GE JV694 Use And Care & Installation Manual
  1. Manuals
  2. Brands
  3. GE Manuals
  4. Ventilation Hood
  5. JV694
  6. Use and care & installation manual
GE JV694 Use And Care & Installation Manual

GE JV694 Use And Care & Installation Manual

36" hood
Hide thumbs Also See for JV694:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Safety instructions.........................2
Operating instructions ...............3
Automatic Thermostat .................................3
Controls ............................................................3
Cleaning...........................................................3
Light Bulb Replacement...............................3
GE Appliances
36'
Installation ............................................4-6
Damper/Duct Connector .,..........................4
Filter Panel .......................................................5
Mounting Brackets ........................................5
Electrical Wiring .............................................6
Consumer Services.....................7
important Phone Numbers..........................7
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JV694 and is the answer not in the manual?

Questions and answers

Related Manuals for GE JV694

Summary of Contents for GE JV694

  • Page 1: Table Of Contents

    36’ Installation ..........4-6 Safety instructions......2 Damper/Duct Connector .,......4 Filter Panel ............5 Mounting Brackets ........5 Operating instructions ....3 Electrical Wiring ..........6 Automatic Thermostat .........3 Controls ............3 Consumer Services.....7 important Phone Numbers......7 Cleaning............3 Light Bulb Replacement.......3 GE Appliances...
