- Page 1 User Manual RSR 10138 EU EN ES PT PL www.teka.com...
-
Page 2: Table Of Contents
CONTENTS 1 1 Warning 2 1 Placement 2 2 Level ing feet Door Right-Left Change (optional 3 1 Key components 4 Maintenance of refrigerator 4 1 Cleaning Stop using 5 Trouble shooting... -
Page 3: 1 Warning
1 Safety warnings 1.1 Warning This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non- retail applications. - Page 4 Refrigerant and cyclopentane foaming material used for the appliance are flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
- Page 5 This is a prohibition symbol. Any incompliance with instructions marked with this symbol may result in damage to the product or endanger the personal safety of the user. Prohibition symbol This is a warning symbol. It is required to operate in strict observance of instructions marked with this symbol;...
- Page 6 1 4 Warnings for using Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the refrigerant circuit; maintenance of the appliance must be conducted by a specialist Damaged power cord must be replaced by the manufacturer, its maintenance department or related professionals in order to avoid danger.
- Page 7 Do not store beer, beverage or other fluid contained in bottles or enclosed containers in the freezing chamber of the refrigerator; otherwise the bottles or enclosed containers may crack due to freezing to cause damages. 1.6 Warnings for energy 1)Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
-
Page 8: 1 Placement
2 Proper use of refrigerators 2 1 Placement Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the refrigerator; tear off the protective film on the doors and the refrigerator body. Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent rust or reduction of insulating effect. -
Page 9: 2 Level Ing Feet L
2 Levelling feet Schematic diagram of the levelling feet Adjusting procedures: a. Turn the feet clockwise to raise the refrigerator; b. Turn the feet counterclockwise to lower the refrigerator; c. Adjust the right and left feet based on the procedures above to a horizontal level. -
Page 10: Door Right-Left Change
Door Right-Left Change Parts to be used for door reverse Putty knife Cross screwdriver Number Name Number Note Pre-installed on the refrigerator, still used when door Upper hinge 5/16 Masking tape Pre-installed on the refrigerator, still used when door Hinge cover Tapping locking Pre-installed on the refrigerator, still used when door screw... - Page 11 4 Dismantle the stopper under the door stopper 5 Install the door on the lower hinge assembly, and then install the upper hinge, hinge cover, pins and hole cap in sequence. Hinge cover Upper hinge...
- Page 12 Light(optional) 4 Changing Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its service agent or similar qualified person. Replacement must first cut off the power supply. product or statement by the distributor 5 Starting to use Before initial start, keep the refrigerator still for half an hour Spare enough space for convenient opening of the doors and drawers or...
-
Page 13: 1 Key Components
3 1 Key components Little door Small tray Temperature- control knob Lamp Small tray Shelf Shelf Large tray Fruits and CE-BC80CM Refrigerating chamber The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consume in the short term. Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature. - Page 14 3 2 Functions Turn the temperature control knob to MAX, the internal temperature of the refrigerator becomes lower. Turn the temperature control knob to MIN, the internal temperature of the refrigerator becomes higher. The letter on the knob only represents the level, but does not mean the specific temperature, the "OFF"...
-
Page 15: Maintenance Of Refrigerator
4 Maintenance of refrigerator 4.1 Cleaning Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent. Please turn off the power before cleaning interior, remove all foods, two tablespoons of baking soda and a quart of warm water. -
Page 16: Trouble Shooting
Trouble shooting You may try to solve the following simple problems by yourself. Check whether the appliance is connected to power or Not work Check whether the voltage is too low Check whether there is a power failure or partial circuits have tripped Odorous foods shall be tightly wrapped Odor Check whether there is any rotten food... - Page 17 Table 1 Climate classes Class Symbol Ambient temperature range + 10 to + 32 Extended temperate Temperate + 16 to + 32 Subtropical + 16 to + 38 Tropical + 16 to + 43 Extended temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging from 10 °C to 32 °C’;...
