- Page 1 User Manual...
-
Page 2: Table Of Contents
More Buttons ............................13 GPRS / GSM Setup ............................14 Two Point Calibration ..........................15 Tare ..................................16 Maintenance Part IV HyQuest Solutions GP-Shell – local Software ..................17 Loggers ................................17 Repair Part V Technical Data Part VI Obligations of the Operator and Disposal Part VII Obligations of the Operator ........................ -
Page 3: I Disclaimer
HyQuest Solutions or KISTERS AG. Other product documentation and the information contained in it, names used may or may not be the trademarks of even if HyQuest Solutions has been advised of the their respective owners. possibility of such damages. -
Page 4: Safety Instructions
Before starting to work, you have to check the functioning and integrity of the system. § Check for visible defects on the iLevel-GW, this may or may not include any or all of the following mounting facilities, connectors and connections, mechanical parts, internal or external communication devices, power supplies or power supply lines, etc. -
Page 5: Specific Safety Instructions
§ The manual provides information on how to operate the sensor system. § HyQuest iLevel-GW is intended to be used in hydrological surveys, and more specifically to determine groundwater and surface water levels. § Never use the the HyQuest Solutions iLevel-GW to transport people! §... -
Page 6: Part I Introduction
433 MHz near field radio interface for all local communications. The wireless technology allows to connect to an iLevel-GW installed in a borehole or other 2” pole without any need to remove or even touch the device. -
Page 7: Part Ii Installation
"Push Open", so that the latch releases the drawer. To lock, simply press your finger on the drawer slightly again and push it in the other direction which is marked "Push Open" until the latch closes. © 2022 HyQuest Solutions... -
Page 8: Assembling And Changing Batteries
The time has to be synchronized again. Initial Commissioning Due to European law, devices will be shipped deenergized only. See Assembling and Changing Batteries on how to fit the batteries. © 2022 HyQuest Solutions... -
Page 9: Configuration
Configuration The software HyQuest Solutions GP shell is used for local communication between a PC and the iLevel-GW data logger. For the communication, a 433 MHz radio link is used. Using HyQuest Solutions GP shell, the parameters of the logger can be configured and measured values are shown directly. -
Page 10: Setup
Under normal circumstances, this option will not be needed. As the data is not coming from HyQuest Solutions GP- Shell but directly from the logger, the language settings of GP-Shell will be ignored. The output will always be in English. -
Page 11: Main Window
Parameters: Opens a menu for configuring a logger. The logger must be identified first. § Data from Disk: Open Files that have been downloaded to the local computer previously, i.e. measured values (i.e. *.g2p files). § Exit: Closes the application. © 2022 HyQuest Solutions... -
Page 12: Parameters
This allows to monitor the water level in real-time, for example when changing water levels by pumping. The shortest possible measuring period is two seconds. § There are 3 modes for the live mode: © 2022 HyQuest Solutions... -
Page 13: Scale
§ Type: Drop Down Menu. Choose between SDI (for general SDI sensors i.e. temperature), SDI12-Pressure (for the pressure channel of the iLevel-GW and wireless sensor (to connect more sensors via near field radio) § No measure, use cached values: must be enabled if a sensor sends multiple values (i.e. pressure and temperature) §... -
Page 14: Gprs / Gsm Setup
GPRS repeat: By activating the check box the logger is allowed to repeat transmissions up to 3 times in case a transmission has failed. For different reasons, such as high network load, transmissions can fail from time to time. If this option is enabled, waiting for the repeated transmission and sending again, consumption battery power. © 2022 HyQuest Solutions... -
Page 15: Two Point Calibration
Y1,Y2 (nominal): Enter the measured value of the sensor § Y1,Y2 (actual): Enter a measured value of a reference. § Calculate and OK: Save the settings to the parameter set. § Reset Coefficients: Restore the original parameters of the sensor. © 2022 HyQuest Solutions... -
Page 16: Tare
Calculate and OK: If all settings are completed, click “Calculate and OK”. The software now calculates the values for the data fields “Offset” and “Multi”. § Reset calibration: Set the values for Multi and Offset to the default settings (Offset = 0.00, Multi = 1.00) § Cancel: Close the windows without changing any settings. © 2022 HyQuest Solutions... -
Page 17: Part Iv Maintenance
§ Loggers HyQuest Solutions GP-Shell – local Software The software “HyQuest Solutions GP-Shell” does not require any maintenance by the customer. If an updated version is released. Loggers Our loggers only require very low maintenance. Do not use any sharp tool or any aggressive cleaning agent to clean the hardware. -
Page 18: Part V Repair
In rare cases, a product may not be delivered in accordance with your order. In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following: 1. Contact HyQuest Solutions using the Repair Request Form made available online: https://www.hyquestsolutions.eu/fileadmin/Form/Telemetry_Solution_app.jpg.pdf... -
Page 19: Part Vi Technical Data
§ Seals: Viton (EPDM or Kalrez optional) § Cable: PUR (standard), PE (drinking water) or FEP (chemical resistant, Teflon-impregnated) Dimensions: Diameter Typically 24 mm Ø, 157 mm length, 200 g (without cable) Ø, Length, Mass Conformity/Complian © 2022 HyQuest Solutions... -
Page 20: Part Vii Obligations Of The Operator And Disposal
Instead, these old appliances must be collected separately and disposed of via the local collection and return systems. Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the designated collection point. © 2022 HyQuest Solutions... - Page 21 Obligations of the Operator and Disposal EU WEEE Directive As players in the environmental market, KISTERS AG and HyQuest Solutions are committed to supporting efforts to avoid and recycle waste. Please consider: Avoidance before recycling! Recycling before disposal! This symbol indicates that the scrapping of the unit must be carried out in accordance with Directive 2012/19/EU.
-
Page 22: Part Viii Appendices
This can happen due to material expansion caused by big temperature difference. Please replace O-rings and cable couplings to avoid damage. Please contact the customer support. HyQuest Solutions GP-Shell – local Software § Error message during installation: No Interface 'Wireless Dongle' found §... - Page 23 Contact Data Europe | HyQuest Solutions (KISTERS AG) +49 2408 9385 0 info@hyquestsolutions.eu Australia | HyQuest Solutions Pty Ltd +612 9601 2022 sales@hyquestsolutions.com.au New Zealand | HyQuest Solutions NZ Ltd +64 7 857 0810 sales@hyquestsolutions.co.nz Latin America | HyQuest Solutions (KISTERS LATAM) +57 350 575 4079 sales-latam@hyquestsolutions.com...
- Page 24 © 2022 HyQuest Solutions 21.04.2022...
