Summary of Contents for EXHOBBY VOLANTEX RC
- Page 2 2 / 12...
- Page 3 3 / 12...
-
Page 4: Charging Instruction
Charging Instruction 1. Unplug the battery from your plane. 2. Carefully plug the charger into the USB port on your computer or USB adapter. 3. Connect battery into the charger. 4. The charging process takes about 3.5 hours. For safety reasons, never charge the battery for longer than 4 hours. - Page 5 3. Connect the battery to the plane, and secure it into the battery cell. NOTE: Keep the gyro switch off (manual mode) before you operate the steps below. See more information in "gyro switch" section. 5 / 12...
- Page 6 One-key Return Activation One-key Return Switch Gyro Switch 0 - Away From You- Manual / Gyro Off (EXPERT) Trainstar Mini comes with pre-installed 1 - At the Middle - Soft Gyro Assit (MIDD) 2 - Towards You - Strong Gyro Assit (BEGINNER) gyro to help control flying easily.
- Page 7 Binding Instruction Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single specific transmitter. When a receiver is bound to a transmitter, the receiver will only respond to that specific transmitter. If you need to rebind for any reason, please follow these steps: 1.Keep the transmitter switched OFF, throttle joystick at buttom position.
- Page 8 Channels Reactions Checking Swing The Transmitter Reaction Gyro Reaction Plane Operaton Place your plane in a neutral position, follow below steps to check the channels reactions. Move the sticks(except the throttle stick) to see if all servo surfaces react correctly as shown in the left diagram(left throttle for example).
- Page 9 Gyro System Calibration If you feel the gyro system is not holding the airplane to fly in correct attitude, follow below steps to re-calibrate the gyro system. 1.Turn the throttle stick to min position. 2.Power on the transmitter and the receiver. 3.Do NOT unlock the throttle.
- Page 10 Follow below steps to replace broken Motor Upper propeller and shaft adaptor. You will need Shaft Part help of a Philips screw driver and pliers(not included). Spinner 1. Take off the spinner and propeller by loosen the screw with a Philips screw driver.
- Page 11 11 / 12...
