INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
CB1200 PELLET INSERT
APPLIANCE
MODEL:
CB1200I-C
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, fire officials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
CAUTION
R
If the information in these instructions is
not followed exactly, a fire could result
causing
injury, or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as fireplace.
• Alert
children
high temperatures
• High temperatures may ignite clothing or other
flammable materials.
• Keep
clothing,
flammable materials away.
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty.
NOTE: To obtain a French translation of this manual,
please contact your dealer or visit
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre revendeur ou
visitez
www.quadrafire.com
7027-804H
WARNING
property
damage,
WARNING
and
adults
to
hazards
furniture,
draperies
and
CAUTION
www.quadrafire.com
personal
of
other
07/22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hearth & Home CB1200
Summary of Contents for Hearth & Home CB1200
- Page 1 INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is CB1200 PELLET INSERT not followed exactly, a fire could result causing property damage,...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Important Safety Information
Important Safety Information A. Appliance Certification B. BTU & Efficiency Specifications Emissions Report #: 0061PN013E Model CB1200 Pellet Insert EPA Certification #: 171-19 Laboratory OMNI Test Laboratories, Inc. EPA Certified Emissions: 0.8 grams per hour Safety 061-S-13-2 Report No. *LHV Tested Efficiency: 67.6% **HHV Tested Efficiency: 63.6%... -
Page 4: Glass Specifications
I. California - Prop65 C. Glass Specifications This appliance is equipped with 5mm ceramic glass. WARNING Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. This product and the fuels used to operate this product (wood), and the products of combustion of such fuels, can expose you to chemicals including carbon black, which is known to the State of California to D. -
Page 5: Getting Started
Getting Started A. Design, Installation & Location Since pellet exhaust can contain ash, soot or sparks, you must consider the location of: Considerations • Windows 1. Appliance Location • Air Intakes • Air Conditioner NOTICE: Check building codes prior to installation. •... -
Page 6: Thermostat Wall Control Location
C. Tools And Supplies Needed WARNING Tools and building supplies normally required for installation, unless installing into an existing masonry fireplace: Risk of Fire! Reciprocating Saw • Damaged parts could impair safe Channel Locks operation. Hammer • Do NOT install damaged, incomplete or Phillips Screwdriver substitute components. -
Page 7: Install Checklist
E. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. __________________________________________________________________________ Customer: ______________________________________________________________________ Date Installed: _______________________________________________________________________ Lot/Address: ________________________________________________________________ Location of Appliance:... -
Page 8: Dimensions And Clearances
Dimensions and Clearances A. Appliance Dimensions 29-1/4 in [743mm] 22 in [559mm] 29-1/4 in [743mm] 8-3/4 in [223mm] 22 in [559mm] 8-3/4 in [223mm] 12-3/8 in 13 in [315mm] 10-7/8 in [330mm] 12-3/8 in [277mm] 13 in [315mm] 10-7/8 in [330mm] [277mm] 13-5/8 in... -
Page 9: Clearance To Combustibles, Ul And Ulc
B. Clearance To Combustibles, UL and ULC 25 in** 25 in** (635mm) (635mm) 29-3/4 in. (756mm) 15-1/2 in* (394mm) Be sure to follow vent manufacturers clearance to combustibles. *If interior of chase will be drywalled, add the thickness to this measurement. **From finished floor protection. -
Page 10: Masonry Chimney And Fireplace Clearances
C. Masonry Chimney and Fireplace D. Minimum Opening for Masonry & Clearances ZC Fireplaces TOP TRIM 19-3/4 in 19-3/4 in (502mm) (502m) 28-1/2 in (724mm) Figure 10.3 18-1/4 in HEARTH Location Inches Millimeters (464mm) EXTENSION Height (Maximum Figure 10.1 22-1/4 Hopper Adjustment)* NOTE: If trim measurement is over 3/4 in (19mm) Height (Minimum... -
Page 11: Floor Protection
F. Floor Protection 1. Zero Clearance Installations* It is necessary to install a floor protection of non-combustible material with a R value of 3.0 (1 inch [25mm] minimum thickness with a “k” value of 0.58) or a 1 inch (25mm) air space between insert base and hearth. -
Page 12: Installation Into A Factory-Built Fireplace
G. Installation into a Factory-Built Fireplace The following is only one example as there are many different models of factory-built fireplaces. The following modifications are permissible: Removal of damper or locked in open position NOTE: This example is for reference only. Any Removal of smoke shelf or baffle modifications must not compromise the Removal of ember catches... -
Page 13: Installation Into A Masonry Fireplace
H. Installation into a Masonry Fireplace • No dilution air is allowed to enter the chimney. All modifications that can be made to a Factory Built a. Secure the fireplace damper in the open position. If this cannot be accomplished, it will be necessary to Fireplace can be made to a Masonry Fireplace. -
Page 14: Vent Information
Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Termination Cap Air Supply Inlet Gas Meter Restricted Area All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. Above Finish Grade (the grade surface 24 in. -
Page 15: Avoiding Smoke And Odors
B. Avoiding Smoke and Odors Vent Configurations When installing a pellet appliance with a horizontal vent Negative Pressure, Shut-Down and Electrical Power configuration the frequency of power outages should Failure be considered: To reduce the probability of back-drafting or burn-back •... -
Page 16: Negative Pressure
C. Negative Pressure NOTICE: Hearth & Home Technologies assumes no responsibility for the improper performance of the WARNING chimney system caused by: • Inadequate draft due to environmental conditions Risk of Asphyxiation! • Down drafts Negative pressure can cause spillage of combustion •... -
Page 17: Equivalent Feet Of Pipe
F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet of pipe which is a method used to determine pellet vent size (Figure 17.1). Vent surfaces get HOT, can cause burns if touched. Non-combustible shielding or guards may be required. -
Page 18: Venting Systems
Venting Systems A. Direct Connect with Outside Air B. Direct Connect without Outside Air NOTE: In Canada, only a full reline is allowed per ULC S628-93, ORD ULC C1482-M1990. NOTE: • Use non-combustible materials around exhaust vent pipe and seal all edges with non-flammable insulation such fiberglass,... -
Page 19: Full Reline With Outside Air - Horizontal
C. Full Reline With Outside Air - Horizontal WARNING CAUTION Fire Risk. Never draw outside combustion air from: Inspection of Chimney: • Wall, floor or ceiling cavity • Masonry chimney must be in • Enclosed space such as an attic or garage good condition. -
Page 20: Full Reline With Outside Air - Vertical
D. Full Reline With Outside Air - Vertical NOTE: In Canada only a full reline is allowed per ULC S628, ORD ULC C1482-M1990. NOTE: Check clearances carefully for this type of installation to ensure adequate room for outside air venting. NOTE: In Canada this fireplace insert must be installed with a continuous chimney liner extending from the fireplace insert to the top of the chimney. -
Page 21: Appliance Set-Up
Appliance Set-Up 2. Using a Phillips head screwdriver and two screws to A. Rear Shroud Installation attach Filler Bracket (Figure 21.3). Tools Required: Electric drill, #26 drill bit, Phillips screwdriver, 3/8 inch wrench, and 7/16 inch socket wrench. Needed to complete installation of the Rear Shroud Assembly;... - Page 22 4. Install the left shroud panel corner; 2 screws into 8. Assemble the right shroud panel corner and the right back of hopper and 1 screw down into the filler shroud panel using 3 screws (Figure 22.5). piece (Figure 22.1). 2 screws into 1 screw down back of hopper...
-
Page 23: Outside Air Kit Instructions
B. Outside Air Kit Instructions 12. Using the electric drill with #26 drill bit; drill 2 holes into the left side of the hopper. Add two screws to secure NOTE: A Quadra-Fire outside air kit; 811-0872, is shroud assembly to the appliance (Figure 23.1). available through your Quadra-Fire Dealer to be used as a the outside air option, but is required for mobile home installations. -
Page 24: Adjustable Hopper Options
C. Adjustable Hopper Options Charred Areas in the Back Depending on your installation, the hopper can be adjusted down 2-1/2 inches (64mm) and will decrease in capacity from 75lbs to 60lbs. To adjust hopper: Top Log Top Log, Left 1. Using a Phillips head screwdriver, remove all the Right screws from the top of the hopper securing the top hopper piece to the bottom hopper piece and... -
Page 25: Panel And Trim Set
E. Panel and Trim Set 6. Hold side curtains in open position and lower panel set over insert setting lower edge of top panel in slot Standard Size: 30 inches H x 40 inches W between hopper lid and panel support as shown in (762mm x 1016mm) Figure 25.5. -
Page 26: Thermostat Installation And Operation
F. Thermostat Installation and Operation The kit comes with a programmable wall thermostat and 25’ of thermostat wire. If you need to run more than 25’ make sure you use a continuous strand of 18 to 22 gauge thermostat wire. For optimum performance your thermostat should be: •... -
Page 27: Mobile Home Installation
Mobile Home Installation You must use a Quadra-Fire Outside Air Kit 811-0872 CAUTION for installation in a mobile home. 1. An outside air inlet must be provided for the combustion air and must remain clear of leaves, debris, THE STRUCTURAL INTEGRITY OF THE MOBILE ice and/or snow. -
Page 28: Reference Materials
Reference Materials A. Service & Maintenance List Date of Service Performed By Description of Service 7027-804H 07/22... -
Page 29: Accessory List
B. Accessory List CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. - Page 30 CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
- Page 31 7027-804H 07/22...
- Page 32 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
