- Page 1 DAAX500L Belt air compressor USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. INTRODUCTION ............................2 2. SAFETY INFORMATION .......................... 3. OPERATION ..............................4 4. GENERAL VIEW AND MAIN COMPONENTS ..................5. MAIN TECHNICAL PARAMETERS ......................8 6. AIR COMPRESSOR PARTS LIST ......................9 7. MAITENANCE ............................11 8. TROUBLES AND REMEDIES LIST OF GOODS ..................WARRANTY ............................... -
Page 3: Introduction
1. XXXXXXXXXXXXXX 1. INTRODUCTION Xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx You’ve received the air compressor you had longed for Probably you’ve already had knowledge of it, but in order to make it serve you always in a good condition, read the manual carefully please. Operate according to the manual, you’ll get the best economy and efficiency from your new com- pressor. - Page 4 Danger! Risk of electric shock! (1) Do not expose the machine to rain. (2) Do not operate the machine in damp or wet environment. (3) Prevent body contact with earthed objects such as radiators,pipes,cooking stoves or refrigera- tors when operating this electric tool (4) Do not use the power cable for any purpose it is not intended for.
-
Page 5: Operation
The safety valve is incorporated into the pressure switch unit,the safety valve opens if the max,per- missible pressure is exceeded,Will be not accepted adjustment 3. OPERATION (1) Working place: *install the compressor in a well ventilated, probably dust and moisture free environment. *a bright place where oil can be easily added. - Page 6 (4)Motor *Install your own motor that match the compressor. *Install the V-belt as showed in the figure. *Adjust belt tension. The belt must a give of about 10-15mm with a space at it’s center, as showed in the figure: **Such things may happen if the belt is too tight: increase the loading, motor get hot, waste energy and break the belt.
- Page 7 Remove the oil plug (10) Fill with oil up to the centre of the level indicator(11) Install back the oil plug(10) *The lubricant oil should be of oilness and contain inhibitor, not easy to be oxidized, get densified or foamed, low residual carbon, hight flash point. *Oil level should maintain in the red scope of the level glass.
- Page 8 Do not stop the compressor by unplugging, but switch OFF using the switch. Unplug after use. (8)Generating compressed air 1.Start compressor(1)and wait until the max. Tank pressure is reached(compressor shuts off). The tank pressure is indicated by the tank pressure gauge(2). 2.
-
Page 9: General View And Main Components
5. Drain valve 6. Crankcase 7. Air filter 8. Motor 9. Tank 5. MAIN TECHNICAL PARAMETER DAAX500L Power: 10 hp / 7.5 kW Tank capacity: 500 L Cylinder: 3*90 mm : Plastic Pressure: 8 bar / 115 psi Engine speed: 870 rpm... -
Page 10: Air Compressor Parts List
6.AIR COMPRESSOR PARTS LIST When requesting information, service or spare parts, please always quote the model, type and serial number of your compressor. Contact us by mail, you will receive satisfied service. - Page 11 Parts name Drain valve Bolt Wheel Spring washer Plain washer Connecting three holes Cylinder head Pressure switch Cylinder head gasket Safety valve Valve plate Pressure gauge Valve sheet Air cock assembly Valve plate aluminum gasket Ball valve Valve sheet Safety net Valve plate Valve plate gasket Spring washer...
-
Page 12: Maitenance
7. MAINTENANCE Prior to each use (1)Check air hoses for damage, replace if necessary. (2)Check all screwed connections for tightness, tighten if necessary. (3)Check power supply cable for damage, if necessary have replaced by a qualified electrician. (4)Every 150 operating hours Check air filter element(18)of compressor pump, clean if necessary } (6) Check oil level of pump at oil sight glass(11), top up oil if necessary (7) Drain condensate from pressure vessel(5). - Page 13 Release water and greasy dirt every day after work through the outlet value under the bottom of the tank. (8)Every 300 operating hours Drain oil and fill with fresh oil. (9)Every 1000 operating hours Have unit serviced by an authorized service station. This will extent the compressor’s service life considerably.
-
Page 14: Troubles And Remedies List Of Goods
8. TROUBLES AND REMEDIES LIST OF GOODS The air compressor can be turned:... - Page 18 DECLARATION OF CONFORMITY AIR COMPRESSOR Model: DAAX500L Brand: We GBR Corp. LTD, Room 1002, 10/F., David House, 8-20 Nanking Street, Jordan, Kowloon, Hong Kong, China, declare under our sole responsibility that this product is in conformity and accordance with the following standards and regulations.
-
Page 19: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 20 Manufactured under license of Daewoo International Corporation, Korea...
