ONLINE SUPPORT
Monoprice™ is pleased to provide free online support. For order related issues, contact the Customer Service department
through the Live Chat link on our website www.monoprice.com or via email at support@monoprice.com
For technical issues, contact the Technical Support department through the online chat button on our website
www.monoprice.com or by sending an email to tech@monoprice.com
Check the website for support times and links.
FEATURES
Distributes either of two HDMI® sources to any or all of four HDMI displays
•
Complies with the HDMI 2.0b and HDCP™ 2.2 specifications
•
Supports HDMI® resolutions up to 4K@60Hz with the 8-bit RGB, YCbCr 4:4:4, and YCbCr 4:2:2 color spaces
•
•
Supports high definition digital audio formats, including LPCM 7.1, Dolby Digital™, Dolby TrueHD™, DTS Digital™, and
DTS-HD Master Audio™
Supports HDR10, HDR10+, HLG, and Dolby Vision™
•
Includes basic EDID® management
•
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or
damaged, please contact Monoprice Customer Service for a replacement.
1x 2x4 HDMI® splitter and switch
1x 5 VDC, 1A AC power adapter
1x Quick user guide
4K HDMI® 2x4 Splitter and Switch
P/N 15866
Quick Start Guide
1
Advertisement
Table of Contents
Related Manuals for Blackbird 15866
Summary of Contents for Blackbird 15866
- Page 1 4K HDMI® 2x4 Splitter and Switch P/N 15866 Quick Start Guide ONLINE SUPPORT Monoprice™ is pleased to provide free online support. For order related issues, contact the Customer Service department through the Live Chat link on our website www.monoprice.com or via email at support@monoprice.com For technical issues, contact the Technical Support department through the online chat button on our website www.monoprice.com or by sending an email to tech@monoprice.com...
- Page 2 PRODUCT OVERVIEW Front Panel EDID: The EDID switch determines how the system determines the EDID® settings to send to the source devices. When placed in the TV position, the system reads the capabilities of the display connected to Output 1 and sends that data to the source devices.
- Page 3 SPECIFICATIONS Model 15866 V2 Inputs 2x HDMI® Outputs 4x HDMI Maximum Resolution 4K@60Hz Video Bandwidth 18Gbps Supported Color Spaces 8-bit RGB, YCbCr 4:4:4, and YCbCr 4:2:2 HDMI Version 2.0b HDCP™ Version High Dynamic Range Support HDR10, HDR10+, HLG, Dolby Vision™...
- Page 4 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Monoprice™, Blackbird™, the Blackbird logo, and all Monoprice logos are trademarks of Monoprice Inc. The terms HDMI®, HDMI High-Definition Multimedia Interface®, HDMI Trade Dress®, and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
