jbc Advanced Series Manual

GARANTIE
DEUTSCH
Für das vorliegende Gerät übernimmt
JBC eine Garantie von 2 Jahre , für alle
Fabrikationsfehler. Diese Garantie
schliesst die Reparatur bzw. den Ersatz
der defekten Teile sowie die
entsprechenden Arbeitskosten ein.
Ausgeschlossen von dieser Garan-
tieleistung sind durch unsachge-
mässen Gebrauch hervorgerufene
Betriebsstörungen.
Zur Inanspruchnahme dieser Garantie
muss das Gerät portofrei an den
Vertriebshändler geschickt werden, bei
dem es gekauft wurde. Fügen Sie dieses
vollständig, ausgefüllte Blatt, bei.
GARANZIA
ITALIANO
La JBC garantisce quest'apparato 2 anni
contro ogni difetto di fabbricazione, e
copre la riparazione e la sostituzione dei
pezzi difettosi, includendo la mano
d'opera necessaria.
Sono escluse da questa garanzia le avarie
provocate da cattivo uso dell'apparato.
Per usufruire di questa garanzia, è
indispensabile inviare, in porto franco,
l'apparato al distributore presso il quale
è stato acquistato, unitamente a questo
foglio debitamente compilato.
SERIAL Nº
STAMP OF DEALER
SELLO DEL DISTRIBUIDOR
CACHET DU DISTRIBUTEUR
STEMPEL DES HÄNDLERS
TIMBRO DEL DISTRIBUTORE
DATE OF PURCHASE
FECHA DE COMPRA
DATE D'ACHAT
KAUFDATUM
DATA DI ACQUISTO
AD 2200
Control Unit 230V 50Hz EU Ref. 2200200
Control Unit 230V 50Hz UK Ref. 2200201
Control Unit 120V 60Hz US Ref. 2200100
2210 Handpiece
2245 Handpiece
2210 Handpiece Ref. 2210000. Power: 20W. For high precision work, SMD, etc.
2245 Handpiece Ref. 2245000. Power: 50W. For general soldering work.
The handpieces and cartridges 2210 and 2245 comply with the MIL-SPEC-2000 referring to the potential
difference between the soldering tip and ground connection, must be less than 2 mV.
The handpieces 2210 and 2245 can be connected to the following JBC stations:
AD 2200, AD 4200, AR 5500 and AM 6000.
2210 Handpiece
Ref. 2210000
Structure of Advanced soldering stations system
The Advanced series has basic modules giving you
full flexibility for choosing what you need for the work
in hand, the modules being supplied separately.
Control unit
- AD 2200
Double control unit
- AD 4200
Handpieces
- 2210 and 2245
Cartridges
- Range of cartridges 2210 and 2245.
Stand
- Soldering iron stand AD 8200 Ref. 0268200
For a station to work properly, a control unit, a handpiece
and one cartridge are needed. The soldering iron stand
is necessary to connect the handpieces to the AD 4200,
AR 5500 and AM 6000 stations.
Cartridges
2210
See overleaf for range
Cartridges
See overleaf for range
2245 Handpiece
Ref. 2245000
Cartridges 2245
Cartridges 2210
2245
SOLDERING
H A N D P I E C E S
2210
2245
