TMG -GWC3 Product Manual

Powered chipper shredder vacuum
Hide thumbs

Advertisement

Quick Links

PRODUCT MANUAL
V2022.03.24
MODEL TMG-GWC3
3-IN-1 KOHLER
POWERED CHIPPER
®
SHREDDER VACUUM
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
www.tmgindustrial.com
Toll Free:1-877-761-2819

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-GWC3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TMG TMG-GWC3

Summary of Contents for TMG TMG-GWC3

  • Page 1 PRODUCT MANUAL V2022.03.24 MODEL TMG-GWC3 3-IN-1 KOHLER POWERED CHIPPER ® SHREDDER VACUUM Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS General Safety Rules ..............3 Parts Description and Fuction.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING Read this Safety & Operating Instructions manual before you use the Wood Chipper. Become familiar with the operation and service recommendations to ensure the best performance of your machine. Safety Labels The WOOD CHIPPER carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the Safety and Information labels that appear on the equipment.
  • Page 4 Propose CAUTION This machine is designed solely to chip wood and must not be used for any other purpose. It should only be used by trained operators who are familiar with the content of this manual. It is potentially hazardous to fit or use any parts other than your dealer parts. The company disclaims all liability for the consequences of such use, which in addition voids the machine warranty.
  • Page 5 Always wear protective goggles or safety glasses with side shields while using the Wood Chipper to protect your eyes from possible thrown debris. Avoid wearing loose clothing or jewelry, which can catch on moving parts. We recommend wearing gloves while using the Wood Chipper. Be sure your gloves fit properly and do not have loose cuffs or drawstrings.
  • Page 6 engine and to the other moving parts of the machine. If required, see your authorized dealer for engine governor adjustments. Keep combustible substances away from the engine when it is hot. Never cover the machine while the muffler is still hot. Do not operate the engine with the air cleaner or the carburetor air intake cover removed.

  • Page 7: Parts Description And Fuction

    PARTS DESCRIPTION AND FUCTION Top Feed Hopper Side Feed Hopper Outlet Hopper 7HP KOHLER Engine Front Foot Support Tow Bar Vacuum Kit 13” Tubeless Tire www.tmgindustrial.com 07/21 Toll Free:1-877-761-2819...

  • Page 8: Products Specification

    PRODUCTS SPECIFICATIONS It may be helpful to familiarize yourself with the controls and features of the Wood Chipper. If you have any question, please contact the dealers in your area. Items Specifications Engine 7HP KOHLER® four strokes, Recoil Start Power Gasoline Chipper Capacity 2CBM/hour to 4CBM/hour...

  • Page 9: Unpacking & Assembly

    UNPACKING & ASSEMBLY 1. After unpacking, check the following components * All numbers are not part numbers in the drawings. For correct part numbers, see explosive diagram Description Quantity Description Quantity Main frame assembly Extension tube Top feed hopper assembly Extension tube connection Side feed hopper assembly Handle pole upper...
  • Page 10 1. Wheel Axle installation 10,11,29 Parts no. Description Specifications Quantity Main frame assembly Wheel axle Washer Ø8 Spring washer Ø8 Bolt M8X20 2. Tire installation www.tmgindustrial.com 10/21 Toll Free:1-877-761-2819...
  • Page 11 Parts no. Description Specifications Quantity Main frame assembly Tire 145/70-6 Ø 8x45 3. Front foot support installation Parts no. Description Specifications Quantity Main frame assembly Front foot support assembly Ø 8x60 www.tmgindustrial.com 11/21 Toll Free:1-877-761-2819...
  • Page 12 4. Tow bar and wheel assembly installation Parts no. Description Specifications Quantity Main frame assembly Front foot support assembly Tow bar assembly Wheel assembly Ø8x60 5. Side feed hopper installation 10,11,12,21 Parts no. Description Specifications Quantity Main frame assembly Side feed hopper assembly Bolt M8X25 Washer...
  • Page 13 6. Outlet hopper installation 32,33,34,35 Parts no. Description Specifications Quantity Main frame assembly Outlet hopper assembly Bolt M6x25 Washer Ø6 Spring washer Ø6 Lock nut 7. Close plate, Flange and top feed hopper installation 32,33,34,35 www.tmgindustrial.com 13/21 Toll Free:1-877-761-2819...
  • Page 14 10,11,29 WARNING When not using the vacuum function, you need to open the close plate, otherwise the top feed hopper will not feed. The machine will become a vacuum, which will seriously damage the machine Parts no. Description Specifications Quantity Main frame assembly Top feed hopper assembly Handle...

  • Page 15: Operating The Wood Chipper

    OPERATING THE WOOD CHIPPER It may be helpful to better familiarize yourself with the features of your Wood Chipper before beginning the steps outlined in this chapter. WARNING Read and understand all instructions, safety precautions, and/or warnings listed in “General Safety Rules” before operating the WOOD CHIPPER.
  • Page 16 Wood Chipping NOTICE Woods’ and branches’ diameter should be no bigger than 75mm. WARNING Do not place your hands into the chute when loading. This is a very UNSAFE method and could result in injury to your hands. Do not reach or step across the rail while the Wood Chipper is running. This is a very UNSAFE method which could cause personal injury, even death.
  • Page 17 Description Quantity Extension tube Extension tube connection Handle pole upper Handle pole down Suction mouth Fastening ring 2. Use the Vacuum function When the vacuum function is used, it is necessary to turn off the close plate, the machine will become a vacuum, and then the vacuum function can be used.

  • Page 18: Maintaining The Wood Chipper

    MAINTAINING THE WOOD CHIPPER Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the engine manufacturer's user manual for maintenance procedures. WARNING Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact the dealers in your area. WARNING Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool.

  • Page 20: Explosion View And Parts List

    EXPLOSION VIEW AND PARTS LIST www.tmgindustrial.com 20/21 Toll Free:1-877-761-2819...
  • Page 21 Part No. Description Part No. Description Hitch trailer Outside chipper room Bolt M10*50 Bolt M8*20 Washer Ø10 Cover plate Lock nut M10 Bolt M6*20 Tow bar Bolt M6*25 Safety pin Ø8*60 Washer Ø6 Tow bar connecting part Spring washer Ø6 Hexagon flange bolt M8*55 Lock nut M6 Rubber washer M30*15...
