Wireless Data Collector
© Copyright
HyQuest Solutions Pty Ltd
INSTRUCTION MANUAL
WIRELESS DATA COLLECTOR
MODEL WDC100
QUALITY SYSTEM
ISO:9001
CERTIFIED
HYQUEST SOLUTIONS PTY LTD
PO BOX 332, LIVERPOOL B.C NSW 1871, AUSTRALIA
Phone:(Int.) 612 9601 2022 Fax: :(Int.) 612 9602 6971
Phone:(Nat.) (02) 9601 2022 Fax: :(Nat.) (02) 9602 6971
Email:
sales@hyquestsolutions.com.au
Web:
www.hyquestsolutions.com.au
1 of 33
Issue 1.7
3 Nov, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDC100 and is the answer not in the manual?

Questions and answers

Related Manuals for HyQuest Solutions WDC100

Summary of Contents for HyQuest Solutions WDC100

  • Page 1 HyQuest Solutions Pty Ltd INSTRUCTION MANUAL WIRELESS DATA COLLECTOR MODEL WDC100 QUALITY SYSTEM ISO:9001 CERTIFIED HYQUEST SOLUTIONS PTY LTD PO BOX 332, LIVERPOOL B.C NSW 1871, AUSTRALIA Phone:(Int.) 612 9601 2022 Fax: :(Int.) 612 9602 6971 Phone:(Nat.) (02) 9601 2022 Fax: :(Nat.) (02) 9602 6971 Email: sales@hyquestsolutions.com.au...

  • Page 2: Table Of Contents

    HyQuest Solutions Pty Ltd TABLE OF CONTENTS Product Overview ................4     Installation ..................5       Planning your System ..................5     Hardware Connections (Transmitter) ............... 8     Hardware Connections (Receiver) ..............10    ...
  • Page 3 HyQuest Solutions Pty Ltd Latest Changes in Transmitter Software Rev 1.3 (7-Dec-2011) Should only be used with Receiver S/W Rev 1.3 Perform Battery Charging control by switching solar to battery Allow the monitoring of SDI-12 data through the aM1, aM2, aM3….. aM9 commands (Previously, only the aM! Command could be used) Latest Changes in Transmitter Software Rev 1.4 (28-Mar-2013)

  • Page 4: Product Overview

    HyQuest Solutions Pty Ltd Product Overview The HyQuest Solutions Wireless Data Collector WDC100 has been designed using surface mount technology to provide a very small, ultra low power wireless SDI-12 and 4-20mA transmitter / SDI-12 receiver network that can be used in harsh environments for extended periods.

  • Page 5: Installation

    915MHz band, then you may need to try different frequencies until you find one that doesn’t clash. You could have several WDC100 OutPost “Systems” operating in close proximity to each other, on different frequencies. Also note that the HyQuest Solutions’...
  • Page 6 HyQuest Solutions Pty Ltd 5. Make sure your SDI-12 Logger can log all the variables you require! All of the data returned from Transmitter #0 will be translated to appear as data from SDI-12 address #0. All the data returned from Transmitter #1 will be translated to appear as data from SDI-12 address #1.
  • Page 7 HyQuest Solutions Pty Ltd Think of the Outpost Transmitter as a data collector – grabbing data from different sensors with varying SDI-12 address, and putting the data in the Outpost Receiver so the Data Logger can retrieve it any time it likes.

  • Page 8: Hardware Connections (Transmitter)

    HyQuest Solutions Pty Ltd Hardware Connections (Transmitter) The WDC100 Transmitter can monitor 1 x 4-20mA signal + up to 9 x SDI-12 parameters (in a single transducer or scattered over 9 x transducers) + a digital input from say a TBRG rain gauge or a water flow meter + the battery voltage powering the transmitter itself.
  • Page 9 HyQuest Solutions Pty Ltd 4-20mA Transducer Transducer Power (Transducer +) Warm Up Warm Up 1,2,…,20 Secs Sample Sample 1 Sec 1 Sec The Transmitter predicts when Poll Time a poll will be received, and (Transmission Interval) takes the 4-20mA sample, so it 0,1,5,10,15,30,60 Mins is ready for the received poll.

  • Page 10: Hardware Connections (Receiver)

    HyQuest Solutions Pty Ltd Hardware Connections (Receiver) The WDC100 Receiver collects data from up to 8 x WDC100 Transmitters and it can also monitor 1 x 4-20mA signal + a digital input from say a TBRG rain gauge or a water flow meter + the battery voltage powering the receiver itself.

  • Page 11: Antenna Mounting

    HyQuest Solutions Pty Ltd Antenna Mounting Both the transmitter and receiver are supplied with a ground plane independent antenna that have 1.5dB gain. (The mounting thread of the antenna is connected to the battery –ve input.) The antenna is mounted by : ...

  • Page 12: Menu Navigation

    HyQuest Solutions Pty Ltd Menu Navigation Info about System Info about Tx’er #0 other Tx’ers highest number Display More status Tx’ers Big Digits of Tx’er #0 Show Show more More Status of Status of My Status receiver Tx’er #0 Set to 999.999 if...

  • Page 13: Configuration

    HyQuest Solutions Pty Ltd Configuration The configuration of all Transmitters is performed through the receiver LCD and buttons, and then sent to the transmitter during the next poll sequence. Both the Receiver and each Transmitter must be configured separately. Receiver Configuration “My Config”...
  • Page 14 HyQuest Solutions Pty Ltd Transmitter Configuration Arrow indicates position to change Select Big Values to be displayed Configure 4-20mA input. Enable, warmup period, transducer range, set transducer level from gauge plate, set units, zero the offset. Set polling interval 0Min  continuous (for testing) Configure Digital Input.

  • Page 15: Operation

    HyQuest Solutions Pty Ltd Operation Battery Indicator : Transmitter being Aerial symbol means Empty if BV < 11V polled 0 to 7 Transmitter responded Full if BV > 13.5V (If Tx is selected, then indicator shows voltage of that Tx’er) Status of each Transmitter : Tick ...

  • Page 16: Displaying Water Volume

    HyQuest Solutions Pty Ltd Displaying Water Volume The WDC100 has the facility to display the water volume (of a reservoir) as a function of the 4-20mA water level (Receiver S/W Rev 1.2 and below). In S/W Rev 1.3 the water volume could also be calculated from the SDI-12 #1 variable.

  • Page 17: Specification

    1 x 4-20mA : 1 x Digital Input : Battery Voltage : Volume Calculated from 4-20mA Water Level Only Indicators WDC100 Transmitter - Status LED indicator WDC100 Receiver – 128 x 64 Graphics LCD Controls WDC100 Receiver – 4 x Pushbuttons Connections...

  • Page 18: Appendix A Creating The Level To Volume Formula

    HyQuest Solutions Pty Ltd Appendix A Creating the Level to Volume Formula The WDC100 has the facility to display the water volume (of a reservoir) as a function of the water level. The function originally implemented was a 4 order polynomial. (Receiver S/W Rev 1.3 and lower) This method is kept here for completeness - some customers had...
  • Page 19 HyQuest Solutions Pty Ltd Click on one of the graph points, then right click and select “Add trendline…” Click on Polynomial and increase “Order” to 4 (to create a 4 order polynomial) Click on the “Options” tab. Select “Set intercept =” and then enter the water volume when the water level is 0.00m...
  • Page 20 + 165.76 x - 19.588 x + 0.000 (where x is the water depth in metres) For this example, the polynomial terms entered into the WDC100 are as follows : (Please note the sign of each term !!!!!) Poly0 = 0.000...

  • Page 21: Appendix B Creating The Level To Volume Mapping

    HyQuest Solutions Pty Ltd Appendix B Creating the Level to Volume Mapping Some customers found it difficult to get the 4 Order Polynomial described in Appendix A, to accurately fit their data – as shown on the Excel spreadsheet / graph below.
  • Page 22 HyQuest Solutions Pty Ltd NOTE : If the data fits nicely in only 8 points say, then repeat the last point 3 times until all 10 points are used! The 2 x Outpost configuration screens where the data is entered are shown below : There is also a new Windows tool called “OutpostConfig”...
  • Page 23 HyQuest Solutions Pty Ltd All configuration is held in the Outpost Receiver, so connect a PC to the receiver via an RS232 to SDI-12 adapter as shown, and start the OutpostConfig Application. 1. Select the RS232 Comm Port. 2. Select the Tx Number that...

  • Page 24: Appendix C Buoy Breather Bag Setup

    HyQuest Solutions Pty Ltd Appendix C Buoy Breather Bag Setup We have changed the transducer venting in the Buoy for several reasons : ‐ Vented transducers always have a problem with moisture collecting in the vent tube. ‐ Venting the vent tube to atmosphere means that the electronics PCB is also vented to atmosphere, which in a marine environment will ultimately lead to corrosion forming.
  • Page 25 HyQuest Solutions Pty Ltd 1. Remove the 4 corner screws securing the metal lid to the electronics enclosure. A plastic tube from the breather bag enters the lid as shown. Remove the joiner and smaller tubing.   Smaller tubing Joiner  ...
  • Page 26 HyQuest Solutions Pty Ltd 5. After feeding the INW submersible cable through the cable gland at the base of the electronics enclosure, fit a large cable tie and do it up tight as a strain relief. Now do up the cable gland to secure the submersible cable.

  • Page 27: Appendix D Sending Custom Sdi-12 Commands

    HyQuest Solutions Pty Ltd Appendix D Sending Custom SDI-12 Commands Once a system is installed and operating, it may be convenient to remotely access a sensor’s SDI-12 custom command set - to adjust a parameter, read an internal setting etc.
  • Page 28 Method 1 : Connect a PC to the Outpost Receiver via an “RS232 to SDI-12” adapter (available from HyQuest Solutions) and run the application supplied, called “Outpost Express”. (This application will encapsulate the SDI-12 command and monitor its progress through the...
  • Page 29 HyQuest Solutions Pty Ltd To operate the “Outpost Express” application, first select the comm port that is connected to the RS232 to SDI- 12 adapter. (If unsure of the COM number, select them one at a time until comms is achieved!)
  • Page 30 HyQuest Solutions Pty Ltd As the transmission sequence occurs, various messages will appear which indicate the request progress. When complete, the SDI-12 response from the command will be passed back through the network and appear as a green highlighted message – as shown.
  • Page 31 HyQuest Solutions Pty Ltd Method 2 : If the Data Logger or RTU connected to the Outpost System has an “SDI-12 Transparent” mode, the required custom command may be sent through the Data Logger or RTU. If the Data Logger or RTU is connected via a modem, then these commands may be sent through a 3G telemetry network –...
  • Page 32 HyQuest Solutions Pty Ltd The SDI-12 X-Command format is as follows : Request a Custom Command : As with any SDI-12 command, the first byte is the address of the transmitter, and in the case of the Outpost, this is a number 0 to 7. This SDI-12 command directs a custom command to a particular sensor on a particular Transmitter.
  • Page 33 HyQuest Solutions Pty Ltd *** NOTE *** ‐ Commands will occur faster if the poll time to a Transmitter is set to “0Min”. ‐ If the poll time is set to any time other than “0Min”, the remote Transmitter will only respond to the SDI-12 command request when it wakes up on the next 1 minute interval.
