value, the whole line will display in red. If it complies with the reference value, it
displays in blue (normal mode).
4. The indicator 1/X shown on the bottom of the screen stands for the current
page/total page number. Swipe the screen from the right/left to advance/return to
the next/previous page.
There are 3 types of display modes available for data viewing, allowing you to
view various types of parameters in the most suitable way.
 Value – this is the default mode which displays the parameters in texts and
shows in list format.
 Graph – displays the parameters in waveform graphs.
 Combine – this option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors.
On-screen Buttons:
(Single graph): Tap it to view the waveform.
• Min/Max: Tap it to define the maximum/minimum value. When the value
goes beyond the specified value, the system will alarm.
Graph: Tap it to view the waveform.
• Combine: This option is mostly used in graph merge status for data
comparison.
• Value: Tap to display the parameters in texts.
• Customize ( ): Tap it, a pull-down list of the data stream items appears
