Summary of Contents for THIEYE Carbox 6
- Page 1 Dash Cam Carbox 6 User Manual Carbox 6 How-to Video...
- Page 2 USER MANUAL ..............Deutsche Anleitung ............取り扱い説明書 ..............Guide de démarrage rapide ..........Guida di Operazione Rapida .......... Manual de usuario ............. Руководство пользователя ...........
-
Page 3: Packing List
Packing List English Dash Cam Carbox 6 Suction Cup Mount 3.5M Car Charger Plastic Crowbar User Manual Optional 1 Rear Camera 6M Rear Camera Cable Rear Camera Screw x 2 3M Glue for Rear Camera Optional 2 GPS Antenna... - Page 4 Layout AV Output Port TF Card Slot Chimeric Insert Up Button Mini USB Port Menu Button OK Button Down Button Mode Button Lens Lock Button Screen Power Button Reset Speaker Microphone Indicator...
-
Page 5: Screen Display
Screen Display Video Mode Exposure Compensation Red Dot (It means recording) Motion Detection Lock License Plate Number Microphone G-sensor Time & Date Video Resolution Parking Monitor Recording Time TF Card Loop Recording Battery Status * When some icons appear on the screen, it means the function is enabled. -
Page 6: Led Indicators
LED Indicators Indicators Status Instructions Red Indicator Is On Charging Blue Indicator Flashes Recording Specifications Screen Size 3.0 inch Image Sensor 2 MegaPixel Lens View Angle 170° Video 1920*1080 / 30FPS (MOV) Photo 4032*3040 (JPG) TF Card Support up to 64GB Storage Compression MJEPG Storage Temperature... - Page 7 Note: * Please use a Micro SD card of at least 32GB. (Over Class 10) * To keep your Micro SD Card in good condition, please format it regularly. As reformatting erases all of your contents, be sure to back up your photos and videos first.
- Page 8 (4) When the car is turned off, connect the dash cam to the car outlet with the car charging cable. (5) Hide the power cable in the gap of the car. (6) Start the engine and Carbox 6 will automatically turn on.
-
Page 9: Basic Instruction
Basic Instruction 1.Power On / Off (1) Auto power on / off with ignition When powered by the car charger, the dash camera will automatically turn on recording when you start your car engine. When turning off your car, the camera will automatically turn off after approximately 5 seconds. - Page 10 In playback mode, press and hold the up button to switch folders of the front and rear camera. 4.Video Mode In video mode, press the OK button to start / stop manual recording. When in recording, red dot and blue indicator will flash. ·Press the lock button to lock the recording in progress.
-
Page 11: Menu Settings Instruction
Menu Settings Instruction Press the menu button to get into the menu settings. During the setting, press the up and down buttons to select, and press the OK button to confirm. After the setting is completed, press the menu button to exit the setting. 1.Video Menu Settings In video mode, when not recording, press the menu button to enter the video menu settings. - Page 12 detected by dash cam. It will stop recording when motion disappears. * Motion detection will result in variable recording duration. If you need record continuously, please turn off the motion detection. Audio record Date Stamps Gravity Sensing After turning on G-sensor, it will lock the recording when detecting a collision during the recording.
-
Page 13: Basic Settings
Basic Settings Press the menu button twice to get into the basic settings interface. Screen Saver The screen display will be turned off after a period of inactivity. The camera is still recording when the screen display turns off. Press the power button to activate the screen. Auto shut down Light Source Frequency Button Sound... - Page 14 Accessories Installation & Instruction 1.Install the Rear Camera (Need to be purchased) The installation location of rear camera is actually quite flexible, so there some recommended locations with different angles of visions. A: Install on the rear windshield. B: Install above the license plate. Connect the red wire to the reverse light Please identify the wire that feeding the reverse light from rear light cluster, although its placement may vary, make sure to refer to your car’s manual.
- Page 15 Mounting Bracket 6 Meters Rear Camera Cable Rear Camera Trigger Wire for Reverse Light (Red) AV Out Connect to Dash Cam Note: The installation illustrations are for your reference only. The placement of the devices and cables may vary depending on the car model. If you encounter any problems during installation, contact a skilled installer (such as the service personnel of the car) for assistance.
- Page 16 Red: not conncted Yellow: In preparation Green: Operates normally 0 0 0 KM/H Speed Display The icon turns “Red” to indicate that no satellite and location has been found, and “Green” indicates that the search for satellite is completed and the positioning is accurate.
- Page 17 (2) Download the dedicate GPS player via link, click here: http://www.thieye.com/download/gpsplayer Note: With TF card inserted, when the GPS Module connects to the dash cam, an installation file of the GPS player will be generated in the root directory of the TF card.
-
Page 18: Troubleshooting
interference or metal composition shelter, etc. * Weather Factors: Sunspots; severe weather (such as typhoon, etc.) * Other Factors: Human interference (such as SA policy, Microwave transmitter); GPS satellite orbit; Electromanetic interference noise around GPS equipment; Surrounding transmitting stations or mobile base station, etc. Troubleshooting If the machine freezes, reboots repeatedly and fails to boot, please try the following methods:...
