TP-Link TL-SG108 Installation Manual
5/8/16-port gigabit desktop switch
Hide thumbs
Also See for TL-SG108:
- Installation manual ,
- User manual (17 pages) ,
- Mounting manual (5 pages)
Advertisement
Quick Links
Installation Guide
5/8/16-Port Gigabit Desktop Switch
Note:
For simplicity, we will take TL-SG108 for example throughout this Guide.
Connection
Power Adapter
Router
WAN Port
LAN Port
LED Explanation
Power
On:
Power on
Off:
Power off
Link/Act
(For TL-SG105/TL-SG105S/TL-SG108/TL-SG108S)
Link/Act (Green)
On:
Running at 10/100/1000 Mbps
Off:
No device is linked to the corresponding port
Flashing:
Transmitting/receiving data
Link/Act
(For TL-SG116)
1000M (Green)
On:
Running at 1000 Mbps
Flashing:
Transmitting/receiving data
10/100M (Yellow)
On:
Running at 10/100 Mbps
Flashing:
Transmitting/receiving data
TL-SG108
Link/Act
PC
PC
Ethernet Ports (1-8)
