- Page 1 Commercial Freezer&Refrigerator Service Manual PRCBE-SERIES Model: PRCBE-36R-N PRCBE-36F-N PRCBE-48R-N PRCBE-48F-N PRCBE 60R N PRCBE 60F N PRCBE-60R-N PRCBE-60F-N PRCBE-72R-N PRCBE-72F-N PRCBE-84R-N PRCBE-84F-N PRCBE-96R-N PRCBE-96F-N...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 1. EXPLODED VIEW 1-1. MUF-28-N EXPLODED VIEW 1-2.PRCBE-36R-N PRCBE-36F-N EXPLODED VIEW 1-3. PRCBE-48R-N PRCBE-48F-N EXPLODED VIEW 1-4. PRCBE-60R-N PRCBE-60F-N EXPLODED VIEW 1-5. PRCBE-72R-N PRCBE-72F-N EXPLODED VIEW 1-6. PRCBE-84R-N PRCBE-84F-N EXPLOED VIEW 1-7. PRCBE-96R-N PRCBE-96F-N EXPLODED VIEW 2. -
Page 3: Exploded View
1. EXPLODED VIEW 1-1. PRCBE-36R-N PRCBE-36F-N EXPLODED VIEW ◎ Part Name COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT COMP EVAP DUCT DRAIN PAN EVAP FAN MOTOR MAIN PCB BOX EVAP COMP BASE GUIDE(L) EVAP DRAIN GUDIE COMP BASE GUIDE(R) UNIT FRONT COVER... -
Page 4: Prcbe-48R-N Prcbe-48F-N Exploded View
1-2. PRCBE-48R-N PRCBE-48F-N EXPLODED VIEW ◎ Part Name COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT EVAP FAN DUCT COMP COMP EVAP DUCT UNIT BRACKET (2EA) EVAP FAN MOTOR AIR GUIDE (FRONT BREATHING) EVAP FRONT PCB FIXTURE EVAP DRAIN GUDIE... -
Page 5: Prcbe-60R-N Prcbe-60F-N Exploded View
1-3. PRCBE-60R-N PRCBE-60F-N EXPLODED VIEW ◎ Part Name COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT COMP EVAP DUCT UNIT BRACKET (2EA) EVAP FAN MOTOR AIR GUIDE (FRONT BREATHING) EVAP FRONT PCB FIXTURE EVAP DRAIN GUDIE DRAWER SIDE FIXTURE UNIT FRONT COVER... -
Page 6: Prcbe-72R-N Prcbe-72F-N Exploded View
1-4. PRCBE-72R-N PRCBE-72F-N EXPLODED VIEW ◎ Part Name COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT COMP EVAP DUCT UNIT BRACKET (2EA) EVAP FAN MOTOR EVAP EVAP DRAIN GUDIE UNIT FRONT COVER UNIT BACK COVER... - Page 7 1-5. PRCBE-84R-N PRCBE-84F-N EXPLODED VIEW ◎ Part Name COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT COMP EVAP DUCT UNIT BRACKET (2EA) EVAP FAN MOTOR EVAP EVAP DRAIN GUDIE UNIT FRONT COVER UNIT BACK COVER...
-
Page 8: Prcbe-96R-N Prcbe-96F-N Exploded View
1-6. PRCBE-96R-N PRCBE-96F-N EXPLODED VIEW COUNTER TOP ASS'Y UNIT SIDE COVER CABINET ASSEMBLY CLEANER DOOR&DRAWER ASS'Y CONDENSER ASS'Y EVAP FAN DUCT COMP EVAP DUCT UNIT BRACKET (2EA) EVAP FAN MOTOR EVAP EVAP DRAIN GUDIE UNIT FRONT COVER UNIT BACK COVER... -
Page 9: Wiring Diagrams
2. WIRING DIAGRAMS 2-1. PRCBE-SERIES R-SERIES 2-2. PRCBE-SERIES F-SERIES... -
Page 10: Main Components
3.MAIN COMPONENTS 1.COMPRESSOR MODEL PART NAME PART NO. HORSE CAPACITY TYPE OF INPUT MAKER PRCBE-36R-N C-BHR250L2Y 115V 60HZ PRCBE-48R-N C-BHR250L2Y 115V 60HZ PRCBE-60R-N C-BHR250L2Y 115V 60HZ PRCBE-72R-N C-BHR250L2Y 115V 60HZ PRCBE-84R-N C-BHR350L2Y 115V 60HZ PRCBE-96R-N C-BHR350L2Y 115V 60HZ EMBRACO PRCBE-36F-N NEU2140U CSIR 115V 60HZ... -
Page 11: Temperature Control Instruction
5.EVAPORATOR FAN MOTOR BLADE MODEL PART NAME PART NO. POLE INPUT TYPE (NUMBER) PRCBE-36R-N ECR01A0K71 PRCBE-48R-N ECR01A0K71 PRCBE-60R-N ECR01A0K71 PRCBE-72R-N ECR01A0K71 PRCBE-84R-N ECR01A0K71 SHADED PRCBE-96R-N ECR01A0K71 115V 60HZ POLE AL 175mm PRCBE-36F-N ECR01A0K71 INDUTION PRCBE-48F-N ECR01A0K71 PRCBE-60F-N ECR01A0K71 PRCBE-72F-N ECR01A0K71 PRCBE-84F-N ECR01A0K71 PRCBE-96F-N... -
Page 12: Parts List
5. PARTS LIST Model Part Name Part Code Description Remark 1. DOOR DOOR ASSEMBLY 36 C3F3713100 DOOR ASSEMBLY 48 C4F3713100 DOOR ASSEMBLY 60 C6F3713100 DOOR HANDLE C3F8201100 DOOR FRAME(L)(R) C3F8707100 DOOR FRAME(T)(U) 36 C3F8707200 DOOR FRAME(T)(U) 48 C4F8707100 DOOR FRAME(T)(U) 60 C6F8707100 DOOR PANEL C3F3707100... -
Page 13: Drawer Guide Side Fixture Use
Model Part Name Part Code Description Remark 36R 48R 60R 72R 84R 96R 36F 48F 60F 72F 84F 96F CONDENSER FAN MOTOR ECR010AK71 ECR71 POWER CORD M721300100 KKP-30(9.85FT) WINDY GUIDE SIDE C3F6818102 GI 0.8T WINDY GUIDE DOWN C3F6818303 GI 0.8T DRAIN PAN M729300101 CONDENSER MOTOR BRACKET... - Page 14 LEFT MIDDLE LEFT MIDDLE RIGHT RIGHT...
