- Page 1 Installation & Manual Central Heating Stove With Solid Fuel Model TKS-18 Tested according to DIN EN 13240 For product efficiency and emission values, see the declaration of conformity!
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ..............................3 2. GENERAL INFORMATION ............................. 3 3. SAFETY ................................. 4 4. INSTALLATION AND CONNECTION ........................4 4.1 SAFETY DISTANCES (MINIMUM DISTANCE) ....................5 4.2 STOVE INSTALLATION AND CONNECTION ..................... 6 4.2.1 Mechanical Thermostat .......................... 6 4.2.2 Chimney Connection .......................... -
Page 3: Introduction
1. INTRODUCTION Wood stoves provide a comfortable and easy-to-use. These heating units combine pleasure with a fireplace view. It is an independent heating unit. The stove body is made of steel and the food heating chamber is made of Teflon or enamel coating. -
Page 4: Safety
3. SAFETY THE VENTILATION CONDITIONS WHERE THE PRODUCT WILL BE INSTALLED AND THE PROTECTION AGAINST FREEZING MUST BE TAKEN INTO CONSIDERATION. All the required standard examinations are tested for the product. The predicted parameters associated with combustion efficiency and exhaust gas emissions are observed. -
Page 5: Safety Distances (Minimum Distance)
4.1 SAFETY DISTANCES (MINIMUM DISTANCE) While installing the stove, the fire regulations and chimney’s instructions must be complied. For any related questions please ask the chimney installer. Minimum distances to be observed in flammable or heat-sensitive materials (eg furniture, wallpaper, wood panels) (see diagram below) are: 25cm from rear wall 15cm from lateral wall and 80cm from the radiation area (front side of the product) -
Page 6: Stove Installation And Connection
50cm (front length) 30cm (lateral length from the inner edge of the fire chamber cover) You can order the floor protection plate from seller when you require. 4.2 STOVE INSTALLATION AND CONNECTION Product installation and assembly should be done according to the user manual and by an authorized person. -
Page 7: Chimney Connection
The mechanical thermostat should be set to the highest degree (90ºC) when the stove is burning.The chain connected to the mechanical thermostat and the vent cover ensures wide opening of the vent cover. After about 15-20 min – the stove becomes hot enough - you can set the Mechanical Thermostat to the required temperature, it should not be under 40ºC;... -
Page 8: Combustion And Heating
CAUTION: Never use wallpaper, chipboard waste, plastic or treated wood (paint, coating, etc.) for heating! Otherwise, the chimney and flue pipes may be blocked. Caution: Do not use flammable materials (thinner, paint, gasoline etc.) 5.2 COMBUSTION AND HEATING First of all put 3-4 bricket wood in the fire chamber and put small pieces of wood or paper to burn. -
Page 9: Ashtray Discharge
5.2.3 Ashtray Discharge After a long period of combustion, at least once a day, the ash should be transferred from the grid to the ash tray by using the ash-handle. We advise you to do this when the stove is cold. When half of the ashtray is filled, draining should be considered. -
Page 10: Problem And Causes
The surface of the stove should not be cleaned with scratching and harmful cleaning material because otherwise the paint surface may be damaged. 6.1 PROBLEM AND CAUSES Reasons why the stove does not Solution heat or smoke coming out Check the chimney efficiency. Clean The stove or the stove-pipe let your stove and stove pipes on time ( see smokes continuously... -
Page 11: General Warranty And Policies
7. GENERAL WARRANTY AND POLICIES ARAL MAKİNA MADENİ EŞYA SAN. VE TİC.LTD. ŞTİ provides warranty to the buyer within the framework of legal provisions. 2 (two) year warranty period against production defects starts from the actual delivery date. An invoice must be presented for inclusion in the warranty.
