Summary of Contents for Drive DeVilbiss Healthcare LPHWCSP19SIL
- Page 1 Phantom Aluminium Wheelchair (LPHWCSP19SIL, LPHWCTS19SIL) Instructions for use...
- Page 2 Introduction Intended purpose To provide manually propelled mobility to an individual who has a walking related disability and/or who does not have the full capacity to walk. Intended user group The wheelchair is intended for an individual who has a walking related disability and/or who does not have the full capacity to walk and has a weight of up to 135kg (21 stone).
-
Page 3: Parts Description
Parts description 12.5" QUICK 1/2 FOLD PUSH BRAKE PUSH WHEEL HANDLE REST RELEASE BACK LEVER HANDLE MECHANISM SIDE ARM REST PANEL SIDE PANEL BRAKE 24" WHEEL FRONT & HANDRIM CASTOR FOOTREST FOOT FRONT REST CASTOR STEPPER TUBE Self Propel model Transit model (LPHWCSP19SIL) (LPHWCTS19SIL) -
Page 4: Preparing For Use
Preparing for use These instructions should be read carefully before using the wheelchair. This product is not for user assembly and does not have a service manual. The following parts may be adjusted by approved service personnel to suit each user’s requirements: Brake Unit (Transit Models) Loosen the bolt heads with a 5mm hex key, sliding the brake unit along the frame. -
Page 5: Footrest Adjustment
Footrest adjustment To fit the footrests, align approximately 45º outwards, push down firmly into the frame (1) Attaching then rotate inwards (2) until they lock into place. the footrest Pull the handle and rotate to release. For optimum comfort it is important to attain the correct leg position. - Page 6 Transfer and use Before using the wheelchair, read the safety notices below; • Do not exceed the 10º maximum gradient. Use slow speeds and do not reverse down a gradient. • Do not use on escalators. • The wheelchair is only suitable for single occupancy. •...
- Page 7 Steep terrain, kerbs and steps Steep terrain: These wheelchairs are not designed for use on gradients beyond 10°. When on a slope, avoid swerving or sudden changes in movement. Over kerbs: Attendants push down on the stepper tube with a foot to raise the front castors (when mounting a kerb for example).
-
Page 8: Brake Operation
Brake operation Parking Brakes To apply the parking brakes, push the handle on the brake unit until locked in place. To release the brake, pull the handle in the opposite direction. The brakes should always be applied when the wheelchair is stationary. Cable Brakes On the transit model, the attendant pushing the wheelchair may use... -
Page 9: Disassembly And Storage
Disassembly and storage This wheelchair has a number of quick release components and the wheelchair frame is easily foldable. This facilitates a light carry weight and minimises storage space required. To disassemble for storage, transport or maintenance, follow the steps below. To reassemble components, reverse these instructions. -
Page 10: Care And Maintenance
Do not use a damaged or badly worn wheelchair. Users should routinely check for any malfunctions or changes in performance. See Accessories and Spare Parts section for approved parts available from Drive DeVilbiss Healthcare Ltd. • Before each use of the wheelchair, the brakes and tyres should be checked. It can be folded up for storage, with the parking brakes on. -
Page 11: Specification
Specification Model LPHWCSP19SIL LPHWCTS19SIL Maximum occupant mass 135 kg 135 kg Overall length with footrest 101 cm 97 cm Overall width 71 cm 66 cm Folded length 81 cm 69 cm Folded width 33 cm 28 cm Folded height 74 cm 74 cm Total mass 13.8 kg... - Page 12 This page is left blank intentionally. Phantom Aluminium Wheelchair (2022-01 rev2) Page 12 of 16...
- Page 13 This page is left blank intentionally. Phantom Aluminium Wheelchair (2022-01 rev2) Page 13 of 16...
- Page 14 This page is left blank intentionally. Phantom Aluminium Wheelchair (2022-01 rev2) Page 14 of 16...
-
Page 15: Warranty
Warranty Your Drive branded product is warranted to be free of defects in materials and workmanship for one year from date of purchase. This device was built to exacting standards and carefully inspected prior to shipment. This warranty is an expression of our confidence in the materials and workmanship of our products and our assurance to the customer. - Page 16 Sidhil Business Park, Holmfield, Halifax 4 Trench Road, Mallusk, Newtownabbey BT36 4TY, Northern Ireland West Yorkshire, HX2 9TN, GB Drive DeVilbiss Healthcare Ltd provide these instructions for use and product markings. info@drivedevilbiss.co.uk | www.drivedevilbiss.co.uk Service & Maintenance Spares Customer Service...
