Please contact us before returning the product to the store. Toll Free: 877-472-4296 MODEL: DH14001...
Page 2
LIMITED 90 DAYS WARRANTY This product is covered by a limited warranty that is effective for 90 days from the date of purchase. The warranty covers any defects in parts and workmanship. This Limited Warranty gives you specific legal rights and you may also have other rights which very from one state (province) to another.
IMPORTANT NOTICE! Please contact us before returning the product to the store. Please Keep Your Instructions! Your Model number is necessary should you need to contact us. Please read through this instruction manual book to familiarize yourself with all parts and assembly steps.
Page 4
DH14001 PARTS LIST Side Apron-A Side Apron-B Center Support Left Leg Playfield 1 Piece 1 Piece 1 Piece 2 Pieces 1 Piece Right Leg End Apron Leg End Panel Leg Side Panel 5/16" Flat Washer 2 Pieces 2 Pieces 2 Pieces...
Page 5
DH14001 PARTS LIST Goal Side PMMA End PMMA Puck Allen Key 2 Pieces 2 Pieces 2 Pieces 2 Pieces 1 Piece Pre-installed Pre-installed Pre-installed Pre-installed Long Puck Catcher Short Puck Catcher Long Scorer Display Wire with Sensor Short Scorer Display...
Page 6
ASSEMBLY INSTRUCTIONS 1. Find a clean, level place to begin the assembly of your Rod Hockey table. The table will be assembled upside down and then turned over on its legs once the assembly completed. This game table is heavy, and turning it over will require at least two strong adults.
Page 7
FI G.3 5. Slide the Playfield (#3) into the grooves of the End Aprons and Side Apron-A and attach the Side Apron-B(#2) to the End Aprons (#7). See FIG 3. FIG.3...
Page 8
FIG.4 6. Attach the Left Leg (#5) and Right Leg (#6) to the Apron using four Bolts (#11) and four Washers (#10) per Leg. See FIG.4. FIG.4 FIG.5 7. Insert Gear (#20) into the player groove on the underside of Playfield (#3). See FIG 5. FIG.5...
Page 9
FI G.6 8. Slide all Player Rods (#24, #25, #26, #27) through the Rod holes in the End Apron. See FIG.6. 9. Attach the Rod Stopper (#21) to the Player Rod using one Screw (#17) per Rod Stopper. See FIG.6B. 10.
Page 10
FI G.7 13. Slide the Goalie Control (#19) through the Goalie hole in the End Apron, secure the Goalie Control (#19) to the underside of the Playfield (#3) using the Bolt (#15), Washer (#51) and Nut (#16). See FIG 7A. 14.
Page 11
FI G.9 21. Attach the Goal (#41) to the end of playfield using two Screws (#14) per Goal. See FIG.9. 22. Slide the Side PMMA (#42) into the slot pre-set on the Side Apron. See FIG.9. 23. Slide the End PMMA (#43) into the slot pre-set on the End Apron. See FIG.9. 24.
Page 12
FI G.1 0 26. Attach the Apron Corner (#37) to the top of Leg using two Screws (#12).See FIG.10. 27. Attach the Apron Corner with Scorer (#38) to the top of Leg using two Screws (#12).See FIG.10. 28. Insert the Sensor Wire from Puck Catcher (#40) into the Control Box (#36). See FIG. 10A. 29.
