Item #1005 443 074
Model #CX1500EVB
USE AND CARE GUIDE
GABLE MOUNTED VENTILATOR FAN
Questions, problems, missing parts? Before returning to the store,
call Everbilt Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Everbilt through the purchase of this ventilator fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Everbilt!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Everbilt CX1500EVB
Summary of Contents for Everbilt CX1500EVB
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Everbilt through the purchase of this ventilator fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your...
-
Page 2: Table Of Contents
Table of Contents Safety Information ........2 Installation —... -
Page 3: Warranty
Warranty The manufacturer extends this warranty to the original retail purchaser of its model or, if this unit is purchased and installed by a new home builder, then to the original owner of the home. No subsequent purchaser of the unit or of a home in which it is installed is entitled to any of the benefits of this warranty. -
Page 4: Tools Required
Pre-Installation TOOLS REQUIRED 14-gauge Phillips Flathead Wood Speed electric screwdriver screwdriver screws square wire Portable Personal Straight Measuring Pencil electric protective edge tape drill equipment PACKAGE CONTENTS Part Description Part Description Mounting bracket nut Gable mount fan Mounting bracket bolt Thermostat assembly Mounting bracket... -
Page 5: Installation - Wall-Vent Mounted
Installation — Wall-Vent Mounted This gable-mounted unit is designed for attics of average size and operates most efficiently when air intakes are located around the eaves. Alternatively, air intake may be from opposing gable vents, but never from roof or ridge vents. At least 600 sq. in. of net free air intake is required per unit for safe and efficient operation. -
Page 6: Installation - Triangular Gable Vents
Installation – Wall-Vent Mounted (continued) Installing the shutter □ With the mounting nuts (D) and mounting bolts (E), secure the 4 mounting brackets (C) to the shroud and then fasten the unit to the frame. NOTE: Mounting the long side of the L brackets with the long side to the shroud may better fit your installation and help reduce vibration. - Page 7 Installation – Triangular Gable Vents (continued) Covering the opening and cutting Framing the opening the hole □ For new installation or installation behind existing louvers, □ Cover the opening with a square piece of plywood, using 2 x 4 studs, frame an opening at least 18 ¼-in square paneling, or sheetrock, at least 21 ¼-in square (depending (depending on stud spacing) on center, on the attic side of on stud spacing).
-
Page 8: Installation - Thermostat
Installation – Thermostat WARNING: Turn off the electrical current to the unit before attempting any service work. If you are unfamiliar with methods of installing electrical wiring, secure the services of a qualified electrician. All electrical connections must be in accordance with local codes and ordinances, and/or with national electrical codes. □... -
Page 9: Maintenance
Maintenance Disconnect the power before you perform WARNING: any maintenance □ Check the electrical connections annually. □ Ensure that the housing is unobstructed and free of debris to allow proper air flow. □ Ensure that the gable vent shutters are operating properly. Care and Cleaning Disconnect the power before you perform WARNING:... - Page 10 Questions, problems, missing parts? Before returning to the store, call Everbilt Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
