Safeel Zero
Dash Cam
USER MANUAL
PSFZ - V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Safeel Zero and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for THIEYE Safeel Zero

Summary of Contents for THIEYE Safeel Zero

  • Page 1 Safeel Zero Dash Cam USER MANUAL PSFZ - V1.0...

  • Page 2: Table Of Contents

    Contents Part 01 - Getting Started Part 03 - Menu Settings Instruction ..........01 1. Packing List 1. Video Settings ..............12 ........02 2. Product Overview a. Resolution ..............13 .....03 3. Button Usage and Operation b. Loop Recording ............13 ..........04 4. LCD Screen c.
  • Page 3 3. System Menu Settings ............18 a. Screen Saver ..............19 b. Auto Power Off ..............19 c. Frequency ...............19 d. Beep Sound ..............20 e. Language ................20 f. Screen Rotation ...............20 g. Date/Time ................20 h. Format ................21 i. Default Setting ..............21 j. Upgrading Firmware ............21 Part 04 - Installation ........22...

  • Page 4: Part 01 - Getting Started

    Part 01 - Getting Started 1. Packing List Dash Cam Suction Cup Mount Adhesive Mount Static Stickers Car Charger with Micro USB Cable User Manual Additional USB...

  • Page 5: Product Overview

    2. Product Overview Threaded Insert Speaker Down Button Reset Micro SD Slot 1.5” LCD Screen 170° Wide Angle Lens Power / Mode Button Micro USB Port Microphone Up Button Status Indicator OK Button...

  • Page 6: Button Usage And Operation

    3. Button Usage and Operation Mode Switching ★ When the camera is Powered ON, repeatedly press Power / Mode Button “ ” to switch mode, there will be modes: Video, Photo, Playback, Settings. ★ Menu Switching When the camera is Powered ON, repeatedly press Power / Mode Button to switch to Settings, then you must press OK Button to enter menu settings, there will be: Video Settings, Photo Settings, System Settings, Exit Settings.

  • Page 7: Lcd Screen

    4. LCD Screen File Lock icon Motion Detection icon Video Resolution TF Card icon Battery Status 1080P 30FPS Microphone icon Date/Time 00：02:58 2019/02/03 04:56:06 Recording Status: When Recording 00：00:00 2019/02/03 04:56:06 Recording Status: When Not Recording...

  • Page 8: Led Indicators

    5. LED Indicators Status Blue Indicator Light When Recording Continuous Flash When Not Recording Constant ON Part 02 - Basic Operation 1. Insert TF Card Inserting the Micro SD Card · Open the slot cover and insert the Micro SD card into the slot and push until it locks into place.

  • Page 9: Power On/Off

    Cautions To keep your Micro SD card in good condition, please reformat it regularly. As reformatting ★ erases all of your content, be sure to offload your photos and videos first. ★ Ensure that the device is completely off before removing the Micro SD card to avoid damages to the memory card.

  • Page 10: Video Mode

    Manual Power On/Off - Switching the camera OFF manually and pulling off the car charger ★ is required for vehicles where the vehicle’s power socket provides continuous power after the engine is turned OFF. · To turn the power off manually, press and hold the power button for at least 3 seconds until the camera is powered off.
  • Page 11 Tips The blue indicator light FLASHING means the dash cam is recording, and it’s CONSTANT ON means the dash cam is not recording. Button Action 1080P 30FPS When not recording: Switch to Photo/Playback/Settings Mode POWER / MODE When recording: Manually Lock File Enable/Disable Audio Start / Stop Video Recording 00：02:58...

  • Page 12: Photo Mode

    4. Photo Mode After being powered on, the dash cam enters the video mode and automatically starts recording. ★ Press OK Button to stop recording. ★ ★ Press Power/Mode Button to switch to photo mode. The photographing icon is displayed on the upper left corner of the screen.

  • Page 13: Playback Mode

    5. Playback Mode After being powered on, the dash cam enters the video mode and automatically starts recording. ★ Press OK Button to stop recording. ★ ★ Press Power/Mode Button twice to switch to playback mode. · In playback mode, press Up/Down Button to choose photo/video file. ·...

  • Page 14: Settings Mode

    6. Settings Mode After being powered on, the dash cam enters the video mode and automatically starts recording. ★ Press OK Button to stop recording. ★ ★ Press Power/Mode Button twice to switch to settings mode. ★ Short press OK Button to enter menu settings. Button Action Switch to Video Recording Mode, and...

  • Page 15: Part 03 - Menu Settings Instruction

    Part 03 - Menu Settings Instruction 1. Video Settings When the camera is Powered ON, it enters the video mode and automatically starts recording. ★ Short press OK Button to stop recording. ★ Repeatedly press Power / Mode Button to switch to Settings mode, then you MUST Press OK Button to enter menu settings.
  • Page 16 ① Video Resolutions: FHD 1080P 30fps / HD 720P 30fps ② Loop Recording Default: 3 Minutes In the case of recording and saving at interval of 3 / 5 / 10 minutes, the dash cam will automatically overwrite oldest file in the memory card once the memory is full. (Note: any locked video files on the memory card will remain protected, and will not be automatically deleted during Loop Recording.) Tips...
  • Page 17 Tips · If you turn on the motion detection function, it only works when the dash camera is Powered ON, the camera will record when it detects motion, which will cause discontinuous recording. · If you need record continuously, we suggest that you should turn off the motion detection function.

  • Page 18: G-Sensor

    ⑥ G-sensor Default: Medium G-sensor will lock the file when detecting a collision during the recording, and the file won't be overwritten by loop recording. The G-sensor sensitivity can be selected OFF / High / Medium / Low in the menu. 1080P 30FPS 00：02:58 2019/02/03 04:56:06...

  • Page 19: Parking Monitor

    ⑦ Parking Monitor Default: OFF When Parking Monitor has been turned on, the dash cam will activate and start recording automatically once it detects motion when the car is parked. And it will turn off after continuously recording about 20 seconds. Tips Only turn on the Parking Monitor while parking, the dash cam will record when detecting a collision.

  • Page 20: Photo Settings

    2. Photo Settings ★ After being powered on, the dash cam enters the video mode and automatically starts recording. Then Capture Mode gle shot press OK Button to stop recording. Repeatedly press Power / Mode Button to switch to Resolution ★...

  • Page 21: System Menu Settings

    ③ Sequence Once set in photo burst mode, the camera will take 3 shots in a row every time the OK button is pressed. Otherwise, the camera only takes one photo every time the OK button is pressed. (Default: OFF) ④...
  • Page 22 ① Screen Saver Default: 1 Minute · When recording If you turn on Screen Saver Mode, the screen display will be turned off after a period of inactivity, but the camera is still recording when the screen display turns off. You can see the Blue Indicator Light is flash during recording.

  • Page 23: Language

    ④ Beep Sound This setting enables/disables a beep sound when you press any button on the camera. Default value: ON ⑤ Language This setting determines the language used for dash cam setting and interface. Default value: English ⑥ Screen Rotation This setting enables the screen rotating when you turn the camera upside down.

  • Page 24: Format

    · Please keeping upgrading the firmware in time to maintain the best user experience. · Make sure your device is always up to date with latest firmware. · Please check back frequently at ThiEYE website (thieye.com/support.html) for the latest firmware updates.

  • Page 25: Part 04 - Installation

    Part 04 - Installation 1. Connecting the Dash Cam and the Mount 2.Installing the Dash Cam ① Clean the area on the windshield where the dash cam will be installed. ② You can attach the suction cup mount or adhesive mount to the windshield where it will not obstruct the driver’s view.

  • Page 26: Part 05 - Connect To Computer

    Part 05 - Connect to Computer With TF card inserted, when connected to computer, three options will be available: Mass Storage, PC Camera, REC-mode. Mass Storage PC Camera REC_mode ★ Mass Storage allows the TF card to be accessed via computer as an external storage. ★...

  • Page 27: Part 06 - Frequently Asked Questions

    Part 06 - Frequently Asked Questions This reason is that you’ve turned on the Motion Detection. · The Motion Detection only works when the dash camera Why won’t the camera is Powered ON, the camera will record when it detects record continuously motion, which will cause discontinuous recording.
  • Page 28 Only need to turn on the Parking Monitor in video menu settings. (Don't need to turn on the G-sensor or motion detection). How to monitor while parking The dash camera will activate and start recording automatically when detecting a collision. Due to the huge HD video data, please use the high-speed SD card.

  • Page 29: Part 07 - Warranty

    Part 07 - Warranty · ThiEYE provides 12 months warranty for this product from the date of its original purchase. · Please feel free to let us know what we can do to assist you when you have any product problem.
