No. Item
1 Display tablet
2 VCI
VCI extension
3
cable
4 Power adaptor
Type A to Type B
5
data cable
Type A to Type C
6
data cable
7 Password envelope
8 Quick Start Guide
Descriptions
Indicates the test result.
Collects vehicle data and sends it to the
tablet for analysis.
Connects the VCI to the OBD II
vehicle's DLC.
For charging the tablet via AC outlet.
Connects the VCI module to the tablet
to perform vehicle diagnosis.
Connects the tablet to a PC to
exchange data.
A piece of paper bearing the product
Serial Number and Activation Code for
product registration.
A quick reference guide to product
operations.
2
X-431 Torque LINK User Manual
Qt.
1
1
1
1
1
1
1
1
