sauder.com
Night Stand
Primary Street Collection |Model 417912
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-13
Français pg 14-15
Español pg 16-17
Lot # 370037
03/02/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Related Manuals for Sauder Primary Street 417912
Summary of Contents for Sauder Primary Street 417912
- Page 1 Primary Street Collection |Model 417912 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
- Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-13 Hammer Not actual size Français 14-15 Español 16-17 Skip the power trip. Safety This time. Warranty Page 2 417912 www.sauder.com/services...
- Page 3 Use this part identifi cation to help identify similar parts. RIGHT END (1) BACK (1) RIGHT DRAWER SIDE (1) LEFT END (1) BASE (1) LEFT DRAWER SIDE (1) TOP (1) DRAWER FRONT (1) D482 DRAWER BACK (1) BOTTOM (1) DRAWER BOTTOM (1) D482 www.sauder.com/services 417912 Page 3...
- Page 4 DRAWER FRONT BRACKET - 1 WASHER - 4 BLACK 9/16" LARGE HEAD SCREW - 6 3S GOLD 5/16" FLAT HEAD SCREW - 8 30S BLACK 1-9/16" FLAT HEAD SCREW - 4 SILVER 1/2" MACHINE SCREW - 4 Page 4 417912 www.sauder.com/services...
- Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push eight HIDDEN CAMS (1F) into the ENDS (A and B) å...
- Page 6 ENDS (A and B). Use four GOLD 5/16" FLAT HEAD Remember: SCREWS (3S). Righty tighty. Lefty loosey. *patent pending glide system å GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Glide end Finished edge Glide end Finished edge Page 6 417912 www.sauder.com/services...
- Page 7 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 417912 Page 7...
- Page 8 Fasten the TOP (C) to the ENDS (A and B). Tighten four å HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Rounded edge S u r f a c i t h h o l Page 8 417912 www.sauder.com/services...
- Page 9 Fasten the BASE (F) to the ENDS (A and B) and å BOTTOM (D). Use three BLACK 9/16" LARGE HEAD SCREWS (1S) through the METAL BRACKETS and into the BASE. Rounded edge BLACK 9/16" LARGE HEAD SCREW (6 used in this step) www.sauder.com/services 417912 Page 9...
- Page 10 BACK fastened. The unit may collapse. Push on opposite corners of your unit if needed to make it "square". Fasten the BACK (E) to your unit using the NAILS (1N). å NAIL (18 used in this step) Page 10 417912 www.sauder.com/services...
- Page 11 (4 used in this step) Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove. Fasten the DRAWER BACK (D482) to the DRAWER SIDES (D36 and D37). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). å www.sauder.com/services 417912 Page 11...
- Page 12 NOTE: The parts are marked "DRAWER RIGHT" and å "DRAWER LEFT" for easy identifi cation. NOTE: The glides are not intended to rotate. å Glide end Glide end (4 screws per drawer) GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 12 417912 www.sauder.com/services...
- Page 13 This completes assembly. Clean with your favorite å furniture polish or a damp cloth. Wipe dry. And to celebrate, why not share your success story? 40 lbs. 15 lbs. 30 lbs. www.sauder.com/services 417912 Page 13...
- Page 14 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 35AA GLISSIÈRE D'ÉLÉMENT UNIVERSELLE ..2 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 35AC TIROIR DROIT ..............1 en ce qui concerne cet DESSUS ................1 35AD TIROIR GAUCHE ............1 élément, faire référence...
- Page 15 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 417912 Page 15...
- Page 16 35AA RIEL UNIVERSAL DE GABINETE ....2 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 35AC CAJÓN DERECHO ............1 Pour contacter Sauder PANEL SUPERIOR ............1 35AD CAJÓN IZQUIERDO ...........1 en ce qui concerne cet FONDO .................1 EXCÉNTRICO ESCONDIDO .......8 élément, faire référence...
- Page 17 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. www.sauder.com/services 417912 Page 17...
- Page 18 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 18 417912 www.sauder.com/services...
- Page 19 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
- Page 20 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
