- Page 1 Peavey 6505 ® ® Tube Guitar Amplifier Operating Manual www.peavey.com...
- Page 2 (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the user’s authority to use the equipment.
- Page 3 ® Congratulations on your purchase of the all new 6505® II. Peavey's classic high-gain legacy continues with the 6505® II. Like the original 6505 head, the 6505 II offers two channels. However, the 6505 II adds separate EQ, Resonance, and Presence controls to each channel, giving you more control and flexibility.
-
Page 4: Ground Switch
PREAMP OUT This output can be used to send a preamp signal from the 6505 II to a mixing console, tape recorder, etc., using a shielded instrument cable. Patching from the PREAMP OUT does not affect the... -
Page 5: Channel Select Switch
Power Switch when power is being supplied to the unit. (11) STANDBY SWITCH/LED This switch allows the 6505 II to be placed in a non-operational standby mode. When the Standby Switch is activated, the tubes remain hot and ready for instantaneous operation, eliminating warm-up time. -
Page 6: Bright Switch
(5-10) and the Post Gain should be set for overall volume. (19/20/21) EQUALIZATION The 6505 II’s equalization block features passive low, mid, and high EQ that is custom tailored for each channel to classic Peavey specifications. Adjusting the control(s) counterclockwise will result in an attenuation of the signal within the frequency band. -
Page 7: Signal Flow Block Diagram
6505 5150 ® SPECIFICATIONS POWER AMPLIFICATION PREAMP SECTION EFFECTS RETURN: Impedance: Very High Z, 470 k ohms SECTION The following specs are measured @ Designed Level: -10 dBV, 300 mV RMS 1 kHz with the controls preset as follows: RATED POWER AND LOAD: Low and High EQ @ 10 120 W RMS into 16, 8, or 4 ohms PREAMP OUT:... - Page 9 Warranty registration and information for U.S. customers available online at www.peavey.com/warranty or use the QR tag below Features and speci cations subject to change without notice. Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
