P4BEA User's Manual
2.3.3

Memory Configuration

There is no jumper setting required for the memory size or type. It is automatically
detected by the system BIOS, and the total memory size is to add them together
DIMM Socket
DIMM1
DIMM2
2.4

I/O Connections/Panel Connections

I/O Connections
ATXPWR
ATXR1
CPUFAN
CHASFAN
JIR
JWOL
FLOPPY
IDE1, 2
MS
KB
COM1/JCOM2
PRINTER
USB
LAN
GAME
LINE_OUT
LINE_IN
MIC
CDIN
AUX
DIMM Modules
PC1600/2100 DDR DRAM 64, 128, 256, 512MB,1GB
PC1600/2100 DDR DRAM 64, 128, 256, 512MB,1GB
ATX Power series Connector
ATX Power +12V Connector
CPU Fan connector
Chassis Fan connector
Infrared Connector
Wake up on LAN connector
Floppy Disk Drive Connector
Primary/ Secondary IDE Connectors
PS/2 Mouse Port
PS/2 Keyboard Connector
Serial Ports 1 & 2
Printer Port
USB Connector
LAN Connector
Game/MIDI Connectors
Line out Connector
Line in Connector
Microphone in Connector
The Connector is for CDIN audio cable
The Connector is for AUX audio cable
17
