output DO4 manual output Event 1 comprehensive output Event 2 comprehensive output Event 3 comprehensive output Event 4 comprehensive output Event 1 (CH1) Event 2 (CH1) Event 3 (CH1)
Page 119: Modbus Communication Protocol
Slave address The slave address is a number from 0 to F manually set at the address setting switch located at the front of Z-COM module. For details, see 3.2.1 SRZ unit address setting (P. 3-3). Although all connected slave units receive the query message sent from the master, only the slave with the slave address coinciding with the query message will accept the message.
Page 120: Function Code
6. HOST COMMUNICATION 6.5.2 Function code Function code contents Function code Function Contents (Hexadecimal) Read holding registers Measured value, control output value, current transformer input measured value, Event status, etc. Preset single register Set value, PID constants, event set value, etc. Diagnostics (loopback test) Loopback test Preset multiple registers...
Page 121: Slave Responses
6. HOST COMMUNICATION 6.5.4 Slave responses (1) Normal response • In the response message of the Read Holding Registers, the slave returns the read out data and the number of data items with the same slave address and function code as the query message. •...
Page 122: Calculating Crc-16
6. HOST COMMUNICATION 6.5.5 Calculating CRC-16 The Cyclic Redundancy Check (CRC) is a 2 byte (16-bit) error check code. After constructing the data message, not including start, stop, or parity bit, the master calculates a CRC code and appends this to the end of the message.
Page 123 6. HOST COMMUNICATION The flow chart of CRC-16 START FFFFH → CRC Register CRC Register ⊕ next byte of the message → CRC Register 0 → n Shift CRC Register right 1 bit Carry flag is 1 CRC Register ⊕ A001H → CRC Register n + 1 →...
Page 124 6. HOST COMMUNICATION Example of a CRC calculation in the ‘C’ language This routine assumes that the data types ‘uint16’ and ‘uint8’ exists. Theses are unsigned 16-bit integer (usually an ‘unsigned short int’ for most compiler types) and unsigned 8-bit integer (unsigned char). ‘z_p’ is a pointer to a Modbus message, and ‘z_messaage_length’...
Page 125: Message Format
6. HOST COMMUNICATION 6.5.6 Message format Read holding registers [03H] The query message specifies the starting register address and quantity of registers to be read. The contents of the holding registers are entered in the response message as data, divided into two parts: the high-order 8-bit and the low-order 8-bit, arranged in the order of the register numbers.
Page 126 6. HOST COMMUNICATION Preset single register [06H] The query message specifies data to be written into the designated holding register. The write data is arranged in the query message with high-order 8-bit first and low-order 8-bit next. Only R/W holding registers can be specified.
Page 127 6. HOST COMMUNICATION Diagnostics (Loopback test) [08H] The master’s query message will be returned as the response message from the slave (SRZ unit). This function checks the communication system between the master and slave (SRZ unit). Example: Loopback test for slave address 1 Query message Slave address Function code...
Page 128 6. HOST COMMUNICATION Preset multiple registers [10H] The query message specifies the starting register address and quantity of registers to be written. The write data is arranged in the query message with high-order 8-bit first and low-order 8-bit next. Only R/W holding registers can be specified. Example : Data is written into the two holding registers from 0ADCH to 0ADDH of slave address 1.
Page 129: Data Configuration
FFFFH represents −1. Data processing with decimal points (1) Communication data of Z-COM module The communication data of the Z-COM module does not include any data with decimal points. Communication data of Z-COM module Integrated operating time monitor (Z-COM module)
Page 130 6. HOST COMMUNICATION Caution for handling communication data • In this communication, the variables that memory area includes handles different address with for control area and for setting area. • If data (holding register) exceeding the accessible address range is accessed, an error response message is returned.
Page 131 6. HOST COMMUNICATION How to use memory area data Memory area function can store up to 8 individual sets of SVs and parameters. One of the areas is used for control, and the currently selected area is “Control area.” Memory area data can be used to check and change settings that belong to memory areas other than the control area.
Page 132 6. HOST COMMUNICATION [Example 1] When data on the Event 1 set value in Memory area 2 of CH1 is read 1. The memory area number, “2” is written to the CH1 setting memory area number (386CH). Data in Memory area 2 is called up to the CH1 register addresses. CH1 register addresses Setting memory area number 386CH...
Page 133 6. HOST COMMUNICATION Control area transfer Any memory area used for control is specified by the memory area transfer (08DCH to 091BH). The area (095CH to 0E5BH) now used for control is called “Control area.” The memory area number (control area) can be changed at either RUN or STOP. Register address CH64 Memory area transfer...
Page 134 • If data in the control area is changed, data in the memory area is also changed. • If data in the memory area is changed, data in the control area is also changed. Data mapping function When using a Z-COM module joined to functional modules, the data mapping function cannot be used. 6-70 IMS01T07-E1...
Page 135: Modbus Communication Data List
Factory Name Data range bute ture set value  Error code 0000 Bit data (Z-COM module) Adjustment data error Data back-up error A/D conversion error Unused Unused Logic output data error b6 to b15: Unused Data 0: OFF 1: ON [Decimal number: 0 to 63] The error condition is shown by the OR of each module.
Page 136 (7) Factory set value: Factory set value of communication data Some of the communication data of the Z-COM module will not be enabled until the power is turned on again, or control is switched from STOP to RUN. Communication data No. 14 to 34 Communication includes both “Normal setting data”...
Page 137 • No. 11 to 15: System data (monitoring item) for PLC communication • No. 27 to 35, 37: System data (setting item) for PLC communication For the communication data of Z-COM module, see Chapter 8 Communication data description (P. 8-1). Register address...
Page 138 6. HOST COMMUNICATION Continued from the previous page. Register address Chan- Attri- Struc- Factory Name Data range bute ture set value  PLC communication error 00CC Bit data code PLC register read/write error Slave communication timeout Unused Internal communication error Master communication timeout b5 to b15: Unused Data...
Page 139 6. HOST COMMUNICATION Register address Chan- Attri- Struc- Factory Name Data range bute ture set value 0: RKC communication Communication 2 8004 32772 1: Modbus protocol 2: MITSUBISHI MELSEC series special protocol A compatible, 1C frame (type 4), AnA/AnUCPU common command (QR/QW), AnA/QnA series, Q series QnA compatible, 3C frame (type 4), command (0401/1401) Only ZR register...
Page 140  Number of connected 8013 32787 0 to 16 modules This is the maximum address of the Z-TIO (Z-TIO module) module that is connected to the Z-COM module.  Number of connected 8014 32788 0 to 16 modules This is the maximum address of the Z-DIO...
Page 141 6. HOST COMMUNICATION Communication data of Z-TIO module For details of Z-TIO module communication data, see SRZ Instruction Manual (IMS01T04-E ). Register address Chan- Attri- Struc- Factory Name Data range bute ture set value  Measured value (PV) 01FC Input scale low to Input scale high ·...
Page 142 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value  Burnout state monitor 040C 1036 0: OFF · · · 1: ON · · · · · · CH64 044B 1099...
Page 143 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value      Unused 064C 1612 · · · · · · 080B 2059 PID/AT transfer 080C 2060 0: PID control ·...
Page 144 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Proportional band 0B1C 2844 TC/RTD:30 TC/RTD inputs: · · · [heat-side] V/I: 30.0 0 (0.0) to Input span (Unit: °C [°F]) ·...
Page 145 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Manual reset ★ 0D1C 3356 −100.0 to +100.0 % · · · · · · If the integral function is valid, set to RO (Only ·...
Page 146 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value −Input span to +Input span RS bias * 101C 4124 · · · · · · · · · CH64 105B 4187...
Page 147 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value EDS mode 129C 4764 0: No function · · · (for disturbance 1) 1: EDS function mode · · ·...
Page 148 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Startup tuning (ST) 165C 5724 0: ST unused · · · 1: Execute once · · · · · ·...
Page 149 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Decimal point position 19EC 6636 0: No decimal place Depends on · · · 1: One decimal place · ·...
Page 150 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Event 1 type 1C2C 7212 0: None Depends on · · · 1: Deviation high (Using SV monitor value) model code ·...
Page 151 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Event 2 type 1DEC 7660 0: None Depends on · · · 1: Deviation high (SV monitor value used) model code ·...
Page 152 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Event 3 type 1FAC 8108 0: None Depends on · · · 1: Deviation high (SV monitor value used) model code ·...
Page 153 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value 216C 8556 0: None Depends on Event 4 type · · · 1: Deviation high (SV monitor value used) model code ·...
Page 154 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value CT ratio 232C 9004 0 to 9999 CTL-6-P-N: · · · · · · · · · CTL-12-S56- CH64 236B 9067 10L-N:...
Page 155 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Derivative gain ♣ 262C 9772 0.1 to 10.0 · · · · · · · · · CH64 266B 9835 266C 9836...
Page 156 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Output limiter (high) 29AC 10668 Output limiter (low) [cool-side] to 105.0 % 105.0 · · · [cool-side] · · ·...
Page 157 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Proportional band limiter 2CEC 11500 TC/RTD inputs: TC/RTD: · · · 0 (0.0) to Input span (Unit: °C [°F]) (high) [heat-side] ·...
Page 158 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Control motor time 30AC 12460 5 to 1000 seconds · · · ♣ · · · · · · CH64 30EB 12523...
Page 159 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Setting change rate limiter 33EC 13292 1 to 3600 seconds · · · unit time · · · · ·...
Page 160 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value −1 −1 203 Address of interacting 36EC 14060 (Interact with its own module address) · · · modules · ·...
Page 161 6. HOST COMMUNICATION Communication data of Z-DIO module For details of Z-DIO module communication data, see SRZ Instruction Manual (IMS01T04-E ). Register address Chan- Attri- Struc- Factory Name Data range bute ture set value  3E6C 15980 Bit data Digital input (DI) state ·...
Page 162 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value DO minimum ON/OFF 41EC 16876 0 to 1000 ms · · · time of proportioning · · · · ·...
Page 163 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Z-DIO Interval time 469C 18076 0 to 250 ms · · · · · · · · · CH16 46AB 18091 ...
Page 164 6. HOST COMMUNICATION Table 1: DI assignment table Set value No assignment AUTO/MAN REM/LOC Interlock release EDS start signal 1 Soak stop RUN/STOP REM/LOC AUTO/MAN EDS start signal 1 Operation mode Soak stop RUN/STOP EDS start signal 1 REM/LOC Soak stop RUN/STOP Memory area transfer (1 to 8) Area set...
Page 165 6. HOST COMMUNICATION Table 2: DO assignment table [DO1 to DO4] Set value No assignment DO1 manual output DO2 manual output DO3 manual output DO4 manual output Event 1 comprehensive output Event 2 comprehensive output Event 3 comprehensive output Event 4 comprehensive output Event 1 (CH1) Event 2 (CH1) Event 3 (CH1)
Page 166 6. HOST COMMUNICATION Memory area data address (Z-TIO) The register addresses, 386CH to 3DABH are used for checking and changing each set value belonging to the memory area. Register address Chan- Attri- Struc- Factory Name Data range bute ture set value Setting memory area 386C 14444...
Page 167 6. HOST COMMUNICATION Continued from the previous page. Chan- Register address Attri- Struc- Factory Name Data range bute ture set value Proportional band 3B6C 15212 TC/RTD inputs: TC/RTD: 30 · · · [cool-side] 1 to Input span or 0.1 to Input span V/I: 30.0 ·...
Page 168 MEMO 6-104 IMS01T07-E1...
Page 169 COMMUNICATION 7.1 PLC Communication Outline.............7-2 7.2 MITSUBISHI MELSEC Series ............7-3 7.2.1 Outline .......................7-3 7.2.2 Wiring ......................7-5 7.2.3 PLC communication environment setting ..........7-11 7.2.4 Setting on the PLC (Computer link module) ..........7-18 7.3 OMRON SYSMAC Series ...............7-19 7.3.1 Outline .....................7-19 7.3.2 Wiring ......................7-21 7.3.3 PLC communication environment setting ..........7-25 7.3.4 Setting on the PLC ..................7-29 7.4 Data Transfer..................7-30...
Page 170: Plc Communication
7. PLC COMMUNICATION 7.1 PLC Communication Outline Communication system for Z-COM module contains “Communication 1 (COM. PORT1, COM. PORT2)” and “Communication 2 (COM. PORT3, COM. PORT4).” Communication 2 (COM. PORT3, COM. PORT4) can be used for PLC communication. There is isolation between Z-COM module internal block diagram “Communication 1”...
Page 171: Mitsubishi Melsec Series
7. PLC COMMUNICATION 7.2 MITSUBISHI MELSEC Series 7.2.1 Outline The SRZ unit can be connected to the MITSUBISHI MELSEC series computer link module without using any program. SRZ unit 1 MITSUBISHI MELSEC series (Unit address 0) RS-422A or RS-485 Up to four SRZ units can be connected SRZ unit 2 RS-422A to a PLC communication port.
Page 172 Digital I/O module Z-DIO-A Up to 31 functional modules can be connected to one Z-COM module. For the joinable number of functional modules, see 4.3 Joinable Number of Modules (P. 4-6). For functional module, see Instruction Manual of the following.
Page 173: Wiring
7. PLC COMMUNICATION 7.2.2 Wiring WARNING To prevent electric shock or instrument failure, turn off the power before connecting or disconnecting the instrument and peripheral equipment. CAUTION Connect connectors correctly in the right position. If it is forcibly pushed in with pins in the wrong positions, the pins may be bent resulting in instrument failure.
Page 174 R (B) Signal ground Send data T (B) Send data T (A) Signal ground The 6-pin type modular connector should be used for the connection to the Z-COM module. Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD., ) IMS01T07-E1...
Page 175 * COM. PORT3 and COM. PORT4 are internally connected. When preparing a cable of connecting the computer link module belonging to the MITSUBISHI MELSEC series to our Z-COM module, cross each pair of wires the A and B terminal positions on their terminal boards are not symmetrical.
Page 176 T/R (A) Send/receive data T/R (B) Signal ground  Unused  Unused Signal ground The 6-pin type modular connector should be used for the connection to the Z-COM module. Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD., ) IMS01T07-E1...
Page 177 * COM. PORT3 and COM. PORT4 are internally connected. When preparing a cable of connecting the computer link module belonging to the MITSUBISHI MELSEC series to our Z-COM module, cross each pair of wires the A and B terminal positions on their terminal boards are not symmetrical.
Page 178 SRZ unit. Cable type: W-BF-02-3000 (Sold separately) [Standard cable length: 3 m] COM. PORT3 and COM. PORT4 are internally connected. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). 7-10 IMS01T07-E1...
Page 179: Plc Communication Environment Setting
7. PLC COMMUNICATION 7.2.3 PLC communication environment setting The PLC communication environmental (system data) settings must be made to perform PLC communication. The system data settings are made by the host communication or loader communication. The system data contains setting items and monitor items. The monitor items require space in the PLC register.
Page 180 7. PLC COMMUNICATION (1) System data (setting items) list The following items are set to the SRZ unit. The following items become valid by turning off the power of the SRZ unit once, and then turning it on again after the settings are changed. The items will also become valid by switching control from STOP to RUN.
Page 181 7. PLC COMMUNICATION Continued from the previous page. Factory Register address Iden- Name Digits Data range tifier value System data address 800D 32781 0 to 65535 2100 bias When the SRZ unit is connected in a multi-drop connection, a bias is set for the register addresses of each unit so that no address duplication occurs.
Page 182 7. PLC COMMUNICATION Changing the register type The register type used for PLC communication can be changed. The factory set value is set to D register (data register). Setting method of the register start number The start number of the register used for PLC communication can be changed. The factory set value is start from D01000 of the D register (data register).
Page 183 7. PLC COMMUNICATION System data address bias and Slave mapping method When the SRZ unit is connected in a multi-drop connection, a bias can be set to prevent duplication of register addresses. Setting the slave mapping method and the system data address bias prevents duplication of register addresses of each unit by the address setting switch.
Page 184 7. PLC COMMUNICATION Continued from the previous page. 2. Change the SRZ unit address by the address setting switch. The register address bias is enabled and there is no longer duplication of register addresses. PLC communication data (Details of data map) Unit address 0 Name Register address...
Page 185 0: Before data collection is completed 1: Data collection is completed [Decimal number: 0, 1] This is the communication data collection state of the functional module joined to the Z-COM module. 0/1 transfer SRZ normal D01001  (For communication checking) communication flag “0”...
Page 186: Setting On The Plc (Computer Link Module)
Item Description Protocol Type 4 protocol mode Station number Computer link/multi-drop Computer link selection Communication rate Set the same as SRZ unit (Z-COM module) Operation setting Independent Data bit Parity bit Without Stop bit Sum check code Provided Writing during RUN...
Page 187: Omron Sysmac Series
7. PLC COMMUNICATION 7.3 OMRON SYSMAC Series 7.3.1 Outline The SRZ unit can be connected to the OMRON SYSMAC series computer link module without using any program. PLC OMRON SRZ unit 1 SYSMAC series (Unit address 0) RS-422A Up to four SRZ units can be connected SRZ unit 2 to a PLC communication port.
Page 188 Digital I/O module Z-DIO-A Up to 31 functional modules can be connected to one Z-COM module. For the joinable number of functional modules, see 4.3 Joinable Number of Modules (P. 4-6). For function module, see Instruction Manual of the following.
Page 189: Wiring
7. PLC COMMUNICATION 7.3.2 Wiring WARNING To prevent electric shock or instrument failure, turn off the power before connecting or disconnecting the instrument and peripheral equipment. CAUTION Connect connectors correctly in the right position. If it is forcibly pushed in with pins in the wrong positions, the pins may be bent resulting in instrument failure.
Page 190 7. PLC COMMUNICATION RS-422A Z-COM module OMRON SYSMAC series W-BF-01 Blue T (A) Black T (B) White R (A) Connect to the COM. PORT3 Orange R (B) Cable type: W-BF-01-3000 (RKC product, Sold separately) [Standard cable length: 3 m] Connection cable W-BF-01 * (RKC product) can use to connect the PLC.
Page 191 COM. PORT4 * * COM. PORT3 and COM. PORT4 are internally connected. The 6-pin type modular connector should be used for the connection to the Z-COM module. Recommended model: TM4P-66P (Manufactured by HIROSE ELECTRIC CO., LTD., ) Customer is requested to prepare a communication cable fit for the control unit to be connected by the PLC.
Page 192 SRZ unit. Cable type: W-BF-02-3000 (Sold separately) [Standard cable length: 3 m] COM. PORT3 and COM. PORT4 are internally connected. For the termination resistor of Z-COM module, see 6.2.4 Termination resistor of Z-COM module (P. 6-13). 7-24 IMS01T07-E1...
Page 193: Plc Communication Environment Setting
7. PLC COMMUNICATION 7.3.3 PLC communication environment setting The PLC communication environmental (system data) settings must be made to perform PLC communication. The system data settings are made by the host communication or loader communication. The system data contains setting items and monitor items. The monitor items require space in the PLC register.
Page 194 7. PLC COMMUNICATION (1) System data (setting items) list The following items are set to the SRZ unit. The following items become valid by turning off the power of the SRZ unit once, and then turning it on again after the settings are changed. The items will also become valid by switching control from STOP to RUN.
Page 195 7. PLC COMMUNICATION Continued from the previous page. Factory Iden- Register address Name Digits Data range tifier value COM module link 800E 32782 0 to 255 seconds recognition time When connecting two or more SRZ units, set the time required until a unit after the second module is recognized.
Page 196 0: Before data collection is completed 1: Data collection is completed [Decimal number: 0, 1] This is the communication data collection state of the functional module joined to the Z-COM module. 0/1 transfer  SRZ normal D01001 (For communication checking) communication flag “0”...
Page 197: Setting On The Plc
Unit number (Model number) Start bit Data bit Stop bit Parity bit Even Transmission speed Set the same as SRZ unit (Z-COM module) I/O port selection RS-422A Synchronization selection Internal synchronization CTS selection 0 V (always ON) 5 V supply...
Page 198: Data Transfer
7. PLC COMMUNICATION 7.4 Data Transfer 7.4.1 PLC communication data transfer The data transmitted between the PLC and the SRZ unit is compiled in the PLC communication data map (hereafter, called data map). In the PLC communication data map the communication data is classified into system data (monitor items), request command, monitor group, and setting group.
Page 199 7. PLC COMMUNICATION Setting request bit (PLC → SRZ) This command requests that the SRZ unit read the communication data of the setting group on the PLC side. [Processing] 1. When the setting request bit of the request command (D01008) is set to “1,” the SRZ unit starts to read the communication data of the setting group from the PLC.
Page 200 7. PLC COMMUNICATION 4. The setting request bit will change to “0” to indicate that reading of data from the PLC is finished. SRZ unit System data (Monitor items) Monitor group Various communication data Setting group The SRZ unit writes “0” to the setting request bit.
Page 201 7. PLC COMMUNICATION 3. When writing is finished, the SRZ unit writes the communication state of the setting group to the monitor completed bit of setting item (Group 2) communication state. SRZ unit System data (Monitor items) Monitor group Various communication data Setting group...
Page 202 7. PLC COMMUNICATION (PLC ← SRZ) Monitor group The communication data of the monitor group does not have a request command setting. The SRZ unit regularly repeats writing of communication data to the PLC each communication period. Note that writing of monitor group data is stopped while the setting group reads or writes by request command.
Page 203: Data Transfer Procedures
Turn on power of functional modules (Z-TIO and Z-DIO modules) joined to the each instrument Z-COM module starts. In addition, writing of the system data (monitor items) begins after the PLC communication start time (factory set value is 5 seconds) has passed.
Page 204 7. PLC COMMUNICATION When the setting group communication data is transferred from PLC to the SRZ unit. Start Set temperature set value (SV) and other setting data to each register (memory) in the PLC. [Data setting] Set “1” to the setting request bit When the setting request bit of the request command of the PLC of request command.
Page 205 7. PLC COMMUNICATION When writing is finished, the SRZ unit writes the communication Monitor completed bit of the state of the setting group to the monitor completed bit of the setting item (Group 2) setting item (Group 2) communication state of the PLC. communication state = 1 If the monitor request bit of the request command of the PLC Monitor request bit...
Page 206: Data Processing Precautions
7. PLC COMMUNICATION 7.4.3 Data processing precautions The data type is treated as binary data with a sign and without a decimal point. For this reason, carefully express and set the data. [Example] Setting of proportional band Initial value of internal data: 3.0 Communication data: Any attempt to write to an unused channel is not processed as an error.
Page 207: Plc Communication Data Map
7. PLC COMMUNICATION 7.5 PLC Communication Data Map The data map summarizes data addresses, channels and names which enable PLC communication. Reference to data map Register Struc- Attri- Data range and Factory Name address ture bute Number of data set value ...
Page 208 7. PLC COMMUNICATION Continued from the previous page. 1, 2 (3) Structure: C: Data for each channel M: Data for each module U: Data for each SRZ unit On a Z-TIO module (2-channel type), there is no communication data for the 3rd and 4th channels. ♣: Parameters only used for heat/cool control, therefore data for CH2 and CH4 are unused.
Page 209 1: ON [Decimal number: 0 to 31] When the power of the SRZ unit is turned on, the Z-COM module begins collecting the data of the connected Z-TIO and Z-DIO modules. When system communication state becomes “1,” PLC communication can be performed.
Page 210 [Decimal number: 0 to 15]  Monitor for the number of D01006 0 to 31 connected modules (DM01006) Number of functional modules connected to one Z-COM module.     D01007 Internal processing (DM01007) Do not use the register address...
Page 211 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value  Setting item (Group 2) D01009 Bit data communication state (DM01009) b0: Setting error b1: Setting completed bit b2: Monitor completed bit Data 0: OFF...
Page 212 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value  Operation mode state D01138 to Bit data monitor D01201 b0: Control STOP (D01138 to b1: Control RUN DM01201) b2: Manual mode (Including Remote mode)
Page 213 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value  Remote setting (RS) input D01458 to Setting limiter (low) to value monitor D01521 Setting limiter (high) (DM01458 to DM01521) [64]...
Page 214 [Decimal number: 0 to 255] * These are error code only of the Z-COM module Each digital output (DO) state of the Z-DIO module is expressed in bit data items. The digital output (DO) state is assigned as a bit image in binary numbers.
Page 215 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value PID/AT transfer D01571 to 0: PID control D01634 1: Autotuning (AT) (DM01571 to DM01634) [64] Activation or deactivation of the Autotuning (AT) function is selected. Caution for using the autotuning (AT) •...
Page 216 7. PLC COMMUNICATION Continued from the previous page. Parameters for autotuning (AT) are provided to compute the PID values suitable for various controlled systems and control actions. Set them, as required. Example 1: When you want to find each constant suited for P control, PI control, or PD control by autotuning. For P control: Set “0”...
Page 217 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value TC/RTD inputs: Proportional band D02019 to TC/RTD: 30 0 (0.0) to Input span [heat-side] D02082 (Unit: ° C [ ° F]) ♣...
Page 218 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value Derivative time [cool-side] D02339 to 0 to 3600 seconds or ♣ D02402 0.0 to 1999.9 seconds (DM02339 to (0, 0.0: PI action) DM02402...
Page 219 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value 0 (0.0) to Input span/unit time Setting change rate limiter D02531 to 0 (0.0) 0 (0.0): Unused (up) D02594 (DM02531 to...
Page 220 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value − Input span to + Input span PV bias D02851 to D02914 (DM02851 to PV bias adds bias to the measured DM02914) value (PV).
Page 221 7. PLC COMMUNICATION Continued from the previous page. Register Struc- Attri- Data range and Factory set Name address ture bute Number of data value DO manual output 1 * D03043 to Bit data D03058 b0: DO1 manual output (DM03043 to b1: DO2 manual output DM03058) b2: DO3 manual output...
Page 222: Usage Example
See the instruction manual for the used host computer. SRZ unit setting See 7.6.3 SRZ unit setting (P. 7-57). For information on joining the Z-COM module to functional Mounting and Wiring modules and mounting, see Chapter 4, “MOUNTING” (P. 4-1).
Page 223 7. PLC COMMUNICATION See 7.6.7 PLC setting (P. 7-64). PLC setting See 7.6.8 Initial setting (P. 7-66). Initial setting Data setting See 7.6.9 Data setting (P. 7-67). 7-55 IMS01T07-E1...
Page 224: System Configuration
Connection cable for connecting SRZ unit and host computer W-BF-02-3000 (RKC product, Sold separately) [Standard cable length: 3 m] ..1 W-BF-28-3000 (RKC product, Sold separately) [Standard cable length: 3 m] ..1 Termination resistors Termination resistor for Z-COM W-BW-02 [for RS-422A] (RKC product)....2 7-56 IMS01T07-E1...
Page 225: Srz Unit Setting
7.6.3 SRZ unit setting (1) SRZ unit address setting Set the SRZ unit address by address setting switch of front of Z-COM module. For this setting, use a small blade screwdriver. In this application, make the setting as follows. (SRZ unit address: 0)
Page 226 7. PLC COMMUNICATION (3) Communication setting of the Z-COM module Conduct the host communication and PLC communication settings by the DIP switch. DIP switch Z-COM module (Right side view) PLC communication Setting contents setting switch Communication speed (Host communication): 19200 bps...
Page 227: Connection To Host Computer
7. PLC COMMUNICATION 7.6.4 Connection to host computer Connect a SRZ unit to converter COM-A and host computer by connection cable. In addition, connect a termination resistor for Z-COM to the COM. PORT2. RS-232C/RS-422A converter Z-COM module COM-A Communication cable...
Page 228: Setting Of The Plc Communication Environmental Setting
(1) Turn on the power of the host computer and SRZ unit The Z-COM module starts collecting data on function modules (Z-TIO and Z-DIO modules) jointed from the time when the power is turned on. Data collection takes about 8 seconds.
Page 229 The SRZ unit occupies a number of PLC registers equal to the maximum number of data items. Even if there are fewer functional modules (Z-TIO/Z-DIO modules) connected to the Z-COM module, or there are unused communication items, the number of registers occupied does not change. If functional modules (Z-TIO/Z-DIO modules) are not connected or there are unused data items, “0”...
Page 230 7. PLC COMMUNICATION Continued from the previous page. Register address Communication item D01955 to D01970 Set value (SV) CH1 to CH16 D01971 to D02018 Unused CH17 to CH64 D02019 to D02034 Proportional band [heat-side] CH1 to CH16 D02035 to D02082 Unused CH17 to CH64 D02083 to D02098...
Page 231 7. PLC COMMUNICATION (3) Setting SRZ setting data by host communication The host computer is used to set communication data of functional modules (Z-TIO/Z-DIO modules) that cannot be set by PLC communication (engineering data, operation data, etc.). If the control is the control start (RUN), transfer the control stop (STOP). Engineering data can only be set in functional modules (Z-TIO and Z-DIO modules) when the SRZ unit is stopped.
Page 232: Plc Setting
7. PLC COMMUNICATION 7.6.7 PLC setting (5) Power on the PLC Turn on the power of the PLC. (6) Conduct the PLC setting Set the Serial communication module of MITSUBISHI MELSEC Q series as follows. Setting item Description Setting item Description Operation setting Independent...
Page 233 7. PLC COMMUNICATION Continued from the previous page. • Description Switches 1 to 5 Switch number Description b15 to b8 b7 to b0 Switch 1 CH1 Communication rate setting CH1 Transmission setting Switch 2 CH1 Communication protocol setting b15 to b8 b7 to b0 Switch 3 CH2 Communication rate setting...
Page 234: Initial Setting
Start Turn on the power of the SRZ unit, the PLC, and the host Turn on power of computer. The Z-COM module starts collecting data on each instrument function modules (Z-TIO and Z-DIO modules) jointed from the time when the power is turned on.
Page 235: Data Setting
7. PLC COMMUNICATION 7.6.9 Data setting It is assumed that initial setting is finished. If each set value of SRZ unit is changed from the PLC without setting the initial values, it is re-written to 0 with each set value of the PLC at that time set to 0. Setting example When set the set value (SV) of SRZ unit as follows: Set value (SV): CH1 = 100 CH2 = 100 CH3 = 110 CH4 = 110 CH5 = 120 CH6 = 120...
Page 236 7. PLC COMMUNICATION When reading of the setting group data ends, the SRZ unit Setting completed bit (bit 0) writes the setting group communication state to the setting of the setting item (Group 2) completed bit (bit 1) of PLC setting item (Group 2) communication state communication state (D01009).
Page 237: Communication Data Description
COMMUNICATION DATA DESCRIPTION 8.1 Reference to Communication Data Contents ........8-2 8.2 Communication Data of Z-COM Module ..........8-3 IMS01T07-E1...
Page 238: Reference To Communication Data Contents
8. COMMUNICATION DATA DESCRIPTION 8.1 Reference to Communication Data Contents RUN/STOP transfer RKC communication (Each SRZ unit) identifier 0133H (307) Modbus register address Control RUN/STOP is switched for each SRZ unit. Attribute: Digits: 1 digit Number of data: 1 (Data of each SRZ unit) Data range: 0: STOP (control stop) 1: RUN (control start)
Page 239: Communication Data Of Z-Com Module
Model code (Functional module) RKC communication identifier  Modbus register address This value is the type identifier code of the Z-TIO/Z-DIO module joined to the Z-COM module. Attribute: Digits: 32 digits Number of data: 100 (Data of each module) ...
Page 240 ROM version (Functional module) RKC communication identifier  Modbus register address This value is a version of the ROM on the Z-TIO/Z-DIO module joined to the Z-COM module. Attribute: Digits: 8 digits Number of data: 100 (Data of each module)
Page 241 Program error (stack) * bit 7 Watchdog timer error * bit 8 to bit 15 Unused * These are error items only of the Z-COM module. RKC communication (ASCII code data) Adjustment data error Data back-up error A/D conversion error...
Page 242 Modbus ch1: 0001H (1) to register address ch100: 0064H (100) Each error state of the Z-TIO/Z-DIO module joined to the Z-COM module is expressed in bit data items. Attribute: Digits: 7 digits Number of data: 100 (Data of each module)
Page 243 RKC communication (Z-COM module) identifier Modbus 0065H (101) register address Allows the state of the contents of the RAM and backup memory (FRAM) of the Z-COM module to be checked. Attribute: Digits: 1 digit Number of data: 1 (Data of each SRZ unit) Data range: 0: The content of the backup memory does not coincide with that of the RAM.
Page 244 Syetem data (monitor items) register address When the power is turned on, collects data of the functional modules joined to the Z-COM module. When data collection ends, the system communication state changes to “1.” When system communication state becomes “1,” PLC communication can be performed.
Page 245 8. COMMUNICATION DATA DESCRIPTION PLC communication error code RKC communication identifier Modbus 00CCH (204) Syetem data (monitor items) register address Indicates an error state of PLC communication by bit data. Error code type • PLC register read/write error Turns ON when it is not possible to read from or write to the PLC register. Three seconds after the normal communication state is restored, this turns OFF.
Page 246 RKC communication identifier Modbus 0132H (306) Syetem data (monitor items) register address This value is the number of the Z-TIO/Z-DIO module joined to the Z-COM module. Attribute: Digits: 7 digit Number of data: 1 (Data of each SRZ unit) Data range: 0 to 31 ...
Page 247 8. COMMUNICATION DATA DESCRIPTION RUN/STOP transfer (Each SRZ unit) RKC communication identifier Modbus 0133H (307) register address Control RUN (control start)/STOP (control stop) is transferred for each SRZ unit. Attribute: Digits: 1 digit Number of data: 1 (Data of each SRZ unit) Data range: 0: STOP (control stop) 1: RUN (control start)
Page 248 8. COMMUNICATION DATA DESCRIPTION Control RUN/STOP holding setting RKC communication identifier Modbus ch1: 0198H (408) to register address ch100: 01BFH (507) It is set whether or not the operation mode before the power supply is turned off is held when the power supply is turned on or power failure recovers.
Page 249 8. COMMUNICATION DATA DESCRIPTION Communication 1 communication speed RKC communication identifier Modbus 8001H (32769) register address Use to set a communication speed of communication 1 via host communication or loader communication. Attribute: Digits: 1 digit Number of data: 1 (Data of each SRZ unit) Data range: 0: 4800 bps 1: 9600 bps...
Page 250 8. COMMUNICATION DATA DESCRIPTION Communication 2 protocol RKC communication identifier Modbus 8004H (32772) register address Use to set a protocol of communication 2 via host communication or loader communication. Attribute: Digits: 1 digit Number of data: 1 (Data of each SRZ unit) Data range: 0: RKC communication 1: Modbus...
Page 251 8. COMMUNICATION DATA DESCRIPTION Communication 2 data bit configuration RKC communication identifier Modbus 8006H (32774) register address Use to set a data bit configuration of communication 2 via host communication or loader communication. Attribute: Digits: 7 digits Number of data: 1 (Data of each SRZ unit) Data range: 0 to 11...
Page 252 8. COMMUNICATION DATA DESCRIPTION PC number RKC communication identifier Modbus 8009H (32777) System data (setting items) register address Set the PLC PC number. Set it to the same number as the PLC. Attribute: Digits: 7 digits Number of data: 1 (Data of each SRZ unit) Data range: 0 to 255 Factory set value:...
Page 253 8. COMMUNICATION DATA DESCRIPTION Register start number (High-order 4-bit) RKC communication identifier Modbus 800BH (32779) System data (setting items) register address Set the start number of the register used in PLC communication. Set this if the register address 65535 is exceeded in the ZR register.
Page 254 8. COMMUNICATION DATA DESCRIPTION COM module link recognition time RKC communication identifier Modbus 800EH (32782) System data (setting items) register address When connecting two or more SRZ units, set the time required until a unit after the second module is recognized.
Page 255 System data (setting items) register address The Z-COM module calculates the number of channels of communication data during RKC communication, and thus the maximum module address of each functional module is set in the number of connected modules (identifier: QY, QU). Select the setting method for this operation.
Page 256 8013H (32787) register address This is the maximum address of Z-TIO modules joined to the Z-COM module. The setting method can be selected using “Method for setting the number of connected modules” (identifier RY). The maximum module address that is set will be the maximum value + 1 of the address setting switch of the Z-TIO module.
Page 257: Trouble Shooting
TROUBLE SHOOTING 10.1 Solutions for Problems..............9-2 IMS01T07-E1...
Page 258 9. TROUBLESHOOTING Solutions for Problems This section explains probable causes and treatment procedures if any abnormality occurs in the instrument. For any inquiries, please contact RKC sales office or the agent, to confirm the specifications of the product. If it is necessary to replace a device, always strictly observe the warnings below. WARNING To prevent electric shock or instrument failure, always turn off the system power before replacing the instrument.
Page 259 9. TROUBLESHOOTING Each module Problem Probable cause Solution FAIL/RUN lamp does not Power not being supplied Check external breaker etc. light up Appropriate power supply voltage Check the power supply not being supplied Power supply terminal contact Retighten the terminals defect Power supply section defect Replace module...
Page 260 PLC • If the communication settings of communicate normally, but Z-COM module are set via host monitor value is not or loader communications, transferred to PLC confirm the communication •...
Page 261 9. TROUBLESHOOTING RKC communication Problem Probable cause Solution No response Wrong connection, no connection or Confirm the connection method or disconnection of the communication cable condition and connect correctly Breakage, wrong wiring, or imperfect contact Confirm the wiring or connector and repair of the communication cable or replace the wrong one Mismatch of the setting data of...
Page 262 9. TROUBLESHOOTING Modbus Problem Probable cause Solution No response Wrong connection, no connection or Confirm the connection method or condition disconnection of the communication cable and connect correctly Breakage, wrong wiring, or imperfect contact Confirm the wiring or connector and repair of the communication cable or replace the wrong one Mismatch of the setting data of...
Page 263: Specifications
SPECIFICATIONS 10.1 Communication Specifications............10-2 10.2 Product Specifications ..............10-6 10-1 IMS01T07-E1...
Page 264: Communication Specifications
• OMRON SYSMAC series special protocol (0401/1401) − C mode command (RD/WD) Maximum connections: Four SRZ units per communication port of PLC (Up to one Z-COM module can be connected to one SRZ unit) • MITSUBISHI MELSEC series Usable PLC type: −...
Page 265 Horizontal parity (BCC check) Data types: ASCII 7-bit code Interval time: 0 to 250 ms Maximum connections: 16 SRZ units per communication port of host computer (Up to one Z-COM module can be connected to one SRZ unit) 10-3 IMS01T07-E1...
Page 266 (1 to 125) of data items available 4: Self-diagnostic error response Interval time: 0 to 250 ms Maximum connections: 16 SRZ units per communication port of host computer (Up to one Z-COM module can be connected to one SRZ unit) 10-4 IMS01T07-E1...
Page 267 10. SPECIFICATIONS Loader communication function Interface: Connection with a loader communication cable for our USB converter COM-K (sold separately). Synchronous method: Start/stop synchronous type Communication speed: 38400 bps Data bit configuration: Address: Start bit: Data bit: Parity bit: Without Stop bit: Protocol: Based on ANSI X3.28 subcategory 2.5 B1 Maximum connections: 1 point...
Page 268: Product Specifications
10. SPECIFICATIONS 10.2 Product Specifications Indication lamp Number of indicates: 3 points • Operation state indication (1 point) Indication contents: When normal (RUN): A green lamp is on Self-diagnostic error (FAIL): A green lamp flashes Instrument abnormality (FAIL): A red lamp is on •...
Page 269 10. SPECIFICATIONS General specifications Insulation resistance: 20 MΩ or more at 500 V DC (Between each insulation block) Withstand voltage: Time: 1 min. Grounding terminal Power terminal 750 V AC COM. PORT1, COM. PORT2 750 V AC 750 V AC COM.
Page 270 10. SPECIFICATIONS Isolation between Inputs and Outputs : Isolated : Not isolated Power supply COM. PORT1 COM. PORT2 COM. PORT3 COM. PORT4 Communication 10-8 IMS01T07-E1...
Page 271 The first edition: AUG. 2006 [IMQ00]...
Page 272 www.rkc-usa.com (800) 576 - 6308 Distributed By Inc,...

RKC INSTRUMENT Z-COM Instruction Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RKC INSTRUMENT Z-COM

Summary of Contents for RKC INSTRUMENT Z-COM

Table of Contents
