Lighting Operating and Maintance Instructions
for
Harmony
H23
Stanford
S23
SP23
Nestor Martin
R23
Smoke Control Exemption Edition
Wood Stoves
with Plexus Control and ZR Technology
This Manual Must Always Be Available To The Stove Operator
Part No.
Model Name
Serial Number
© EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006
Instructions Part Number IN1143 Ed.B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Euroheat Harmony H23
Summary of Contents for Euroheat Harmony H23
- Page 1 Smoke Control Exemption Edition Wood Stoves with Plexus Control and ZR Technology This Manual Must Always Be Available To The Stove Operator Part No. Model Name Serial Number © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
-
Page 2: Warranty Registration
Please ensure this is fully completed by your installing engineer with details of your approved Euroheat supplier and returned to Euroheat within 4 days of installation. The free 0 year technical telephone help can only be authorized if the stove is registered with Euroheat by returning the registration form. -
Page 3: Model Identification
This information is also attached to your stove for reference. Important Please ensure the warranty registration form is returned to Euroheat. In this way the model and its history will be recored for reference in the future. Contact Details: www.euroheat.co.uk... - Page 4 It must also be operated strictly with the procedures given in this manual. If you are unsure about anything concerning your stove please seek professional advice. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 5 The time taken for the paint to be fully cured will normally be approximately 6 hours. If you re-paint or fit new parts to your stove, another period of curing will be necessary but the curing time will be much shorter. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 6 Constantly adjusting the stove’s controls will upset this balance and give poor economy and unacceptable amounts of emissions. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 7 Operating Tool fast and if damp may leach out and be absorbed into porous surfaces. for Plexus Control and Ash Pan Removal Allen Key For Plexus Maintenance Poker © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 8 “A” as soon as possible. Lighting Lighting or Rousing a All Other Slumbering Fire Times This lever may be hot. Always use the stove tool to make air direction adjustments. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 9 and 6. No under grate air supply. No under grate air supply. This control knob may be hot. Always use the stove tool to make air volume adjustments. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 10 Never clean out ashes onto paper, never use a plastic bristled brush or a vacuum cleaner to remove ash. Never let children “help” with the stove in any way. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 11 Never open the ash pit door without the stove door being ajar and never leave either the stove door or the ash pit door open for longer than absolutely necessary. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
-
Page 12: Getting Started
Resist the temptation to use more paper than this, or to crumple it too tightly; doing either will prevent the rapid development of flames and will cause smoke to be produced. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B... - Page 13 Move the air direction lever to its uppermost position and do not be alarmed if the fire appears to die, or be tempted to move it back to its middle position. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 14 You can throw away your “L” plates and move on to become an advanced driver. See page 5. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 15 Before checking your technique, make absolutely certain that the wood you are using is dry, not “seasoned”, “barn stored” or “ready for burning”. It must be dry if you want to burn it successfully, cleanly and efficiently. (see the Euroheat document Number —‘IN1172’ for further information The Fire Went Out Do not put wood onto the kindling too soon or without allowing vents for the flames.
- Page 16 If you are having to burn unsplit logs, that issue most of their initial gasses only from their ends, it is important to rake embers so that the log ends are over the charcoal bed to heat the gasses to © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 17 If you have fitted a remote control to the stove, please read Technical Guides IN7 Multi Function Remote (pictured) and IN4 for Single Function Remote, for advice on making the most of its facilities. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
- Page 18 If you have managed to run your stove overnight, without staining the glass, you have achieved the highest achievement possible as a stove operator and you should award yourself an enormous gold star. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
-
Page 19: Choice Of Logs
“higgledy-piggledy” manner. IDEAL LOG LENGTHS:- 8 inches, 00mm. MAXIMUM LOG LENGTHS:- 3 inches, 330mm © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B... -
Page 20: Cleaning The Stove
National Chimney Sweeps Association. Telephone: 0785 873 The Solid Fuel Association. Telephone: 0845 604406 . HAVE YOUR STOVE FITTED AND MAINTAINED BY EXPERIENCED PROFESSIONALS. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B... -
Page 21: Simple Maintenance
The door can be adjusted by loosening the not securing the eccentric latch pin and screwing the pin in or out to adjust the horizontal and vertical closing position. © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B... -
Page 22: Other Maintenance
It is important that all the stove seals are replaced when any signs of wear are apparent or they become degraded and that only parts approved by Euroheat must be fitted. Summer Shut Down At the end of each heating season the entire installation should be thoroughly cleaned and examined for soundness, this should include having the flue examined by a registered sweep. - Page 23 EN 340-A:004. Warranty Thank you for choosing a Euroheat/Nestor Martin stove. It has been constructed with the utmost care and with the finest materials; we hope it gives you many years of pleasurable warmth. If your stove has an enamel finish you will notice, after the stove has been used several times, it develops what is called a “crackle”...
- Page 24 © EUROHEAT DISTRIBUTORS (H.B.S.) LTD. Nov 2006 Instructions Part Number IN1143 Ed.B...
