  • Page 1 Instruction Manual SKU: 6414-287 11.5ft x 11.5ft Tension Shelter Gazebo...
  • Page 2 KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC. This Tent is Made With Fabric That Meets CPAl-84 Specification For Flame Resistance. lt is Not Fire Proof. The Fabric Will Burn lf Left ln Continuous Contact With Any Flame Source. The application of any foreign substance to the tent fabric may render the flame-resistant properties ineffective.
  • Page 3 Pre-Assembly PLANNING ASSEMBLY Part Part Description Description Corner Connector Expension Bolt Post Fasten Hook Beam Bungee cord Beam joint Bolt Cap Roof Rib Nut Cap Roof Connector Glass Fiber Rod Support Bar Canopy Foot Plate Allen Key Bolt (M6*15) Wrench Bolt (M6*65) Wrench Gasket...
  • Page 4 Assembly STEP 1. Setting up the top frame Fig.1 Fig.2 Fig.3 1.1 Attach the two Beam C to the Beam joint D to have full length Beam as show in Fig.1. Repeat this until all four beams assembled. Please note the short tube connector on Beam joint D must face inside.
  • Page 5 Assembly (continued) STEP 2. Setting up the top frame Fig.4 Fig.5 2.1 Insert the Roof Rib E to the Roof Connector F as show in Fig.4. 2.2 Instert the another end of Roof Rib E to the short tube connector on Beam joint D as show in Fig.5.
  • Page 6 Assembly (continued) STEP 3. Attaching the canopy top Fig.6 Fig.7 Fig.8 3.1 Put the canopy S on the top of roof rib and use Fasten Hook N to hook on the triangular ring on canopy corner and the hole on Corner Connector A as show in Fig.6. 3.2 Connect the Glass Fiber Rod R to be one completed rod.
  • Page 7 Assembly (continued) STEP 4. Setting up gazebo Fig.9 Fig.10 4.1 Attach the Foot Plate H to Post B with hardware P/J/K/L/Q as show in Fig.9. 4.2 Insert the Leg B to the Corner Connector A as show in Fig.10.
  • Page 8 5.1 Use Expension Bolt M to secure your gazebo to the ground to stablize the gazebo as show in Fig.11. Finally, please check and tighten all the bolts and nuts before you use it. Congratulationns, you have done the gazebo set up! SKU: 6414-287 Code: 20MY00111601 Email: service@casualwayusa.com Home Hardware Stores Limited 34 Henry Street West, St.
