Service-Management
Service Manual
ALANA
ALANA
Inhaltsverzeichnis
Allgemeiner Teil ...................................... 2 ... 3
Bedienhinweise .............................................................................. 2
Servicehinweis ............................................................................... 3
Platinenabbildungen ............................. 4 ... 32
Schaltpläne
HF-Teil ........................................................................................ 4
Prozessor-Teil ............................................................................. 7
CD-Teil ...................................................................................... 10
Klangsteller ............................................................................... 12
RDS, Interfaces ........................................................................ 14
NF-Teil ...................................................................................... 16
Anschluss-Platte ....................................................................... 20
Bedienplatte .............................................................................. 22
Platinenabbildungen .................................................................... 25
Ersatzteilliste ....................................... 31 ... 32
Zusätzlich erforderliche Unterlagen für den Komplettservice
Additionally required Documents for the Complete Service
Service
Manual
Sicherheit
Safety
Mat.-Nr./Part No.
720108000000
All manuals and user guides at all-guides.com
GHM9100
Mejico
GHN6100
Seite

Table of Contents

General Section ....................................... 2 ... 3
Operating Hints .............................................................................. 2
Service Hint .................................................................................... 3
Circuit Diagrams
and Layout of the PCBs ........................ 4 ... 32
Circuit Diagrams
RF Part ....................................................................................... 4
Processor Part ............................................................................ 7
CD Part ..................................................................................... 10
Sound Control ........................................................................... 12
RDS, Interfaces ........................................................................ 14
AF Part ...................................................................................... 16
Connection Board ..................................................................... 20
Operating Board ....................................................................... 22
Layout of the PCBs ...................................................................... 25
Spare Parts List ................................... 31 ... 32
Dieses Service Manual ist nur in Datenform verfügbar
This Service Manual is only available as data
Änderungen vorbehalten
Subject to alteration
Made by GRUNDIG in Germany
H-S44
0302
720108500490
http://www.grundig.com
Page
