- Page 1 AP-Xtreme Sim-Racing Chassis Master Assembly Guide SECTION C: Display Support Assembly Page C-1 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 2 Refer to the main chassis you are assembling and advance to the page indicated below. Skip section C. Proceed to Section D. APX-1000 (No Display) Proceed to next page. Overhead Auxiliary Display Proceed to page Error! Bookmark not defined.. APX-2000 (Single Display) Proceed to the next page.
- Page 3 This page applies when the overhead display mount is being installed. A5 x 2 W1 x 2 H2-1 x 2 CV1 BRK (Optional) Install with larger hole A16 x 2 to top. Threaded End Up C2-2 x 2 W1 x 2 E5VR N1 x 2 Compact...
- Page 4 Proceed to next page. APX-2000 (Single Display) Proceed to page 7. APX-3000 (Triple Display <32”) Proceed to page 17. APX-3000UW (triple Display >32”) Page C-4 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 5 A5 x 1 W1 x 1 H2-1 x 1 C2-2 x 2 W1 x 2 N1 x 2 Install E5 unless E5VR was installed in the previous step. Page C-5 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 6 C2-1 x 2 W1 x 2 N1 x 2 A9 x 1 Install A9 for a single display. DO NOT INSTALL THIS IF YOUR SIM IS CONFIGURED AS TRIPLE DISPLAY. If you are building an APX-2000 (Single Display) then you are finished with this section. Proceed to Section D. Page C-6 Revised: 3/9/2020 Last Edited by: FR...
- Page 7 This page only applies to APX-3000. C2-2 x 4 W2 x 4 N2 x 4 A5 x 2 W2 x 2 H2-1 x 2 If you have the Dual Sensor VR E5 x 2 Option then Threaded install E5VR with End Up CV1 Bracket Install the 2 vertical monitor rails using the hardware indicated.
- Page 8 This page only applies to APX-3000. C2-1 x 4 W2 x 4 N2 x 4 A6 x 2 Mount the transverse brackets at the same height using the hardware shown above. Snug the nuts to prevent the brackets from sliding down, but do not overtighten. Page C-8 Revised: 3/9/2020 Last Edited by: FR...
- Page 9 This page only applies to APX-3000. C2-1 x 4 W2 x 4 N2 x 4 Mount the transverse rail to the transverse brackets using the hardware indicated above. Center the rail onto the chassis and insure the rail is level. The rail is centered when there is exactly 7.5 inches overhanging on each side. Tighten the nuts securely.
- Page 10 This page only applies to APX-3000. C2-1 x 8 W2 x 8 N2 x 8 Mount the angle plates to the transverse bar as shown above using the hardware indicated. Page C-10 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 11 This page only applies to APX-3000. C2-1 x 2 W2 x 2 N2 x 2 Mount the monitor bracket backing plate in the center of the transverse bar using the hardware indicated as shown with the wide end toward the top. Page C-11 Revised: 3/9/2020 Last Edited by: FR...
- Page 12 This page only applies to APX-3000. C2-1 x 8 W2 x 8 N2 x 8 Threaded End to Outside Set E7 flush to the notch as shown Pre-install the hardware on the angle plate and then slide in the E7 lateral bar until it is flush to the notch. Snug the fasteners to keep them in place.
- Page 13 This page only applies to APX-3000. A8 x 2 C2-1 x 4 W2 x 4 N2 x 4 Mount the 2 remaining monitor backing plates to the lateral bars using the hardware shown. Page C-13 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 14 This page only applies to APX-3000. A5 x 4 H2-1 x 4 W2 x 4 Install the end caps on the transverse and lateral bars. Page C-14 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 15 This page only applies to APX-3000. A9 x 3 Attach to back of monitors using screws provided Attach receiver plate to backing plate. H2-1 x 6 W2 x 6 Snap monitor and bracket onto receiver plate. (Monitor omitted for clarity) End here.
- Page 16 This page only applies to APX-3000UW. C2-2 x 4 W1 x 4 N1 x 4 A5 x 2 W1 x 2 H2-1 x 2 E5 x 2 Threaded End to Top Install the 2 vertical monitor rails using the hardware indicated. Page C-16 Revised: 3/9/2020 Last Edited by: FR...
- Page 17 This page only applies to APX-3000UW. A11 x 2 C2-1 x 8 W2 x 8 N2 x 8 E8 x 2 Mount the angle brackets to the inner sides of the verticals using the side with the holes that are spaced closer together. Then mount the E8 cross-pieces to the brackets.
- Page 18 This page only applies to APX-3000UW. C2-1 x 8 W2 x 8 N2 x 8 A7 x 4 Mount the swivel plates to the cross-piece as shown. Page C-18 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 19 This page only applies to APX-3000UW. C2-1 x 8 W2 x 8 N2 x 8 E9 x 4 Threaded End to Outside Mount the lateral extensions on each side as shown above. Set E9 flush to the notch as shown Page C-19 Revised: 3/9/2020 Last Edited by: FR...
- Page 20 This page only applies to APX-3000UW. A9 x 3 C2-1 x 6 W2 x 6 N2 x 6 Mount the back bracket for the VESA support to the cross-pieces. Page C-20 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 21 This page only applies to APX-3000UW. C2-1 x 8 W2 x 8 N2 x 8 A13 x 2 Mount the support plate as shown. Do not tighten the bolts yet. Page C-21 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 22 This page only applies to APX-3000UW. H2-1 x 8 W2 x 8 A12 x 4 Install the end caps as shown. Page C-22 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 23 This page only applies to APX-3000UW. Attach to back of displays using screws provided C2-1 x 6 W2 x 6 N2 x 6 If monitors tip toward driver after they are installed add 1 or 2 W2 washers between the bracket and aluminum extrusion as shims.
- Page 24 This page only applies to APX-3000UW. Tighten 4 First Lift nuts to and hold retain position Mount the displays and adjust the positioning of the side arms and VESA brackets. It may be necessary to place some upward preload on the arms before tightening the braces to counteract the weight of the monitors. Page C-24 Revised: 3/9/2020 Last Edited by: FR...
