- Page 1 Reference Guide Main Unit Apeos 7580 Apeos 6580 Apeos 5580 November 2022 GM1668E1-1 Edition 1 FUJIFILM Business Innovation Corp.
- Page 2 This product uses eT-Kernel. eT-Kernel is a trademark of eSOL Co., Ltd. in Japan and other countries. Other company names or product names are registered trademarks or trademarks of each company. FUJIFILM and FUJIFILM logo are registered trademarks or trademarks of FUJIFILM Corporation. Apeos, ApeosWare, DocuWorks, PaperSecurity, Smart WelcomEyes and TrustMarkingBasic are registered trademarks or trademarks of FUJIFILM Business Innovation Corp.
- Page 3 Notations in Manual The following symbols are used in this manual. Indicates important information you have to know or be reminded before Important operations. Indicates supplemental information useful for operations. Note Indicates reference destinations. Refer “ ” Names and inputs of folders, files, apps, and functions. Also reference pages of the manual.
-
Page 4: Before Using The Machine
Before Using the Machine Device Components Front Component Function Duplex Automatic Document Load a document here. Feeder Document Cover Holds a document in place. Document Glass Load a document here. Control Panel Consists of operation buttons, LED indicators, and the Touch Panel Display. - Page 5 Component Function Waste Toner Container Cover Open this cover to replace the Waste Toner Container. Paper Trays 1, 2, 3, 4 Load paper here. Locking casters Used to move this machine. Lower Left Cover Open this cover to clear paper jams. Paper Tray 5 (Bypass) Used for loading non-standard paper that cannot be loaded in Trays 1, 2, 3, 4.
-
Page 6: Lan Connection
Component Function Telephone line connectors Use “TEL” to call when using the telephone or handset (TEL) (optional). Use “LINE 1” for calls using a handset connected to the TEL Telephone line connectors jack. (LINE1) Telephone line connectors (LINE2) Telephone line connectors (LINE3) Reset button Automatically switches the machine off when a current leakage... - Page 7 Inside Component Function Offset Catch Tray Outputs are delivered here. (optional) Waste Toner Open this cover to replace the Waste Toner Container. Container Cover Waste Toner Collects waste toner. Container Fusing Unit Fuses toner on paper. Handle Used to pull out the Transfer Unit. Transfer Unit Transfers toner images on the drum to paper.
-
Page 8: Control Panel
Control Panel Refer For Control Panel, refer to the “Reference Guide - Operations”. Component Function Built-in IC Card Used to authenticate a user using an IC card. Reader (optional) Paper Clip Tray Used for placing paper clips and staples. Power Button The power switches on. -
Page 9: Print Area
Component Function USB memory slot Insert a USB memory device directly here. (optional) Note A memory card reader or a USB memory device cannot be connected to the USB memory slot with a USB cable. Note that the machine will not recognize the memory on a memory card reader or a memory device connected to a USB interface connector on the rear side of the machine when a USB memory device is already inserted in the USB memory slot. - Page 10 Changing the extended printable area settings Login to the System Administrator Mode. > [Device] > [App Settings] > [Print Settings] > [Other Settings] > [Print Area] > [Extended]. You can change the settings from [Tray / Output] > [Edge Erase / Print Position] >...
-
Page 11: Recommended Paper
Paper Recommended Paper Standard paper Paper name Paper type setting for paper Image processing Image quality Paper weight tray to the paper type guarantee (g/m Plain Plain (A) Monochrome paper To use paper other than the above, contact your local representative. Recycled paper Paper name Paper type setting for... -
Page 12: Storing And Handling Paper
Storing and Handling Paper Storing paper Follow the guidelines below since paper is susceptible to moisture in the air and easily deformed by impacts. Store paper in a place of low humidity. Paper that has absorbed moisture can create paper jams or ... -
Page 13: Loading Paper
Basic Operations of the Machine Loading Paper After loading paper, configure the Paper Tray settings on the Home screen. Important Do not place paper or other objects in the reserved space of the tray. It may cause paper jams or machine malfunction. - Page 14 Pinch the two Guide Clips, and adjust to the correct paper size. Fan a stack of paper, face the print surface down, and then load the paper with edges aligned according to the direction of the arrow. Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction.
- Page 15 Fan a stack of paper, face the print surface down, and then load the paper with edges aligned according to the direction of the arrow. Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction. Push in the Paper Tray.
- Page 16 Slide the Paper Guide to the correct paper size. Setting special paper and other media Hole punched paper Paper orientation: Load paper with holes facing the right side when viewed from the front of the machine Postcards Paper orientation: SEF Refer “Notations in Manual”...
-
Page 17: Loading Documents
Loading Documents Document Feeder Loadable paper Paper size A3, 11 x 17" Custom size 84 x 140 mm to 297 x 432 mm Paper weight Single side printing 38 to 200 (g/m Double side printing 50 to 200 Maximum number of sheets (sheets) (C paper) Note When the Fax Kit is equipped, the loadable paper size is up to 600 mm for the length. -
Page 18: Document Glass
Open the Document Stopper. Note To prevent a document from being left behind, “Document Feeder Attention Light” is turned on after the Scan job is completed and turned off after approx. 3 sec. Document Feeder Attention Light Document Glass Loadable paper Paper size (mm) Width Up to 297... -
Page 19: Outputting Paper
Outputting Paper Print Surface The print surface refers to the surface printed on in single-sided printing (the first page in double- sided printing). Paper is output to the Output Tray with the print surface faced downward in the case of front side output, and with the print surface faced upward in the case of back side output. -
Page 20: Maintenance
Maintenance Consumables Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine. -
Page 21: Touch Panel Display
Stamp Replacement Kit Open the Document Cover and pinch the handle to open the Side 2 scanner. Stick included pins into the Stamp kit to extract Stamp ink. Insert new Stamp ink. Close the Side 2 scanner, then close the Document Cover. Cleaning Main Unit When wiping the main unit with a wet cloth, use a soft, moistened and tightly-squeezed cloth. -
Page 22: Document Feeder Rollers
Scanner Document cover, Document Glass, film, scanner glass For the cleaning method, refer to the label on the main unit. Wipe off any dirt with the supplied cloth about once a month. When stains cannot be removed easily, wipe them lightly with the soft cloth slightly moistened with a thin neutral detergent solution. -
Page 23: Paper Tray
Inside Lower Left Cover Open the Lower Left Cover. Note When High Capacity Feeder B1 is installed, hold the handle and fully move the unit to the left. Remove the jammed paper. Close the Lower Left Cover. Exit Depending on the optional units equipped in the right side of the machine, the method of paper removal differs. - Page 24 Remove the jammed paper. Push in the Paper Tray. Paper Tray 4 Pull out the Paper Tray 4 until it stops. Remove the jammed paper. If paper is jammed in the paper feed section, open the inner cover and remove the jammed paper. Slowly push in the Tray until it contacts the back side.
-
Page 25: Duplex Automatic Document Feeder
Duplex Automatic Document Feeder Remove all documents from the Document Tray. Pull up the front handle of the Top Cover and open the cover until it stops. Open the Left Cover until it stops. Left Cover Remove the document. If the document is caught in the entry, remove the jammed paper from the Left Cover. -
Page 26: Transfer Unit
Transfer Unit Note Before pulling out the Transfer Unit, check the screen display for any remaining paper in the left and right covers of the machine, Paper Tray 5 (Bypass), Exit, or optional High Capacity Feeder and Finisher. If the Transfer Unit is pulled out while paper is remaining in any of these locations, the paper may become torn. - Page 27 [2b], [2c] Open the handle [2b] ( ), turn the knob [2c] right ( and remove the jammed paper ( Return the handle [2b]. [2c], [2d] Open the handle [2d] right ( ), turn the knob [2c] right ), and remove the jammed paper ( Return the handle [2d].
-
Page 28: Main Specifications
Appendix Main Specifications This section lists the main specifications of the machine. Note that the specifications and the appearance of the product may change without prior notice. Note The specifications are not intended to guarantee the image quality performance and feeding ... - Page 29 Item Specification Reduction/enlargement Size-for-size:1: 1 ± 0.7% Preset: 50%, 70%, 81%, 86%, 115%, 122%, 141%, 200% Variable: 25 - 400% (1% increments) Continuous copy speed Paper size A4/JIS B5 JIS B4 JIS B5 (sheets/minute) 7580 (continuous 1-sided copy/same magnification, 6580 monochrome) 5580 Note...
-
Page 30: Print Function
Print Function Item Specification Type Built-in Print Size A3, 11 x 17" [12 x 18" (305 x 457 mm) with Bypass Tray] A5, Postcard (by Japan Post) Continuous Same as the Basic Specifications/Copy Function print speed Printing Standard: ART EX Standard 600 x 600 resolution... -
Page 31: Fax Function
Item Specification Scan 600 x 600, 400 x 400, 300 x 300, 200 x 200 resolution (dpi) Scan Speed Same as the “Scan Speed” of the Duplex Automatic Document Feeder Interface Standard Ethernet 1000BASE-T/100BASE-TX/10BASE-T Optional Wireless LAN (IEEE 802.11 a/b/g/n/ac) Box storage Supported TCP/IP (WebDAV, HTTP) -
Page 32: Internet Fax
Item Specification Transmission time 2 seconds or more but below 3 seconds Note When transmitting an A4 size 700-character document in the standard quality (8 x 3.85 lines/mm) and high speed mode (28.8 kbps or above: JBIG). This is only the transmission speed for image information and does not include the controlling time for the communication. - Page 33 Item Specification Interface Ethernet 1000BASE-T/100BASE-TX/10BASE-T IP fax (SIP) Item Specification Document size Same as the Fax Function Scanning resolution Same as the Fax Function Supported protocol SIP, JT-T.38 Coding method Same as the Fax Function Interface Ethernet 1000BASE-T/100BASE-TX/10BASE-T Duplex Automatic Document Feeder Item Specification Type...
-
Page 34: Location Of Warning And Caution Labels
Safety Notes Refer Also refer to “User's Manual”. Location of Warning and Caution Labels 5 Appendix... - Page 35 Symbol Marks Some of the following symbols may not be used depending on the model. DANGER, WARNING, Do not use creased Elapsed time and CAUTION paper Electric shock Do not use back Cleaning of scanner carbon paper Hot surface Do not use torn paper Dirt on the output paper Pinched fingers...
-
Page 36: License Agreement
EVENT WILL FUJIFILM BI NOR ITS LICENSOR BE LIABLE TO CUSTOMER FOR ANY CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES, INCLUDING ANY LOST PROFITS OR LOST SAVING, EVEN IF FUJIFILM BI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR ANY CLAIM BY ANY THIRD PARTY. - Page 37 8. Other Provisions (1) Adobe is original licensor of Software whose rights and intellectual properties are to be protected by this Agreement and may solely enforce the same right as of FUJIFILM BI provided in this Agreement. (2) This agreement is governed by the laws of Japan.
