3.1.

Installing the LD2000

The LD2000 is a wall mounted device. There are four mounting holes on the sides of the unit
spaced 7.5 inches (.19m) apart. Use drywall anchors if securing the unit to drywall.
3.2.

Connecting the SeaHawk Leak Detection Cable

The LD2000 is shipped with a 15-foot (4.57m) leader cable. One end of this leader cable
connects to the LD2000 controller, and the other end connects to the SeaHawk leak detection
cable (sensing cable). Connect each end of the leader cable as follows:
With the screws of the terminal block connector on the LD2000 facing up, connect the four
1
stripped, bare wires of the leader cable to the terminals in this order, from left to right: white,
black, green, red.
Note If the terminal connector is removed from the end of the cable, make sure the wires are in
this same order when the connector is reapplied.
Unscrew the end-of-line (EOL) terminator from the other end of the leader cable.
2
Attach the first length of leak detection cable (sensing cable) to the leader cable.
3
