- Page 1 USER MANUAL MODEL: ALX-OMNI-LITE Chemical Allocation Controller English (Original Instructions) Updated: 03/24/2021...
-
Page 2: Table Of Contents
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Table of Contents General Configuration (continued) Overview Unit Info and Configuration Terminology Set Date & Time Specifications USB Options Installation Operation Installation Requirements Dispensing An Application Mounting Controller Reporting Connecting Ethernet... -
Page 3: Overview
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Overview Specifications Software The ALX-OMNI-LITE is a simple, entry-level time-based chemical dispenser with mounting plate for dispense ▪ Maximum number of Users: 100 Applications. It restricts access to chemicals to only authorized individuals either with a 4 digit access ▪... -
Page 4: Installation Requirements
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Installation Requirements Electrical ▪ 110 VAC, 5A, Single Phase, 50-60 Hz ▪ NEMA 5-15 GFCI Protected Outlet ▪ Surge suppression recommended Compressed Air (typical installation) ▪ Clean, dry air ▪ 10 CFM (283 L/min) @ 80 psi (5.5 bar) minimum ▪... - Page 5 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Mounting System ▪ Determine mounting location, with consideration of the following: ▪ User accessibility ▪ Distance to electrical outlet ▪ Distance to Devices/pumps ▪ Securely mount to wall using appropriate hardware (not included) via the keyholes on the mounting plate.
-
Page 6: Connecting Devices
M12 cable connections, then tighten two more clicks using wrenches. ▪ Plumb compressed air lines and fluid lines for regulator, pumps, and valves as necessary [see below] Installation Example: *Shown with ALX-OMNI-LITE-8 for dispensing up to 8 chemicals 03/24/2021 Page 6 of 21 ALX-OMNI-LITE Manual V1.0... - Page 7 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Notes: 03/24/2021 Page 7 of 21 ALX-OMNI-LITE Manual V1.0...
-
Page 8: Administrator Login
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT This section explains how to setup the ALX-LITE using the built-in keypad and screen. Administrator Login LITE Admin Menu 1-Users Press the ADMIN key. ▪ 2-Devices ▪ Type in a 4-digit administrator passcode. - Page 9 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Users (continued) Edit Users 00-Add New User Editing a User 01-administrator ▪ Select a user in the list and press ENTER. >02-Jason ▪ Edit the user settings as necessary Press the ESC key to exit.
-
Page 10: Devices
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Devices Edit Devices Adding a Device >0555-CONFIG PUMP ▪ Make sure devices are connected and green lights 0875-CONFIG PUMP are illuminated. 0689-Water (Red) ▪ Log in as an administrator. ▪ Use ↑ and ↓ keys to select Devices and press ENTER. - Page 11 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Devices (continued) Deleting a Device Editing Device #0555 Type: AODD Pump ▪ Select a Device in the list and press ENTER. Prime (Start/Stop) ▪ Use the ↓ key to scroll to the bottom of the >...
- Page 12 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Applications The ALX-LITE is designed to accommodate multiple step dispense applications for up to 6 chemicals at a Edit Applications time. Dispenses are controlled via simple time values >000-Add New App with the option of multiple products per dispense Application.
- Page 13 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Applications (continued) Edit Applications 000-Add New App Deleting a Dispense Step 001-Demo App 1 ▪ Select an Application in the list and press ENTER. >123-Demo App 2 ▪ Select the Step# you wish to delete and press the DEL key.
-
Page 14: Unit Info And Configuration
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Unit Info/Configuration Unit ID#: 123456 Login Level: Users ▪ Log in as an administrator. Logging: ON ▪ Use ↑ and ↓ keys to select Unit Info/Config Language: English and press ENTER. -
Page 15: Usb Options
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT USB Options USB Options The ALX-LITE includes a 8GB USB drive already Update USB logs plugged into the port on the bottom of the controller. Export config The controller will store dispense logs on this USB Import users drive, which can be retrieved manually at anytime. -
Page 16: Dispensing An Application
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Dispensing an Application 11/11/2016 01:27PM CleanLogix ALX-LITE ▪ If the screen says Press START to Begin, Press START. Welcome! Enter Passcode ▪ If the screen says Enter Passcode, Type in a 4-digit passcode or swipe a valid RFID card. - Page 17 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT USB Reporting USB Options Export Dispense Logs >Update USB logs Export config ▪ Make sure a USB drive is plugged into the controller port. Import users ▪ Log in as an administrator.
-
Page 18: Troubleshooting
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Troubleshooting Oh No! User pressed STOP before the dispense Cause Dispense Cancelled! finished. During a dispense, do not press any buttons until the post-dispense screen Solution appears, signaling the end of the dispense. - Page 19 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Troubleshooting (continued) Select App#--- Cause No Applications are setup. No applications Login as an Administrator and create Solution new Applications (Page 14). Action Failed Export Settings was attempted, but Cause there is no USB drive in the USB port.
-
Page 20: Parts Callout
USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix A - Parts Callout Part No. Description Part No. Description F1158 SCREW MACHINE M2.5 X 5 SS PHILLIPS PAN HD P1429 PUSH-PULL BUTTON RED 40MM F1160 SCREW MACHINE 4-40 X 7/8 ZN PHILLIPS PAN HD... - Page 21 USER MANUAL: ALX-OMNI-LITE READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT Appendix A - Parts Callout (continued) ALX-LITE Part No. Description Part No. Description CAN CONNECTED MODULE WITH FOUR 3-WAY P1206 GAUGE 1-1/2" DUAL SCALE CAN-SO-4 MANIFOLDED VALVES P1207 PIPE HEX PLUG 1/8 POLY...
