All Traffic Solutions ATS 3 Manual

ATS 3 Trailer with Integrated Solar Option
Thank you for purchasing an ATS 3 Trailer with the Integrated Solar Option and the Single-
Arm Solar Panel Mounting Bracket. This guide will show you how to set up your new trailer
and Integrated Solar system. The trailer can be paired with a SpeedAlert 18 Radar Message
Sign, InstAlert 18 Variable Message Sign, or Shield 12 or Shield 15 Radar Speed Sign. The
ATS 3 Trailer is compact and has a low tongue weight, making one-person deployment very
manageable. Power comes from our Integrated Solar Option, an integrated system of lithium batteries and solar
charging (see The Integrated Solar Option on the next page).
[Figure 1] ATS 3 Trailer and SA 18 with Integrated
Solar
Before you begin
If you have a TraffiCloud Web subscription, the first thing you'll need to do to get started using your signs with
TraffiCloud is to create at least one Site for each sign remotely, in advance, from your office. With TraffiCloud, you
configure a sign's Site for everything from speed to messaging (if equipped), reports, alerts and more. Sites are the
key to generating traffic reports, because TraffiCloud organizes traffic data for reports by Site. If necessary, you can
also perform these steps after you install a sign at a physical location. See "Creating a Site" in the Getting Started with
TraffiCloud Guide for your sign.
If you don't have a Web subscription, you can set up the sign while you are on location, using the onboard buttons
on the sign. You can also set up a Site with TraffiCloud Sign Manager for Windows, over a USB or Bluetooth
connection, and perform basic sign setup with the TraffiCloud Mobile app for Android over Bluetooth. See Step
4: Configure the sign manually (optional) on page 9.
Viewing this document
This guide is best viewed in Adobe® Reader or Adobe Acrobat Pro, using the default two-page view
directly in a Web browser.
ATS | Chantilly, VA | United States | Tel: 1-866-366-6602 | Email:
Copyright © 2022 | All Traffic Solutions, Inc.® | Document ver.1.0 | All rights reserved.
[Figure 2] Integrated Solar components (trailer mounted)
