- Page 1 DIRECT AIR COMPRESSOR SERIES USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. PREPARATION FOR STARTING ......................2 2. SAFETY GUIDELINES ..........................2 3. WARNING ..............................2 4. CAUTION ..............................3 5. APPLICATION ............................3 6. GENERAL VIEW AND MAIN COMPONENTS ..................4 7. TECHNICAL SPECIFICATIONS ......................5 8. SPARE PARTS LIST..........................6 9. -
Page 3: Preparation For Starting
1. PREPARATION FOR STARTING (1) Air compressor should be placed in a clean, dry and ventilated area. (2) In order to extend compressor lifespan ,reduce heat for moving parts by making sure this air compressor cover must be at least 0.3~0.5 meters away from the wall. (3) Keep voltage within±5% of rating (4) Keep the oil level in the red circle leveler. -
Page 4: Caution
(2).Never use an electric air compressor outdoors when it is raining or on a wet surface, as it many cause an electric shock. (3).This unit starts automatically. Always shut off the compressor, remove the plug from the outlet, and emptying all pressure from the system before servicing the compressor, and when the compressor is not in use. -
Page 5: General View And Main Components
6. GENERAL VIEW AND MAIN COMPONENTS 1. SWITCH 2. SAFETY VALVE 3. REGULATOR 4. GAUGE 5. OIL WINDOW 6. AIR FILTER 7. DRAIN COCK 8. BREATH PIPE... -
Page 6: Technical Specifications
7. TECHNICAL SPECIFICATIONS DAAC24DN Power: 2 hp/1.5 kW Tank capacity: 24 L Cylinders: 1*42 mm/1*47 mm Air filter type: 3/8” Plastic Pressure: 8 bar/115 psi Engine speed: 2850 rpm(50 Hz)/ 3450 rpm(60 Hz) Flow: 135 L/min(1*42mm)/ 169 L/min(1*47mm) Noise: 84 dB DAAC50DN Power: 2hp/1.5 kW... -
Page 7: Spare Parts List
8. SPARE PARTS LIST... -
Page 9: Things To Do The First Time
9.THINGS TO DO FOR THE FIRST TIME (1) Connect the wheel to the air compressor. (2) Use screwdriver to tight the axle (3) Install the Rubber foot pad to the air compressor. - Page 10 (4) Remove the Warning Sign and oil plug (5) Add the oil Oil must be add until the red point...
- Page 11 (6) Install the breath pipe into the hole of the crankcase cover (7) Install the Air Filter into the compressor head. (8) Connect the power (9) Pull up the red knob of pressure switch in position on...
-
Page 12: Operation And Maintenance
10. OPERATION AND MAINTENANCE (1).Please check the technical documents carefully after you opened the case(documents including introduction manual) Check if the spare parts are correct, and check if the compressor is in good condition. (2).Pull out the oil plug, filling N32 machine lubricating oil to the oil hole till the stipuiated level in winter. -
Page 13: Troubles And Remedies List Of Goods
11. TROUBLES AND REMEDIES LIST OF GOODS PROBLEM POSSIBLE CORRECTIVE ACTION CAUSE(S) Compressor will not run 1.No electrical power 1.Plugged in? Check fuse/breaker 2.Blown fuse 2.Replace blown fuse. 3.Breaker open 3.Reset determining why problem 4.Thermal overload opern Happened 5.Pressure switch bad 4.Motor will restart when cool (approx. -
Page 14: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 15 Manufactured under license of Daewoo International Corporation, Korea...
