  • Page 1 SLIMLINE 150 INSTALLATION GUIDE FOR ENGINEER / INSTALLER...
  • Page 2 If the power cable becomes damaged, it must be • The safety regulations for low-voltage replaced by EnviroVent, an authorised service installations. agent for your region/ country, or a similarly qualified person in order to avoid a hazard.

  • Page 3: Technical Specifications

    Technical Specifications Before you begin to install the heat recovery unit, check that it has been supplied complete and undamaged. The Slimline 150 unit should include the following components: 1. Heat recovery appliance 2. Wall mounting bracket kit; - 2x suspension strips 3.
  • Page 4 The Slimline 150 comes ready to wire into the • Low sound level 230V mains fused spur. • Comes as standard with automatic bypass...
  • Page 5 Technical Specifications Supply voltage (V/Hz) 230/50 Protection degree IP30 Dimensions 1000 x 660 x 198 Duct diameter (mm) Ø125 (w x d x h) (mm) External discharge Weight (kg) 24.5 Filter class G4/G4 or G4/F7 Fan factory setting (control unit) 4-Way switch Ventilation capacity Permissible...
  • Page 6 Note: In practice, the value may deviate 1 dB(A) as a result of measuring tolerances. = [W] Note: The value stated in the circle is the capacity per fan (in Watt) SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 7 Technical Specifications 1. To dwelling   2. To atmosphere 3. From dwelling 4. From atmosphere 5. Electric connections 6. Connection condensate discharge AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 8 19. Sleeve cable 230V postheater or extra preheater 20. Mains cable 230V 21. 9-pole connector (only for Plus version) 22. Connector eBus 23. Fall protection front panel SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 9 In this mode the hot air in the The user information menu shows when the dwelling is replaced by cooler outside air as Slimline 150 frost control system is activated far as possible. (see page 19). bypass...
  • Page 10 B. Hole for gland to be mounted by installer (for sleeve cable postheater/ extra preheater). The Slimline 150 is also available as a Plus If a postheater or extra preheater is connected version. This version is equipped with a to connector X14 (accessible after opening...
  • Page 11 2x G4 surface mounted G4= Coarse 60% 0-10V proportional f7= ePM1 50% (PLUS version only) Slimline 150 Plus Filter kit RH sensor G4= Coarse 60% f7= ePM1 50% Please contact EnviroVent for order codes Transmitter wireless remote control 2 positions...

  • Page 12: Installation Instructions

    Installation Instructions The Slimline 150 can be mounted directly to • The installation room must be frost-free. the wall or ceiling using the mounting brackets • When mounting flexible ducts, bear in mind supplied for that purpose. that it must be possible to replace them in due course.
  • Page 13 Installation Instructions Placing the appliance for ceiling mounted   Condensate discharge  Appliance disconnecting from   mounting bracket   AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER  ...
  • Page 14 Installation Instructions Placing the appliance for wall mounted     Appliance disconnecting from mounting bracket Condensate discharge  SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150 ...
  • Page 15 Installation Instructions The Slimline 150 must always be fitted with a The condensate discharge line can be mounted condensate discharge. The condensate must to it, preferably glued, if necessary using a square be discharged through a drainpipe. EnviroVent bend. The installer can glue the condensate recommend using KITCONDENSATE-BK.
  • Page 16 (see page 33). Cables to be connected by installer (wire diameter at least 0.34 mm SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...

  • Page 17: Control Display

    Control Display Switching the appliance ON/OFF Warning When working on the appliance, always remove the voltage from the appliance by isolating the power. AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 18 The control unit display shows what the operating mode of the appliance is. Settings in the control unit software of the Slimline 150 can be called up and changed with the aid of the operating keys. Ex factory the control module is set for the English language.
  • Page 19 Control Display The supply and extract The supply and extract The supply and extract The supply and extract fans are running at 30 fans are running in fans are running in fans are running in /h or they are stopped ventilation mode 1 ventilation mode 2 ventilation mode 3...
  • Page 20 ( ); if the return key ( ) is not pressed, the display will return to the main screen some 5 minutes after the last time a key is operated. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 21 Control Display Device information menu From the main menu, turn the right-hand setting knob to select the ”Device information” menu and confirm the selection by pressing the right- hand setting knob. If several appliances are connected, a selection from the appliances can be made in this menu;...
  • Page 22 Deactivate the key lock once-only by holding down the right-hand setting knob for 3 seconds! Permanently deactivate it by changing the setting in the key lock menu. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 23 Control Display Installer menu From the main menu, turn the right-hand setting knob to select the “Installer” menu and confirm the selection by pressing the right-hand setting knob. several appliances connected, a selection from the appliances can be made in this menu;...

  • Page 24: Troubleshooting

    (limitedly). The display does show the fault symbol (spanner). This fault can be read out in the menu “Messages”. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 25 Trouble Shooting Locking fault Warning When the appliance detects a locking fault, it When working on the appliance, always remove the voltage from the will no longer work. The (permanently lighted) appliance by isolating the power. display shows the fault symbol (spanner) together with fault code.
  • Page 26 Note: If mode 2 of a multiple switch does not work, the modular connector of the multiple switch has been connected the wrong way round. Cut off one of the RJ connectors to the multiple switch and mount a new connector the other way round. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...

  • Page 27: Maintenance

    Maintenance User maintenance User maintenance is limited to periodically cleaning or replacing the filters. The filter only has to be replaced when that is indicated on the display (it shows the text “FILTER”) or, if a multiple switch with filter indication is mounted, when the red LED at the switch lights up.
  • Page 28 Maintenance SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...

  • Page 29: Installer Maintenance

    Maintenance Installer maintenance Isolate power Swing open the front panel (can also be taken from the hinges, if required). Installer maintenance includes cleaning the heat exchanger and fans. Dependent on the conditions, this must done about once every three years. AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 30 For ceiling mounting, carefully remove the condensate bin; there may still be some condensate left in the condensate bin Rinse the exchanger with warm water and a regular detergent. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 31 Maintenance AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 32 Press the Return key ( ) to leave any selected menu  and the appliance will return to operating mode. and the appliance will return to operating mode. SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...

  • Page 33: Electric Connections

    Electric Connections Wiring diagram Only for Plus version Slimline Slimline Green/ Slimline Slimline Brown Blue White nr.1 nr.2 Green Yellow yellow 150 Plus 150 Plus Outdoor Indoor Service Motor Sensor External Multiple Pre- Control Supply Extract Control Post- Output 0-10 V temp.

  • Page 34: Electric Connections Accessories

    Cable feed option for postheater the switch to setting 3 for longer than 2 seconds or by Power lead 230V switching it to absence mode ( ). SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: Slimline 150...
  • Page 35 Electric Connections Accessories Coupling several Slimline appliances  The slave appliances must be set as slaves before the appliances are interconnected through eBus! Refer to the supplied service tool manual for further instructions. There must be a separate 230V fused spur/isolator for every appliance.
  • Page 36 Cable sleeve Connection postheater or extra preheater The postheater or extra preheater (only possible for Slimline 150 Plus) are electrically connected to connector X14; just for a postheater there is also a temperature sensor that must be connected to no. 7 and 8 of the 9-pole connector that is only installed in the Plus version.
  • Page 37 Electric Connections Accessories Connection postheater Temperature sensor postheater 7 - 8. Connection extra preheater Setting parameter 11 & 12 (see page 39) The strain reliever to be installed by the installer (not supplied with the appliance) for feeding the 230 volt cable to the postheater or extra preheater. AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 38 0-10 volt input as well Setting parameter 19, 20 & 21 (page 40) The Slimline 150 Plus can be equipped with an external provision with 0-10 volt control. Connections X15-3 and X15-4 are set as standard as 0 - 10 V input; it is activated as standard.

  • Page 39: Service Parts

    EnviroVent for Filter holder set (2 pieces) order a replacement mains cable from order codes EnviroVent to avoid danger. A damaged Filter kit 2x G4 filter (standard version) mains should only be replaced by a Control board (Plus version) When replacing, qualified person.

  • Page 40: Setting Values

    Fixed imbalance -100 m /h t/m 100 m FACTORY SETTING STEP NO. DESCRIPTION ADJUSTING RANGE STEP Slimline 150 Plus 0 (= no additional heater) Heater 1 (= additional preheater) 2 (= postheater) Temperature postheater 21,0 °C 15,0 °C t/m 30,0 °C 0,5 °C...
  • Page 41 Setting Values FACTORY SETTING STEP NO. DESCRIPTION ADJUSTING RANGE STEP Slimline 150 Plus 0 (= Extract fan off) 1 (= Absolute min. flow rate 30 m 2 (= Flow rate mode 1) Extract fan mode 3 (= Flow rate mode 2)
  • Page 42 Setting Values FACTORY SETTING STEP NO. DESCRIPTION ADJUSTING RANGE STEP Slimline 150 OFF (= RH-sensor not active) RH-sensor (= RH-sensor active) +2 most sensitive +1 → Sensitivity RH-sensor default setting RH-sensor → -2 least sensitive FACTORY STEP NO. DESCRIPTION SETTING...
  • Page 43 Product data sheet conform Ecodesign (EU), nr. 1254/2014 (Annex IV) Supplier: EnviroVent Model: Slimline 150 The annual electricity The annual heating SEC-Value Climate zone Type of control Energy class (SEC) consumption (AEC) in saved (AHS) in kWh/m²/a in kWh Clock...

  • Page 44: Warranty

    ENVIROVENT SUPPLY & INSTALLATION If your product has been supplied and installed The warranty is in addition to your statutory or by EnviroVent Ltd it is covered with a two-year legal rights. parts and labour warranty. If you detect a...
  • Page 45 AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
  • Page 46 Your feedback is important to us as we strive to improve our and improvement EnviroVent reserves the products, services, and overall customer experience. Please email right to alter products specification and us to help us serve you better: feedback@envirovent.com appearance without notice.
