USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Table of Contents Advanced Configuration System Requirements Installation Motor Current Sensor Brush RPM Adjustment Physical Set-Up Plumbing Connections Drive Parameters Timing Relay Motor Speed Adjustment Maintenance Operation Troubleshooting Start Up Appendices...
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Overview System Requirements Water Supply The BLX-700 is a compact automated footwear scrubbing unit built to accommodate 1 user at a time. • Flow: 5 GPM (3.8L/m) minimum* The included user manual contain installation, •...
X-700 OTOR GEAR UCER USER MANUAL: BLX-700-GEN2 6.00 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT 8.00 START BUTTON E-STOP BUTTON Installation RUN LIGHT RUSH 1/2" DIA MNT BOLT SECOND HOLE X 8 BLX-700 SS MOTOR AND GEAR UNIT RIGHT REDUCER 6.00...
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Installation Physical Set Up: 1. Set unit in desired location. 2. Aspects to consider when deciding on placement: • Clearance for general use • Location of drain • Emergency exit paths or egress •...
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Installation (continued) Motor Speed Adjustment The speed of the motor(s) is controlled by the Variable Frequency Drive (VFD). To adjust the speed, turn the knob on the front of the VFD while the unit is Speed under power and motor is running.
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Operation Start Button Start Up E-Stop 1. Verify installation has been completed: Indicator Light • Brushes and grate are secured • Unit is plugged in and receiving power • Water and solution have been plumbed and lines are open 2.
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Cleaning Procedures Removing Grate & Brushes 1. Shut down the unit (see pg. 7). 2. Remove the two vertical brushes by unscrewing the knobs at the top of each brush and lifting them up and off of their shafts [Figure 8.1].
Page 9
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Advanced Configuration Options Motor Current Sensor Brush RPM Formula: Automation Direct ACS-200 Current Switch The formula for calculating Speed in RPM from Drive Frequency in Hertz is: The motor current sensor monitors the current draw...
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Advanced Configuration Options (continued) Drive Parameter Settings Delta MS300 (AD GS20) Variable Frequency Drive PARAMETER DESCRIPTION SETTING UNIT NUMBER P00.20 Source of Frequency Dial P00.21 Source of Oper Input P01.12 1st ACC Time P01.13...
Page 11
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Preventative Maintenance The following maintenance procedures are recommended for normal use. Units which see a high amount of use should be inspected more frequently. Weekly: Gear Reducer: • Check unit for proper sensor function and brush •...
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Troubleshooting Unit not operating & Power Indicator is not Unit is leaking onto floor: Illuminated: • Check to make sure all joints are sealed. • Verify unit is plugged in. • Verify water and solution inlets are attached and •...
Page 13
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Troubleshooting F063 Fault Code "SW OverCurrent" on F004 Fault Code on Variable Frequency Drive: Variable Frequency Drive: • If unit is connected to a GFCI, verify its ratings Cause: The fault occurs when the torque load on...
Page 14
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix A - Parts Callout : BLX-700 BLX-700-GEN2 User Manual Page 14 of 19 Updated: 09/02/22...
Page 15
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix A - Parts Callout : BLX-700 Part No. Description Part No. Description F1000 STANDOFF 1/4 x 1/2 x 1/2 SS P1005 STERLING SS MOTOR 1/2HP, 1800 RPM F1001 Washer 3/4" X 1-1/4" X 1/16" PTFE...
Page 16
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Electrical Panel Parts Callout (115V) NO. PART NUMBER DESCRIPTION NO. PART NUMBER DESCRIPTION M2375 - BLX-700 GEN2 115V-1PH M2375 - BLX-700 GEN2 115V-1PH F1172 F1172 SCREW THEAD FORMING...
Page 17
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix B - Electrical Panel Parts Callout (230V) NO. PART NUMBER DESCRIPTION M2373 - BLX-700 GEN2 NDF 230V-1PH F1172 SCREW THEA M2268 BACK PANEL P1172 P1111 END STOP TE P1122 POWER SUPP...
Page 18
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix C - Electrical Schematic (115V) BLX-700-GEN2 User Manual Page 18 of 19 Updated: 09/02/22...
Page 19
USER MANUAL: BLX-700-GEN2 READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix C - Electrical Schematic (230V) BLX-700-GEN2 User Manual Page 19 of 19 Updated: 09/02/22...
