Page 1: Section B: Main Chassis Assembly
AP-Xtreme Sim-Racing Chassis Master Assembly Guide SECTION B: Main Chassis Assembly Page B-1 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual... - Page 2 If you have assembled the SlipSense Assembly from Section A then skip to the next page! Place Rails E1 on the ground as shown. Slide 6 C2-1 carriage bolts into the slots as shown and secure each A10 vibration foot even with each end with the indicated washer and nut. Tighten these bolts. Then loosely secure the floor brackets about ¼...
- Page 3 Drill these for GTpro3 Floor Mount Pedals B1 Bottom Side Using a ¼” (7mm) drill bit drill through the partial holes according to the pedals you are using. These holes may have been drilled for you before it shipped. It will be easier to attach these pedals to the floor now. N3 x 3 Partially drilled holes...
- Page 4 C1-2 x 2 W1 x 2 N1 x 2 W2 x 4 H2-2 x 4 Turn the E1 rails so they stand on the rubber vibration feet. Lower the assembled floor and front cap between the rails and secure using the indicated bolts and washers at the front. Then slide the floor brackets into alignment with the holes on the floor and secure using the fasteners indicated.
- Page 5 Refer to the pedals you will be installing and advance to the section indicated below. If you will be installing Thrustmaster or Logitech pedals in the inverted position please advance to page 6. If you will be installing GTpro3 or other floor mounted pedals please advance to page 11.
- Page 6 This page only applies to the Thrustmaster/Logitech Inverted Pedal Mount B3 x 2 C2-2 x 4 W2 x 4 N2 x 4 Attach the pedal arches pointing back toward the driver as shown. Slide 2 carriage bolts C2-2 into the upper inside rail from the rear of the rail.
- Page 7 This page only applies to the Thrustmaster/Logitech Inverted Pedal Mount N3 x 4 W1 x 4 H1-3 x 4 Attach the pedal deck B4 to the pedal arches using the hardware indicated. Do not tighten these until the final position has been determined.
- Page 8 This page only applies to the GTpro1 Inverted Pedal Mount C2-2 x 4 W2 x 4 N2 x 4v B14 x 2 Install B14 arched panels using hardware indicated above E12 x 2 H2-2 x 4 W2 x 4 Slide three specialized insets into the bottom slot of each E12 extrusion. Mount using the hardware indicated above. Please advance to page 11.
- Page 9 This page only applies to the Dead Pedal Assemble the dead pedal to achieve the desired positioning as shown below. H1-3 x 2 N1 x 2 W1 x 2 W1 x 2 Assemble the pedal as shown above. Page B-9 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 10 This page only applies to the Dead Pedal C2-2 x 4 W2 x 4 N2 x 4v Page B-10 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 11 B5 x 2 C2-2 x 4 W2 x 4 N2 x 4 Slide C2-2 carriage bolts into each outer slot of the rails. Mount the pedal arches to the outside of the rails as shown. Do not tighten the bolts until final positioning is determined. Page B-11 Revised: 3/9/2020 Last Edited by: FR...
- Page 12 N3 x 4 W1 x 4 H1-3 x 4 Mount the B6 wheel deck using the fasteners indicated. Do not tighten these bolts until final position is determined. Page B-12 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 13 This page only applies if installing g-Sense belt tensioners C2-4 x 2 If installing seat belts as part of the g-Sense active seat belt system, then pre-install the extra bolt shown above on each side. Page B-13 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 14 B7 x 2 C2-2 x 4 W2 x 4 N2 x 4 Mount the B7 rear wings using the fasteners indicated. Align them even with the back of the rails and tightened them into place. E4 x 1 H1-2 x 1 W1 x 1 C1-2 x 2 W1 x 2...
- Page 15 H1-2 x 1 W1 x 1 C1-2 x 3 W1 x 3 N1 x 3 E2 x 1 Take one E2 rail and install 2 C1-2 carriage bolts toward the front and 1 C1-2 carriage bolt near the rear of the chassis. Page B-15 Revised: 3/9/2020 Last Edited by: FR...
- Page 16 C1-1 x 2 2 Tall 2 Short Insert 2 C1-1 carriage bolts into the slots as shown in preparation for mounting one of the Ricmotech seats. Screw the B13 end bracket into the end of cross-member E3. Page B-16 Revised: 3/9/2020...
- Page 17 C2-2 x 8 W2 x 8 N2 x 8 Pre-thread the C2-2 bolts, washers and nuts onto the B13 brackets. Slide the crossmembers into the bottom slot using the taller one for the front crossmember and the shorter one for the rear cross-member. Finger-tighten the bolts until the seat is installed and its final position can be determined.
- Page 18 Install B8 only if installing a Thrustmaster or Logitech Shifter C1-2 x 2 Install B8-SQ only if installing a W1 x 2 Quaife PSL Sequential Shifter N1 x 2 Mount the B8 Shifter mount on the 2 inner holes using the hardware indicated. Page B-18 Revised: 3/9/2020 Last Edited by: FR...
- Page 19 If you did not install B8 from the previous step then you will need to support E2 until the next step. C1-2 x 2 W1 x 2 E2 x 1 N1 x 2 H1-2 x 1 W1 x 1 Slide intwo additional C1-1 on the Slide in two additional C1-1 if inner slots of both E2 rails if mounting a hand brake...
- Page 20 If you will be installing an H-pattern Pro shifter you will install B9-H instead with the cup holder opening to the rear. C1-2 x 4 (or 6) B9-S W1 x 4 (or 6) N1 x 4 (or 6) Mount the Keyboard tray underneath the E4 rails and secure with the hardware indicated. The cup holder may be oriented to the front if no shifter is present, otherwise orient toward the back.
- Page 21 If you will be installing a Fanatec Clubsport shifter then install the mounting brackets now. C1-2 x 4 W1 x 4 N1 x 4 Mount the Fanatec Shifter adapters as shown using the hardware indicated. Save the M4 screws included with the brackets to mount the shifter later.
- Page 22 Refer to the main chassis you are assembling and advance to the page indicated below. Skip to page 25. APX-1000 APX-2000 Proceed to next page. APX-3000 APX-3000UW Page B-22 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 23 C1-2 x 6 W1 x 6 N1 x 6 Orient B11 depending on display size to be used to position the display the appropriate distance from the driver. Assemble the B11 monitor uprights using the hardware indicated. Do not tighten the nuts until final placement has been determined. Page B-23 Revised: 3/9/2020 Last Edited by: FR...
- Page 24 Wiring hole for WindSense. Install toward NEW B12 right side when PANEL viewed from seated position. W1 x 6 N3 x 6 H1-3 x 6 Mount the monitor transverse panel between the uprights with the hardware shown. Tighten these securely. Page B-24 Revised: 3/9/2020 Last Edited by: FR...
- Page 25 This page only applies to installing shakers. Use the hardware provided with them to mount the shaker to the bracket. C2-1 x 2 W2 x 2 N2 x 2 The recommended location for a single shaker is as shown. Dual shaker can be mounted in opposite corners. The shakers may be mounted upside-down but must always be mounted vertically for prolonged life.
- Page 26 W2 x 4 H2-2 x 4 Install the rear cap using the fasteners indicated. Tighten these down fully. Page B-26 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 27 H1-2 x 2 W1 x 2 Secure the rear of the shifter rails to the rear cap using the hardware indicated. Page B-27 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 28 W1 x 4 H1-3 x 4 N3 x 4 Secure the rear cap to the rear wings using the hardware indicated. Tighten these bolts securely. Page B-28 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
- Page 29 W1 x 1 H1-1 x 1 Install the cap to the end of the entry-side support rail using the hardware indicated. Page B-29 Revised: 3/9/2020 Last Edited by: FR APX 1000+ Assembly Manual...
